Efficient near-infrared luminescence in a Na₂CaTi₂Ge₃O₁₂:Cr³⁺ garnet for light-emitting-diode applications

Abstract

Near-infrared phosphor-converted light-emitting diodes (NIR pc-LEDs) have emerged as ideal light sources for a variety of advanced spectroscopy applications, demonstrating the importance of developing efficient NIR phosphors. In this work, a Ti⁴⁺-containing garnet, Na₂CaTi₂Ge₃O₁₂, was selected as the host material to minimize the ionic size mismatch after Cr³⁺ substitution. Interestingly, this substitution generates charge self-balance, enabling excellent efficiency of the developed material. Under 465 nm excitation, it exhibits broadband emission covering the first NIR window (λ_em,max = 790 nm) with a full width at half maximum (FWHM) of 120 nm. The optimized sample achieved a photoluminescence quantum yield (PLQY) of 75%. Moreover, a NIR pc-LED device was fabricated by combining the optimized phosphor with a blue (λ_em = 455 nm) InGaN chip. Upon application of a driving current of 100 mA, the device demonstrated a NIR output power of 18.24 mW and a corresponding NIR photoelectronic conversion efficiency of 6.49% and exhibited excellent performance in biological tissue imaging and non-destructive testing. Therefore, this work provides an efficient NIR phosphor, which has promising potential in spectroscopy applications.

---

1. Introduction

Near-infrared (NIR) spectroscopy in the region of 700–1100 nm has a wide range of applications in fields, such as security monitoring, biological imaging, and medical diagnostics, due to its invisibility to the human eye and strong penetration capability in biological tissues of these wavelengths.^1–7 However, conventional NIR light sources, including incandescent and halogen lamps, suffer from low efficiency, short lifetimes, large volumes, and poor spectral tunability, which cannot meet the requirements for intelligent applications of NIR light sources in portable devices.^8–12 In contrast, NIR phosphor-converted light-emitting diodes (NIR pc-LEDs), manufactured by coating a NIR phosphor on a high-brightness blue InGaN LED chip, exhibit high efficiency, spectral tunability, small size, and low cost, making them ideal NIR light sources for multifunctional smart applications.^13,14 As a crucial component, the NIR phosphor is the key material determining the output power and spectral coverage of a NIR pc-LED device. Therefore, there is a significant demand for developing efficient NIR phosphors.

To date, various activators have been adopted to achieve NIR emission via directly doping inorganic compounds.¹⁵ Among them, Cr³⁺ ions, when introduced in a weak crystal field, exhibit broadband absorption in the blue light region and produce spin-allowed ⁴T₂ → ⁴A₂ transitions, realizing broadband NIR emission. Moreover, the emission peak wavelength can be tuned by adjusting the octahedral field strength, making the output spectrum of the device designable.¹⁶ However, as the 3d electrons of Cr³⁺ are exposed in the outer layer, the 3d–3d transitions are easily affected by external environments, including lattice vibrations and high-energy phonons, making it a challenge to develop efficient Cr³⁺-activated NIR phosphors with excellent thermal stability.

Recently, Cr³⁺-doped garnet NIR phosphors have attracted considerable attention due to their superior photoluminescence quantum yields (PLQY) and thermal robustness, as exemplified by Y₃In₂Ga₃O₁₂:Cr³⁺ (λ_em,max = 760 nm, PLQY = 91.6%, I_423K/I_298K = 100%), Ca₃Sc₂Si₃O₁₂:Cr³⁺ (λ_em,max = 770 nm, PLQY = 92.3%, I_423K/I_298K = 97.4%), SrLu₂Al₃ScSiO₁₂:Cr³⁺ (λ_em,max = 785 nm, PLQY = 89.4%, I_423K/I_298K = 97.6%), Y₃Ga₃MgSiO₁₂:Cr³⁺ (λ_em,max = 782 nm, PLQY = 79.9%, I_423K/I_298K = 84.4%), Gd₃Al₂Ga₃O₁₂:Cr³⁺ (λ_em,max = 730 nm, PLQY = 97.3%, I_423K/I_298K = 96.8%), and Gd₃Mg_0.5Al_1.5Ga_2.5Ge_0.5O₁₂:Cr³⁺ (λ_em,max = 763 nm, PLQY = 90%, I_423K/I_298K = 85.3%).^9,17–21 However, garnets always have a strong crystal field, resulting in emission wavelengths shorter than 790 nm for most Cr³⁺-activated garnet phosphors. To achieve relatively long-wavelength NIR emission, a universal strategy is to weaken the crystal field strength by introducing cations with larger ionic size, such as Sc³⁺ (r_6-coor. = 0.745 Å), In³⁺ (r_6-coor. = 0.80 Å), Mg²⁺ (r_6-coor. = 0.72 Å), and Zr⁴⁺ (r_6-coor. = 0.72 Å) ions.^22–29 However, the Ti⁴⁺ (r_6-coor. = 0.605 Å) ion is rarely considered for incorporation into garnet phosphor materials, mainly due to its small radius, which is unlikely to generate a weak crystal field environment; moreover, the non-equivalent substitution by Cr³⁺ ions will lead to the formation of defects, which are detrimental to the luminescence efficiency. Notably, outside the garnet system, some Ti⁴⁺-containing phosphors exhibit excellent luminescence performance, such as Li₂Mg₃TiO₆:Cr³⁺ with a PLQY as high as 72.1%.³⁰ In fact, Ti⁴⁺ ions have an ionic radius very similar to that of Cr³⁺ (r_6-coor. = 0.615 Å), which can minimize the ionic radius mismatch and lattice distortion caused by Cr³⁺ substitution.

Based on the above considerations, here, we attempted to introduce Ti⁴⁺ ions into the octahedral sites of a garnet. To suppress the formation of defects or Cr⁴⁺ caused by Cr³⁺ substitution, the dodecahedral site was set to be co-occupied by Na⁺ and Ca²⁺ ions to self-balance the charge. Consequently, the Na₂CaTi₂Ge₃O₁₂ garnet material was proposed as a host for Cr³⁺ substitution and was synthesized via a solid-state reaction method at a relatively low temperature. This material exhibits broadband emission centered at 790 nm, which has a full width at half maximum (FWHM) of 120 nm and effectively covers the NIR-I region. The optimized Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ sample demonstrates a PLQY of 75.06% and an absorption efficiency (AE) of 34.07%. The fabricated NIR pc-LED device achieves a NIR output of 18.24 mW and efficiency of 6.49% under a driving current of 100 mA. This material shows promising potential for applications in biological tissue imaging and non-destructive testing.

2. Experimental

2.1. Synthesis

Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0, 0.005, 0.01, 0.02, 0.04, 0.06, 0.08, and 0.1) samples were synthesized using the conventional high-temperature solid-state reaction method. The raw materials, including Cr₂O₃ (Aladdin, 99.99%), NaHCO₃ (Aladdin, 99.95%), CaCO₃ (Macklin, 99.9%), TiO₂ (Aladdin, 99.99%), and GeO₂ (Aladdin, 99.999%) were accurately weighed based on the chemical composition. To compensate for the loss of Na at high temperature during the synthesis process, an excess of 5% NaHCO₃ was added. The powders were thoroughly ground in an agate mortar for 30 min. The mixtures were subsequently transferred to alumina crucibles and sintered in a tube furnace under an air atmosphere. The synthesis temperature was set to be 1000 °C and retained for 8 h. The cooled product was then removed from the crucible and ground into fine powder for subsequent characterization and analysis.

2.2. Characterization

X’Pert³ PANalytical (Cu Kα, λ = 1.5406 Å) was used to record X-ray diffraction (XRD) patterns of the samples. Rietveld refinements of the XRD patterns were performed using the GSAS software to determine the precise crystal structures. VESTA software was used to visualize the crystal structure. Electron paramagnetic resonance (EPR) spectra were recorded at 77 K (liquid nitrogen) using a JESFA300 spectrometer. Photoluminescence (PL) spectra and fluorescence decay curves were acquired using the FLS-980 fluorescence spectrophotometer (Edinburgh Instruments). Diffuse reflectance (DR) spectra were recorded on a UV-3600 plus UV-NIR Spectrophotometer (Shimadzu, Japan). PLQY and AE were measured using a Quantaurus-QY Plus C13534-11 (Hamamatsu Photonics). NIR pc-LED devices were fabricated by mixing the optimized Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ phosphor with UV photosensitive resin in a 1 : 1 weight ratio and coating the mixture on 455 nm LED chips. The NIR output power, photoelectric conversion efficiency, and electroluminescence spectra of the devices were recorded on the HAAS2000 High Accuracy Array Spectroradiometer photoelectric system (EVERFINE, China).

3. Results and discussion

3.1. Crystal structure

The phase purity and crystal structure of the synthesized Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0, 0.005, 0.01, 0.02, 0.04, 0.06, 0.08, and 0.10) samples were identified using XRD patterns as shown in Fig. 1a. The diffraction peaks of all samples are in excellent agreement with the standard XRD pattern for Na₂CaTi₂Ge₃O₁₂ (ICSD no. 15418), being isostructural with our previously reported Na₂CaZr₂Ge₃O₁₂ garnet,²⁵ confirming the successful synthesis of the target compounds with a single pure garnet phase. Notably, Cr³⁺ substitution even at a high concentration (x = 0.1) did not cause significant variations in the XRD patterns, indicating that the substitution did not change the garnet phase. In these garnets (Fig. 1b), the octahedral and tetrahedral sites were expected to be occupied by Ti⁴⁺ and Ge⁴⁺, respectively, forming [TiO₆] and [GeO₄] polyhedrons, while the dodecahedral site was expected to be filled with Na⁺ and Ca²⁺ ions with an atomic ratio of 2 : 1. To confirm this hypothesis, Rietveld refinements were performed on the XRD pattern of the undoped Na₂CaTi₂Ge₃O₁₂ (Fig. 1c) and Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ (Fig. 1d) samples. The refined structural parameters are provided in Table 1, and atomic positions are provided in Tables S1 and S2 (ESI†). The excellent residual factors validate the success of these refinements and confirm the crystal structure as expected.

Fig. 1 (a) XRD patterns of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0–0.10) samples compared with the standard card for the Na₂CaTi₂Ge₃O₁₂ garnet. (b) Crystal structure of Na₂CaTi₂Ge₃O₁₂. Rietveld refinement of powder XRD data patterns for (c) Na₂CaTi₂Ge₃O₁₂, and (d) Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺. (e) Lattice parameters (a/b/c) and (f) cell volume (V) of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0–0.10) samples. (g) EPR spectra of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.04 and 0.08).

Table 1 Refined results of XRD patterns for Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0, and 0.06)

Formula	Na2CaTi2Ge3O12	Na2CaTi1.94Cr0.06Ge3O12
Temperature (°C)	25	25
Radiation type; λ (Å)	X-ray; 1.5406	X-ray; 1.5406
2θ range (deg)	15–90	15–90
Space group; Z	Ia3̄d	Ia3̄d
β (deg)	90	90
a = b = c (Å)	12.268569	12.267690
Unit cell volume (Å^3)	1846.64	1846.24
Weighted profile R-factor, Rwp	9.47%	8.51%
Profile R-factor, Rp	6.70%	6.08%
χ ^2	1.264	1.016

---

In these garnets, Cr³⁺ (r_6-coor. = 0.615 Å) is expected to replace Ti⁴⁺ (r_6-coor. = 0.605 Å) in the octahedral site, owing to their similar ionic radii. Generally, the slightly larger Cr³⁺ substituting smaller Ti⁴⁺ will, to some extent, induce lattice expansion. However, the lattice shrinkage was detected after Cr³⁺ substitution, deduced from the refined results as shown in Table 1. To verify this trend, the lattice parameters (a and V) of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0, 0.005, 0.01, 0.02, 0.04, 0.06, 0.08, and 0.1) samples (Fig. 1e and f) were determined by performing Rietveld refinements. A linear lattice shrinkage is clearly observed as the Cr³⁺ substitution ratio increases. This phenomenon seems abnormal when only Cr³⁺ substituting Ti⁴is considered. In fact, the same amount of smaller Ca²⁺ (r_8-coor. = 1.12 Å) will substitute larger Na⁺ (r_8-coor. = 1.18 Å), driven by the need to maintain charge self-balance. Therefore, it can be considered that co-substitution is happening, with a slightly smaller [Cr³⁺–Ca²⁺] unit replacing the slightly larger [Ti⁴⁺–Na⁺] unit, which should be the origin of the lattice shrinkage. This result confirmed that defects formed by Cr³⁺ substituting Ti⁴⁺ can be avoided via automatic adjustment of the Na⁺/Ca²⁺ ratio in the dodecahedral site, which demonstrates the beneficial effects of mixed site occupation in stabilizing the Cr³⁺ valence state and preventing the formation of defects.

To reveal the local structural environment of Cr³⁺ ions in these garnets, EPR spectra of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.04 and 0.08) samples were collected at 77 K as presented in Fig. 1g. The dominant resonance signal observed at g = 3.97 is attributed to isolated Cr³⁺ ions occupying octahedral sites, while the signal at g = 1.93 is derived from exchange-coupled Cr³⁺–Cr³⁺ ion pairs, suggesting most of the Cr³⁺ ions are isolated. Notably, no additional resonance signals corresponding to Cr³⁺ ions occupying other crystallographic sites can be observed in the EPR spectra, which further corroborates the incorporation of Cr³⁺ ions only into the octahedral sites of Na₂CaTi₂Ge₃O₁₂.

3.2. Photoluminescence

The band gap of the host material plays an important role in the photoluminescence properties of phosphors. To evaluate the bandgap of the Na₂CaTi₂Ge₃O₁₂ host, DR spectra were collected as shown in Fig. 2a. The DR spectrum of the host demonstrates strong absorption in the ultraviolet region of this garnet. The band gap can be estimated from the optical bandgap (E_g) calculated using the Kubelka–Munk function:^31,32where F(R) is the absorption coefficient while R is the reflectance, hν is the photon energy, and A is a constant. The value of n is determined by the electronic transition type, with n = 1/2, 3/2, 2, and 3 corresponding to direct allowed transition, direct forbidden transition, indirect allowed transition, and indirect forbidden transition, respectively. In this class of garnet material, the electronic transition usually belongs to the direct allowed type; therefore, n = 1/2 is employed in this calculation.²⁵ The optical bandgap (E_g) of the Na₂CaTi₂Ge₃O₁₂ host is determined to be 4.11 eV via fitting the Kubelka–Munk function (Fig. S1, ESI†). This bandgap is relatively narrow among garnets, but still surpasses that of many other hosts of efficient Cr³⁺-substituted phosphors, such as LiInSi₂O₆ (3.45 eV).³³ Upon Cr³⁺-doping, the samples exhibit three strong absorption bands in the ultraviolet, blue, and red light regions, derived from the ⁴A₂ → ⁴T₁(⁴P), ⁴A₂ → ⁴T₁(⁴F) and ⁴A₂ → ⁴T₂(⁴F) transitions of the Cr³⁺ ions, respectively. As the concentration of Cr³⁺-dopants increases, the absorption gradually intensifies due to the increased number of luminescence centers. This further confirms the observation that the three absorption bands originate from Cr³⁺ 3d–3d transitions. More apparently, the photoluminescence excitation (PLE) spectra of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005, 0.01, 0.02, 0.04, 0.06, 0.08, and 0.10) samples (presented in Fig. 2b) display three distinct excitation bands with peaks located at 330, 465, and 670 nm, which should be assigned to the above mentioned three electronic transitions.

Fig. 2 (a) Diffuse reflectance spectra of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0–0.10) samples. (b) Normalized PLE spectra of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10). (c) PL spectra with excitation at 465 nm of Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10). (d) Normalized PL spectra of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10) sample. (e) Normalized excitation and emission spectra of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺. (f) Electron-lattice coupling energy (Sħω) of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10).

Upon 465 nm excitation, the photoluminescence (PL) spectra of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005, 0.01, 0.02, 0.04, 0.06, 0.08, and 0.10) samples were collected, as shown in Fig. 2c. The normalized emission spectra as presented in Fig. 2d exhibit broadband emission covering 700 to 1100 nm with a FWHM of about 120 nm. A slight spectral red-shift (from 779 to 794 nm) can be observed with the increase of Cr³⁺-dopant concentration, which is likely to be caused by reabsorption due to a considerable overlap between the excitation and emission spectra as depicted in Fig. 2e. Moreover, a slight spectral broadening with the FWHM extended from 120 to 127 nm was observed. The spectral broadening should be due to the increase of the electron-lattice coupling strength.^34,35 To verify this, the electron-lattice coupling energy (Sħω) was calculated as shown in Fig. 2f. The electron-lattice coupling energy clearly shows a gradual increase as the Cr³⁺ dopant concentration (x) increases, demonstrating the gradually enhanced electron-lattice coupling effect.

The optimal Cr³⁺ dopant concentration in this garnet is x = 0.06, which has the highest emission intensity (Fig. 3a). The PLQY and AE of this sample were measured under 465 nm excitation (Fig. 3b), yielding values of 75.06% and 34.07%, respectively. Compared to some other Ti⁴⁺-containing phosphor materials (Table 2), the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ phosphor exhibits excellent PLQY and demonstrates relatively long-wavelength NIR emission.

Fig. 3 (a) Normalized emission intensity as a function of Cr³⁺ concentration x. (b) Photoluminescence quantum yield (PLQY) and absorption efficiency (AE) measurement of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺. (c) Tanabe-Sugano diagram for Cr³⁺ in an octahedral crystal field. (d) Emission spectrum of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ sample with single Gaussian band fitting. (e) Decay curve of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ with single exponential fitting. (f) Decay curves of Na₂CaTi_2-xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10).

Table 2 Photoluminescence properties of Cr³⁺-activated NIR Ti⁴⁺-containing phosphors

Compound	λ em (nm)	PLQY (%)	AE (%)	I 373K/I298K (%)	Ref.
Na2CaTi2Ge3O12:Cr^3+	790	75.06	34.07	42.13	This work
Li2Mg3TiO6:Cr^3+	790	72.1	28.1	68.2	30
Ca3MgTiGe3O12:Cr^3+	786	66.5	37	∼50	36
Li2Mg2.99Ti0.99Ga0.02O6:Cr^3+	707	73.1	—	∼70	37
Ca3ZnTiGe3O12:Cr^3+	785	39	29.6	>70	29
LiGaTiO4:Cr^3+	717	70.22	23.2	52.7	38

---

This broadband NIR emission is attributed to the ⁴T₂(⁴F) → ⁴A₂ transition of Cr³⁺ ions in a weak octahedral crystal field. The strength of the crystal field can be approximately estimated from the ratio between the crystal field splitting (D_q) and the Racah parameters (B):^39,40

where E(⁴A₂ → ⁴T₁) and E(⁴A₂ → ⁴T₂) represent the energies of the ⁴A₂ → ⁴T₁(⁴F) and ⁴A₂ → ⁴T₂(⁴F) transitions, respectively, determined from the excitation spectra, and ΔS denotes the Stokes shift. Upon fitting these equations, the values of D_q and B were calculated to be 1492 and 683 cm⁻¹, respectively, resulting in a D_q/B value of 2.18 (Fig. 3c). This D_q/B value is lower than 2.3, confirming that the Cr³⁺ ions are indeed situated in a relatively weak octahedral crystal field environment.

As there is only one kind of octahedral site in the garnet, it is expected that the NIR emission of this material should be derived from only one type of luminescence center. Thus, the emission spectra should be well fitted by a single Gaussian band. However, the fact is that the emission spectrum of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ sample shows a slight deviation from a single Gaussian band (Fig. 3d). To further confirm this deviation, the decay curve of this sample was recorded, which shows slight deviation from a single exponential function as shown in Fig. 3e. In fact, this deviation can be seen in all the decay curves of the Na₂CaTi_2−xGe₃O₁₂:xCr³⁺ (x = 0.005–0.10) samples (Fig. 3f). Nevertheless, these decay curves cannot be fitted by a double exponential function, excluding the existence of a second type of luminescence center. The reason for this deviation should be ascribed to the differentiation of the octahedral site caused by the disordered distribution of Na⁺ and Ca²⁺ ions in the second coordination sphere, which would lead to coordination of Na–Cr–Na, Na–Cr–Ca, and Ca–Cr–Ca. In our previous work, the cationic disorder at the dodecahedral site of the garnet consistently proved advantageous for achieving relatively long-wavelength NIR emission. This material clearly possesses relatively long-wavelength NIR emission (λ_em = 790 nm) compared to many other garnets, such as Y₃In₂Ga₃O₁₂:Cr³⁺ (λ_em,max = 760 nm), Ca₃Sc₂Si₃O₁₂:Cr³⁺ (λ_em,max = 770 nm) and Gd₃Mg_0.5Al_1.5Ga_2.5Ge_0.5O₁₂:Cr³⁺ (λ_em,max = 763 nm),^17,18,21 benefiting from the cationic disorder.^34,41

The lifetime of each sample can be obtained by fitting the decay curves (Fig. S2, ESI†) with the following single exponential function:^42,43

where I_t and I₀ represent the emission intensity at time t and the initial emission intensity, respectively, A is the fitting constant, and t and τ denote the time and lifetime, respectively. The fitted results show that the lifetime gradually decreases from 57.32 to 41.03 μs as the Cr³⁺ concentration increases. This is attributed to the gradually enhanced interactions between Cr³⁺ ions, resulting in energy loss through non-radiative transitions.

3.3. Thermal stability

The temperature-dependent PL spectra of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ sample were acquired under 465 nm excitation covering a temperature range of 298 to 473 K as depicted in Fig. 4a and Fig. S3 (ESI†). As the temperature increases, the emission intensity gradually decreases. At 373 K, the sample retains 42.13% of its initial intensity (at 298 K), as shown in Fig. 4b, suggesting a relatively poor thermal stability when compared with some other Ti⁴⁺-containing phosphors as listed in Table 2. Nevertheless, the almost linear decrease in the temperature range of 298–398 K makes it an excellent material to be applied in temperature sensing with a sensitivity of 0.67% K⁻¹ (Fig. 4c).

Fig. 4 (a) Emission spectra of Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ excited at 465 nm in the temperature range of 298–473 K. (b) Normalized integral emission intensity as a function of temperature. (c) Linearly fitting the relationship between emission intensity and temperature. (d) The fitted activation energy for thermal quenching. (e) Normalized PL spectra at different temperatures. (f) The fitted Huang–Rhys factor (S) and phonon energy (hv).

The thermal stability of the phosphor is generally determined by two mechanisms, namely, the cross-over process and thermal ionization. The cross-over process occurs when the excited electrons pass through the intersection of the ground state energy levels and excited state energy (Fig. S4, ESI†). The energy barrier is the activation energy (ΔE_a), the energy difference between the lowest excited state and the crossing point, which can be calculated by fitting the Arrhenius equation:⁴⁴

where I_T and I₀ denote the emission intensities at temperature T and 298 K, respectively, and A is a host-dependent constant. Fitting this equation (Fig. 4d) yielded an activation energy (ΔE_a) of 0.33 eV. This value is relatively low compared to some thermally stable materials, such as ScBO₃:Cr³⁺ (ΔE_a = 0.36 eV) and GdAl₃(BO₃)₄:Cr³⁺ (ΔE_a = 0.41 eV).^22,45 However, the activation energy for the thermal quenching (ΔE_a) of phosphor materials is not an unchangeable parameter, and it can be enhanced through the optimization of the synthesis conditions, as demonstrated in the case of Ca₃Sc₂Si₃O₁₂:Cr³⁺ (ΔE_a = 0.220 eV → 0.336 eV).¹⁸

The normalized PL spectra (Fig. 4e) reveal a red-shift of approximately 16 nm for the emission peak wavelength (791 → 807 nm), accompanied by a peak width expansion from 126 nm to 139 nm. The red-shift of the emission spectra can possibly be attributed to the lattice expansion with increasing temperature, which leads to a consequent weakening of the crystal field.⁴⁶ The broadening of the temperature-dependent PL spectra reflects enhanced electron-lattice interactions, which increase the vibrational amplitude of excited electrons with the assistance of the electron–phonon coupling (EPC) effect. The degree of the EPC effect can be represented by the Huang–Rhys factor (S) via fitting the following equation:^47,48

where hν represents the phonon energy, k is the Boltzmann constant and T is the temperature. Fitting this equation (shown in Fig. 4f) yielded an ultralow Huang–Rhys factor (S) of 1.68 and a phonon energy (hν) of 77 meV. These results indicate that the EPC effect in Na₂CaTi₂Ge₃O₁₂:Cr³⁺ phosphors is significantly weaker than that in some other NIR phosphors, such as KAlP₂O₇:Cr³⁺ (S = 2.58), Ca₃MgHfGe₃O₁₂:Cr³⁺ (S = 1.86), and GaTaO₄:Cr³⁺ (S = 3.8).^26,49,50

Considering the relatively weak EPC effect in this material, the influence of high-energy phonons on the excited electrons is weak, thereby minimizing the possibility of thermal quenching via a cross-over process. Consequently, the relatively poor thermal stability of this material can be primarily attributed to thermally induced ionization. This mechanism depends on the energy gap between the lowest excited state and the bottom of the conduction band, which is significantly determined by the band gap of the host material. Considering that the optical band gap of Na₂CaTi₂Ge₃O₁₂ is relatively narrow, it is likely that thermal ionization will happen at elevated temperatures.

3.4. Application of a NIR pc-LED device

To assess the practical performance of the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ phosphor, the optimized sample was mixed with UV photosensitive resin in a 1 : 1 mass ratio and then coated on a 455 nm blue InGaN chip (inset of Fig. 5a) to prepare a NIR pc-LED device. Fig. 5a shows the electroluminescence (EL) spectra of the manufactured devices at different driving currents. Fig. 5b and Table S3 (ESI†) show the NIR power and the photoelectric conversion efficiency corresponding to each driving current. The NIR output power exhibits an increase from 5.33 to 49.27 mW as the current is gradually increased from 25 to 450 mA, while the NIR photoelectric conversion efficiency decreases from 7.43% to 3.4%. Notably, at a driving current of 100 mA, the NIR output and NIR photoelectric conversion efficiency reached 18.24 mW and 6.49%, respectively, with a maximum emission peak at 790 nm. These output parameters suggest great potential of this device for spectroscopic applications.

Fig. 5 (a) Electroluminescence (EL) spectra, and (b) NIR output power and conversion efficiency of the NIR pc-LED under various driving currents (25–450 mA). (c) Schematic diagram of biological tissue imaging and non-destructive examination. (d) Natural and NIR light images of a hand. (e) Natural and NIR light images of a fractured cable. (f) Contour plot of NIR intensity in the cable fracture zone. (g) Longitudinal sectional intensity plot at the dotted line.

To evaluate the practical application of this device, a scheme of non-invasive and non-destructive NIR imaging was constructed, as demonstrated in Fig. 5c, via capturing photographs under NIR light generated by the fabricated NIR pc-LED device. Fig. 5d demonstrates the photographs of a hand captured under natural light and NIR light. Under the exposure of NIR light, the blood vessels in the palm can be clearly identified, and the subtle skeletal contours were visible, demonstrating the potential of the device for non-invasive biological imaging applications.

This NIR pc-LED device was also employed for the detection of cable breakpoints. Fig. 5e demonstrates a broken cable with an intact protective layer under the exposure of visible and NIR light. The protective layer of the cable exhibits high transmittance under the NIR light, and the captured NIR image effectively revealed the cable breakpoint. Extracting the intensity distribution from the NIR image as grayscale values and plotting a pseudo-color map generates a longitudinal sectional intensity profile of the cable breakpoint (Fig. 5f and g), enabling better observation of the damage point. These applications highlight the immense potential of this work in biological tissue imaging and industrial non-destructive testing.

4. Conclusion

In summary, we successfully designed and synthesized efficient Na₂CaTi₂Ge₃O₁₂:Cr³⁺ garnet phosphors. The phosphors exhibit a broad NIR emission ranging from 700 to 1100 nm, with a peak centered at 790 nm and a FWHM of 120 nm under 465 nm excitation. The optimized PLQY and AE reach 75.06% and 34.07%, respectively, for the sample with x = 0.06, demonstrating the material's excellent efficiency. This excellent efficiency possibly benefits from the suppression of defect formation and Cr⁴⁺via charge self-balance. Although the thermal stability of this material is relatively poor, an unexpected nearly linear decrease of the emission intensity as a function of temperature up to 400 K demonstrates its excellent temperature sensing properties. Finally, a NIR pc-LED device was constructed using the Na₂CaTi_1.94Ge₃O₁₂:0.06Cr³⁺ phosphor. The device achieves a NIR output power of 18.24 mW and photoelectric conversion efficiency of 6.49% at 100 mA. The device's practical applications in biological tissue imaging and industrial non-destructive testing have been successfully demonstrated.

Data availability

Data underlying the results presented in this paper can be obtained from the authors upon reasonable request.

Conflicts of interest

The authors declare no competing financial interest.

Acknowledgements

The authors would like to thank the National Natural Science Foundation of China (52372139) and the Guangzhou Basic and Applied Basic Research Project (2025A04J5106).
