Assessing the predictability of anharmonic vibrational modes at the example of hydroxyl groups – ad hoc construction of localised modes and the influence of structural solute–solvent motifs

Abstract

The performance of the grid-based Numerov procedure for the prediction of fundamental as well as the first vibrational overtone has been systematically probed for harmonic and anharmonic model systems. In addition to monitor the prediction with respect to the spacing of the potential grid the influence of higher order approximations to the second derivative (i.e. stencils) in Schrödingers equation is evaluated. The latter enable a significant increase of the grid-spacing to achieve results of similar accuracy obtained with smaller stencil sizes. Application to the hydroxyl vibrational mode of methanol, phenol and the natural product thymol in vacuum and carbon tetrachloride predicted wavenumbers within less than 1% of experiment. Due to the highly localised character of the OH-vibration the ad hoc construction of the associated normal mode yields results of similar accuracy than those obtained using the analytical normal modes, effectively eliminating the requirement of an analytical normal mode evaluation of the entire system. This property was shown to be of particular advantage when considering explicit solute–solvent contacts, which have been demonstrated to be superior compared to an implicit representation of solvent effects. The combination of the observed findings (i.e. enlarged grid-spacing due to the application of higher order stencils, construction of localised normal modes) is envisaged to be of particular benefit when investigating localised modes in large systems, such as OH or NH groups in large (bio)macromolecules or solid-state surfaces.

---

1 Introduction

Due to its straightforward applicability and high throughput capacity vibrational spectroscopy is among the most widely used methods for the classification of small molecules in science and technology. Since the mode assignment in complex spectra can be cumbersome computational approaches to aid in the classification are of particular interest. Especially in view of the continuously increasing computational capacities a broad variety of approaches are currently available.

The simplest and most widely used method for the prediction of vibrational modes is the harmonic approximation, in the majority of cases employed in the context of density functional theory. Here the potential close to the energy minimum conformation is approximated by a parabola, i.e. the potential of the harmonic oscillator model. This simple approach works surprisingly well for the calculation of fundamental vibrations of selected functional groups, but may lead to a significant deviation from experimental data for other chemical systems. Also, because of the neglect of anharmonicity and mode–mode coupling, it fails dramatically in the prediction of higher order excitations (overtones) and combination bands, observed in the NIR region. In cases these two effects compensate acceptable results are obtained albeit for the wrong reasons.

Various methods have been developed to take mode anharmonicity and coupling into account. The most prominent ones being the vibrational self consistent field (VSCF) method and the vibrational second order perturbative (VPT2) ansatz.¹ The VPT2 ansatz is based on the calculation of higher order derivatives (third and upwards) of the system's energy, as shown by Barone.² While it is only applicable for potentials with high harmonicity, the method gives a quite accurate, albeit computational costly prediction of higher excitation states for these systems.^1,2 The VSCF method^3–7 on the other hand tries to optimize a linear combination of vibrational wave functions (e.g. analytical solutions of harmonic oscillator wave functions) by variation of the linear combination's coefficients. Since in this approach the vibrational wave function is based on a product approach similar as the electronic wave function used in the Hartree Fock (HF) electronic structure theory, correlated vibrational methods such as perturbation theory-VSCF (VSCF-PT)^8,9 and configuration interaction VSCF (VSCF-CI)^10–12 have been developed.

Another approach currently gaining popularity is numerically solving the time-independent Schrödinger equation by grid-based approaches, such as Numerov's method^13–16 or discrete variable representation (DVR).^17–19 The DVR method is often the method of choice, since it employs an infinite order in the formulation of the finite difference approximation employing a sinc() basis. However, the associated matrix formulation requires a fully occupied dense matrix,²⁰ whereas in the Numerov case only banded-matrices occur, the respective band width being equal to the finite size of the stencil. This feature enables the application of sparse matrix routines greatly reducing computing time and memory requirements.²¹ While for modern computational architectures the exploitation of matrix sparsity is of no noticeable benefit in one-dimensional applications, it becomes of particular advantage in applications with more degrees of freedom (see ref. 21 and 20 for 2D- and 3D-examples). Since these grid-based methods can be applied to any arbitrary potential curve, the influence of various forms of anharmonicity can be easily taken into account by application of a suitable coordinate scan of a given molecule. The reduced masses in the kinetic energy operator of Schrödinger's eqn (1) also enable an explicit consideration of quantum chemical effects, such as the magnitude of tunnelling outside of the classically accessible region. Especially if only a localised signature mode such as the vibration of a hydroxyl group investigated in this work is of interest, grid-based methods provide a highly efficient ansatz yielding also excellent predictions of the respective first overtone. This vibrational mode has been chosen, because of its high infrared and near infrared activity as well as its local character resulting from the weak coupling with other vibrations.

For this reason this work aims at the determination of the applicability of a matrix implementation of Numerov's method for the prediction of OH vibrational modes. First, results obtained for model potentials differing in their degree of anharmonicity and grid density are compared to the respective analytical solution. Furthermore, IR measurements of the OH-stretch vibration of phenol and the natural product thymol in carbon tetrachloride have been performed and compared to the theoretically predicted frequencies and oscillator strengths. Special focus was given to reduce the number of computations thus providing a general and efficient work flow, e.g. without the requirement of a harmonic frequency analysis. Finally, the sensitivity of the method to the influence of solvent effects is investigated at the example of carbon tetrachloride, comparing an implicit description of the solvation with the costly explicit inclusion of solvent molecules.

2 Methods

2.1 The Numerov method

To predict the vibrational energy eigenstates an ansatz for solving the time independent Schrödinger eqn (1) for a given finite-spaced potential, namely the Numerov method,^13,14,22 has been employedwhere Ψ denotes the wave function along the respective normal coordinate q, μ and ħ are the reduced mass of the given degree of freedom (dof) and the reduced Planck constant, respectively. The potential V(q) has to be supplied on an equispaced grid, E denotes the associated energy eigenvalue.

Numerov's method is based on the representation of the given function Ψ(q) as Taylor polynomial at the points q (index 0), q + Δq (index +1) and q − Δq (index −1).

Summation of Ψ₊₁ and Ψ₋₁ leads to the cancellation of all odd and the doubling of all even entries. Rearrangement yields an approximate expression for the second derivative of Ψ.

Due to the nature of second order ordinary differential equations without linear terms, the second derivative of a function Ψ(q) is equal to a function value f(q) times the function Ψ(q) itself, which is used to define the fourth (and higher order) derivatives.

In case of the time independent Schrödinger equation the function f(q) is described in eqn (1). With this expression the approximation of its second derivative can be written as

By applying Dirichlet boundary conditions, the terms and can be simplified to the matrix terms [Doublestruck A]Ψ(q) and [Doublestruck B]Ψ(q) (see eqn (S1), ESI†).^13,14,21

Using the matrices [Doublestruck A] and [Doublestruck B] as well as the diagonal matrix [Doublestruck V], containing V(q) as elements, eqn (5) can be written as

which is in the same form as the time independent Schrödinger equation [Doublestruck H]Ψ = EΨ, with

Eigendecomposition of [Doublestruck H] yields the diagonal eigenvalue-matrix [Doublestruck E], the associated eigenvectors are collected in Ψ. Similar methods have also been employed in the description of the electronic structure of atoms and small molecular systems.^23–30

The method can be extended to higher order numerical derivatives by defining the Taylor series for higher degrees (e.g. [Doublestruck A] and [Doublestruck B] matrices with seven diagonal entries would require a Taylor series of the eighth degree). A generalisation to higher orders of Numerov's method is presented elsewhere.^15,21

To predict the IR intensities the transition moment integral μ_mn(8), consisting of the respective wave functions Ψ of the two involved states m and n, as well as the transition moment operator [small mu, Greek, circumflex](q), has to be calculated.

In case of infrared spectroscopy [small mu, Greek, circumflex](q) equals the dipole moment μ as a function of the molecule's normal coordinates q, making infrared measurements especially sensitive on polar functional groups like OH or CO. A slightly more common representation of the intensities in vibrational spectroscopy is the use of the oscillator strength f_mnwhere m_e denotes the electron mass, e the elementary charge and ν_mn the transition energy between the two states m and n.^31,32 Typically, the oscillator strengths are normalised to that of the fundamental mode.

2.2 Experimental setup

For the measurements 10% (m/v) solutions of the analytes phenol (university supply) and thymol (Sigma, 99.5% purity) have been prepared in carbon tetrachloride. For the investigation of structural motifs an additional measurement was taken with the same analytes in a 10% (m/v) n-hexane solution. The solutions have been transferred into quartz cuvettes with a pass length of 2 mm and sealed to avoid evaporation of the solvents. The dilutions have been measured using the Fourier-transform infrared spectrophotometer Spectrum 400 FT-IR/FT-NIR (PerkinElmer, Massachusetts, USA) in transmission mode. The spectral range was set from 2000 cm⁻¹ to 10 000 cm⁻¹ with a spectral resolution of ±2 cm⁻¹. All measurements have been carried out at room temperature with 16 scans per sample to amplify the signal to noise ratio. Additionally experimental data of methanol have been taken from the work of Futami et al.³¹ Since only position and intensity of specific known peaks of high intensity were needed for this work, the interpretation of the resulting, baseline corrected spectra could be carried out without the need of advanced statistical methods. Spectrum IMAGE R1.8.0.0410 was used for recording spectra.

As a measure for the anharmonic contribution of the obtained potentials the anharmonicity factor χ is commonly used

While in case of harmonic systems both terms cancel, leading to χ = 0, values different from zero characterise the degree of anharmonicity. This measure can be applied both to experimental measurements as well as theoretical predictions.

2.3 Model systems

In addition to the assessment of its applicability to real chemical systems the accuracy of Numerov's method was tested against three analytically solvable systems with different degrees of anharmonicity, namely a harmonic and two Morse models M1 and M2.

V_Morse = D(1 − e^{−α(r−r₀)})² (12)

The three potentials share the same curvature at the equilibrium position, with M1 showing the highest degree of anharmonicity. The harmonic force constant k_harm of 4621.4 kJ (mol Ų)⁻¹ was chosen, since it corresponds to that of a typical O–H bond.^33,34 The α parameter of M1 has been chosen from the work of Arai et al.³⁴ and was set to 2.511 Å⁻¹. This results in a well depth of D = 366.48 kJ mol⁻¹. The second, less anharmonic, Morse potential M2 was constructed by doubling the well depth D to 724.96 kJ mol⁻¹ while maintaining the curvature in the equilibrium position. This results in an α value of 1.776 Å⁻¹. The equilibrium distance r₀ of all potentials has been set to zero, thus r formally represents the elongation and contraction of the bond from its minimum position. The reduced mass μ_OH has been determined from the values of ¹⁶O and ¹H taken from the National Institute of Standards and Technology database.³⁵ The potentials of the three different model systems along with the respective wavefunctions of the five lowest eigenvalues are depicted in Fig. 1.

Fig. 1 The three used potentials (solid) for the evaluation of grid size effects with their corresponding first five eigenstates (dashed). The figure shows the connection of a decreasing difference between energy eigenstates and increasing anharmonicity. While in the harmonic (violet) case all eigenstates are equidistant they move closer together with increasing anharmonicity (blue to green).

2.4 Quantum chemical calculations

To obtain the potentials needed to apply Numerov's method, DFT calculations on generalized gradient approach (GGA) level, using the BP86^36,37 functional, and hybrid level, using the B3LYP³⁸ functional with the 6-311++G(3df,3pd) basis set,^39–42 have been carried out in vacuum and in carbon tetrachloride using the density based polarized continuum model for implicit solvents SMD.⁴³

Following an initial energy minimisation with tight convergence settings for energy and gradient, harmonic frequencies have been determined at the minimum geometry. For the energy scan a variation along the respective degree of freedom (dof) in discrete steps of 0.01 Å has been performed and the molecule's energy and dipole moment were evaluated at every point.

For the OH-stretch vibration three different definitions of the dof have been chosen. First, only the OH-distance r_OH was varied by only changing the coordinate of the hydrogen atom serving as a simple approximation to the vibration. Secondly, the appropriate normal coordinate scan of the hydroxyl vibrational mode has been employed. The atom displacement was carried out alongside the OH-stretch normal coordinate q, allowing for a similar atom displacement to experimental observations. A disadvantage of this approach is the requirement of a harmonic frequency analysis of the entire system, which may become a demanding and time-consuming prerequisite in case of larger molecules.

For this reason a constructed normal coordinate q̄ has been considered as third option. The associated normal mode components of the oxygen and hydrogen atoms q̄_O and q̄_H have been determined according to their respective masses m_O and m_Hvia

with r_OH being the respective distance vector at the minimum geometry. The components of all other contributions have been set to zero, followed by the normalisation of the constructed mode. As a consequence of this simplification a constant value for the reduced mass of 1.067 g mol⁻¹ is obtained.

This approach can be justified by the strongly local character of the OH vibration. The absolute values of the associated normal coordinates considering only the oxygen and hydrogen atoms (B3LYP level, vacuum) amount to 0.9999 in case of methanol, phenol and thymol, respectively, implying the contribution of all other atoms to the normal coordinate is less than 0.01%. The associated reduced masses of the three systems of 1.067 g mol⁻¹, 1.066 g mol⁻¹ and 1.066 g mol⁻¹ also demonstrate excellent agreement with the estimated mass of the constructed mode, the respective deviations being on the order of mg mol⁻¹. This approach has the advantage that no frequency analysis is required to formulate the direction of the potential energy scan, while at the same time the representation of the normal mode is more accurate compared to the simple variation of the H position along the hydroxyl bond vector.

Afterwards, a Numerov calculation of the resulting potential curves is carried out to obtain the energy eigenstates and the transition moment integrals^44,45 are calculated for the prediction of relative intensities.

All quantum chemical molecule calculations were performed using the Gaussian09 package,⁴⁶ while the Numerov calculations were performed on in house code, implemented in GNU octave⁴⁷ and the C programming language, using the GNU Scientific library.⁴⁸ For better utilisation of multi-core systems the GNU Parallel⁴⁹ load balancer was used.

3 Results and discussion

3.1 Analytically solvable model potentials

In case of the analytically solvable systems the accuracy of eigenvalues predicted by Numerov's method depending on the density of data points is evaluated. Each potential has been prepared in the range of ±2.5 Å around the energy minimum, the distance of h between the individual data points is given as

Besides the influence of the grid density also the impact of higher order derivatives of the matrix Numerov method are investigated.^15,21 To accomplish this all calculations were performed with matrix stencils inheriting three, five, seven and nine points per row, corresponding to an error order of [scr O, script letter O](h⁴) to [scr O, script letter O](h⁸) in the [Doublestruck A]-matrix, as well as a second, fourth, sixth and eight order derivative in the [Doublestruck B]-matrix.

The absolute difference between the Numerov results and the analytical solutions for selected eigenstates as a function of the grid density for the used harmonic oscillator is depicted in Fig. 2 for different Numerov matrix stencil sizes.

Fig. 2 Energy difference between Numerov calculations and the corresponding analytical solution of the quantum harmonic oscillator as function of the grid density for different stencil sizes and selected energy levels E_n (n = 0, 1, 5, 10). The grid density is represented by the number of data points within a distance of ±2.5 Å around the energy minimum. The dotted line marks the implementations precision limit. For the calculation a force constant of k = 4621.4 kJ (mol Ų)⁻¹ was used.

For a reliable prediction of infrared spectra (MIR/NIR) at least an accuracy of 10⁻² kJ mol⁻¹ (0.8 cm⁻¹) for the first eigenstates is required. Fig. 2 shows that even the simplest implementations of the method are sufficiently accurate for this task. Using larger stencils (seven point onwards) reach this limit even for the 10th eigenstates with less than 80 points per Ångström. For the ground state, the calculation with a nine point stencil even reaches the precision limit of the implementation at around 10⁻¹¹ kJ mol⁻¹. This level of accuracy even meets the required precision to compare to experimental data obtained via laser spectroscopy reporting uncertainties on the order of 10⁻⁴ cm⁻¹.⁵⁰

Since the computational overhead of larger stencils is effectively negligible, the largest available stencil should be employed. This has the advantage that coarser grids can be employed, reducing the number of computations along the vibrational mode. To achieve a precision of 10⁻² kJ mol⁻¹ for the first excited state E₁ the three-point stencil requires a minimum grid spacing of approximately 0.030 Å, while in case of the nine-point stencil a spacing of 0.056 Å is sufficient, effectively reducing the number of grid points by a factor of two.

In case of the Morse systems M1 and M2 very similar characteristics have been observed, the respective plots are provided in the ESI† (Fig. S1 and S2). It can be concluded that the performance of the higher order stencils is not reduced due to the anharmonicity in the potentials.

3.2 Prediction of hydroxyl vibrational states

Based on the findings of the analytically solvable potentials the methodology is applied to the OH vibrational mode of the molecules methanol, phenol and thymol. Since it shows a strong local character and high infrared activity in the mid- and near-infrared region, it is possible to study this mode independently from the other vibrations in the molecule. Due to the comparably large wavenumbers of the OH vibration it can be easily identified even in the presence of C–H and N–H vibrations of the solute or the solvent.

Tables 1 and 2 list the experimental and calculated wavenumbers as well as the respective infrared intensities for the normal mode and OH-distance scans, respectively. Both the B3LYP and BP86 functionals as well as the treatment in vacuum and implicit solvent are considered.

Table 1 Predicted wavenumbers ν in cm⁻¹ and relative intensities I obtained via a normal coordinate OH scan of the three systems methanol, phenol and thymol in comparison to experiment

		BP86 vacuum		B3LYP vacuum		Exp. gas	BP86 SMD		B3LYP SMD		Exp. CCl4
		ν	I	ν	I	ν	ν	I	ν	I	ν	I
a This work.
Methanol	ν 01	3550.5	1.000	3676.7	1.000	3681^31	3532.2	1.000	3657.3	1.000	3645^31	1.00^31
	ν 02	6934.0	0.220	7189.8	0.154	7196^31	6898.3	0.130	7151.1	0.097	7121^31	0.06^31
	χ	−83.5	—	−81.8	—	−83	−83.1	—	−81.8	—	−85	—
Phenol	ν 01	3527.8	1.000	3664.7	1.000	3654, 3657^54,55	3502.2	1.000	3637.5	1.000	3612,^a 3611^54,56	1.00
	ν 02	6889.3	0.132	7167.5	0.090	7141^54	6838.6	0.080	7112.4	0.058	7056,^a 7053, 7052^54,56	0.05
	χ	−83.2	—	−81.0	—	84	−82.9	—	−81.3	—	−84	—
Thymol	ν 01	3528.0	1.000	3667.0	1.000	—	3503.4	1.000	3640.6	1.000	3616^a	1.00
	ν 02	6889.1	0.148	7171.5	0.097	—	6840.4	0.086	7118.0	0.061	7060^a	0.04
	χ	−83.4	—	−81.2	—	—	−83.2	—	−81.6	—	−86	—

---

Table 2 Predicted wavenumbers ν in cm⁻¹ and relative intensities I obtained via an OH distance scan of the three systems methanol, phenol and thymol in comparison to experiment

		BP86 vacuum		B3LYP vacuum		Exp. gas	BP86 SMD		B3LYP SMD		Exp. CCl4
		ν	I	ν	I	ν	ν	I	ν	I	ν	I
a This work.
Methanol	ν 01	3552.4	1.000	3678.7	1.000	3681^31	3533.7	1.000	3658.6	1.000	3645^31	1.00^31
	ν 02	6938.7	0.247	7194.4	0.166	7196^31	6902.1	0.133	7154.3	0.097	7121^31	0.06^31
	χ	−83.1	—	−81.5	—	−83	−82.7	—	−81.5	—	−85	—
Phenol	ν 01	3531.7	1.000	3668.5	1.000	3654, 3657^54,55	3505.2	1.000	3640.3	1.000	3612^a, 3611^54,56	1.00
	ν 02	6898.4	0.140	7176.1	0.092	7141^54	6846.4	0.078	7119.4	0.056	7056^a, 7053, 7052^54,56	0.05
	χ	−82.5	—	−83.0	—	84	−82.0	—	−80.6	—	−84	—
Thymol	ν 01	3532.3	1.000	3671.0	1.000	—	3507.5	1.000	3644.5	1.000	3616^a	1.00
	ν 02	6898.8	0.161	7180.7	0.100	—	6850.1	0.087	7127.2	0.060	7060^a	0.04
	χ	−82.9	—	−80.7	—	—	−82.5	—	−80.9	—	−86	—

---

Comparison of the two used DFT functionals shows, that for all three investigated systems, the B3LYP functional's results are more consistent with the measured data compared to the BP86 case. The deviation from the experimentally observed wavenumber varies between 0.02% for the first overtone of methanol in the gas phase and 0.95% for the first overtone of the thymol OH vibration in CCl₄. On the other hand the accuracy of the BP86 functional varies between 3.0% for the first phenol overtone in CCl₄ and 3.6% for the first methanol overtone in vacuum. The same applies to the prediction of the intensity ratios between the fundamental vibration and its first overtone. In all three investigated systems the B3LYP functional predicts the correct order of magnitude, but slightly overestimates the intensity of the first overtone. The BP86 functional on the other hand overestimates the overtone intensity by a factor of two in the methanol and thymol case. Interestingly the anharmonicity factors χ resulting from BP86 show a slightly better agreement with experiment than observed in the B3LYP case, which is a result of a compensation of errors between the fundamental and overtone. However, the deviation in χ is typically on the order of a few wave numbers only.

Another important finding is the fact that the BP86 functional required a notably higher number of SCF cycles to converge for configurations notably displaced from the minimum structure. Thus, despite its simpler formulation no advantage in computation time could be observed when using this functional and the application of the hybrid B3LYP approach proved to be preferred. For this reason only the B3LYP level of theory was applied in all investigations using the constructed normal modes q̄. Since the OH-stretch modes in the investigated systems show only contributions of the associated bond partners with virtually no motion of the other atoms, the constructed modes provide results of similar accuracy (see Table 3). To highlight the deviation between the q and q̄, the associated angles and the difference in reduced mass has been listed in the ESI,† (cf. Table S1). It can be seen that the constructed mode differs by approximately 1° from the analytical modes, with a decrease in angle upon increase of the system size. The deviation between the reduced masses are on the order of mg mol⁻¹. In this case the lowest deviation is observed in the methanol case, which can be explained by the smaller mass of the methyl group when compared to the aromatic systems. The deviation of the predicted wave numbers to those using the analytical wavenumbers is on the order of 1 cm⁻¹ for the fundamental modes and 2 cm⁻¹ in case of the respective overtones.

Table 3 Predicted wavenumbers ν in cm⁻¹ and relative intensities I obtained via a constructed normal mode OH scan of the three systems methanol, phenol and thymol in comparison to experiment. Based on the result of Tables 1 and 2 only the B3LYP level was employed in this case

		B3LYP vacuum		Exp. gas	B3LYP SMD		Exp. CCl4
		ν	I	ν	ν	I	ν	I
a This work.
Methanol	ν 01	3675.8	1.000	3681^31	3656.4	1.000	3645^31	1.00^31
	ν 02	7187.7	0.155	7196^31	7148.9	0.097	7121^31	0.06^31
	χ	−82.0	—	−83	−81.9	—	−85	—
Phenol	ν 01	3663.8	1.000	3654, 3657^54,55	3636.6	1.000	3612,^a 3611^54,56	1.00
	ν 02	7165.3	0.093	7141^54	7110.3	0.059	7056,^a 7053, 7052^54,56	0.05
	χ	−81.1	—	−84	−81.4	—	−84	—
Thymol	ν 01	3666.0	1.000	—	3639.7	1.000	3616^a	1.00
	ν 02	7169.4	0.100	—	7116.0	0.062	7060^a	0.04
	χ	−81.3	—	—	−81.7	—	−86	—

---

Overall the B3LYP level potential energy scans based on normal coordinates q and q̄ yield slightly more accurate results except in the case of methanol in vacuum. The deviation with respect to the experiment values being approximately 0.2% in the gas phase and 0.8% in CCl₄. The larger deviation in the latter case can be attributed to the implicit treatment of solvation effects in the SMD approach, which does not take a possible formation of structural motifs between the solute and the solvent into account. A comparison of the potential energy scans for the three systems, two functionals and the three different definition of the scanning coordinate in vacuum is depicted in Fig. S3 (ESI†).

3.3 Investigation of solvent effects – implicit solvation versus explicit structural motifs

Despite its low permittivity of 2.228 carbon tetrachloride may act as both hydrogen bond acceptor as well as halogen bond donor. In order to estimate the magnitude of the C–Cl⋯O and O–H⋯Cl interactions an energy minimisation of the phenol⋯CCl₄ complex has been carried out. The resulting interaction energies at B3LYP/vacuum level amount to −3.4 kJ mol⁻¹ and −4.8 kJ mol⁻¹ in case of hydrogen and halogen bonding. If both structural motifs are present (i.e. phenol⋯(CCl₄)₂) a total energy of binding of −10 kJ mol⁻¹ has been obtained after energy minimisation. These values confirm the possibility of explicit interaction between solute and solvent, which in turn can be expected to have a direct influence on the hydroxyl bond strength.

In order to assess the impact of these structural motifs the model system used for the Numerov approach has been extended to include two explicitly treated solvent molecules. In addition to the treatment in vacuum the entire complex has also been treated subject to implicit solvation in CCl₄, the respective model systems are labeled explicit CCl₄in vacuum and explicit CCl₄ in implicit solvent. Fig. 4 depicts the respective minimum structure for thymol obtained at B3LYP/6-311++G(3df,3pd)/vacuum level. The formation of a hydrogen bond-like motif and the halogen bond are clearly visible. Despite the substantially increased computational effort of the complex systems (each CCl₄ molecule contributes 74 electrons to the DFT calculation) a normal mode analysis at the minimum geometry has been carried out followed by a potential energy scan along the OH mode using a tight resolution of 0.01 Å for methanol, phenol and thymol, respectively.

In order to support the results obtained from the Numerov analysis an anharmonic frequency calculation at VPT2 level has been performed as well using two different strategies. First, only the OH-mode is included in the anharmonic treatment while in the second calculation all modes have been considered. Due to the dramatic increase in computational demand the latter was only possible in the methanol case. The comparison of wave numbers resulting from the two VPT2 settings yield differences in wavenumbers of just a few cm⁻¹, thus confirming the highly local character of the hydroxyl vibration in the three molecules.

The comparison of all predicted wave numbers for the fundamental and first overtone are listed in Table 4 including experimental data where available. In each case a decrease of the wave numbers from vacuum to implicit solvation to the explicit CCl₄ model in vacuum can be observed, demonstrating that despite the increased computational effort the explicit consideration of solute–solvent contacts results in an improvement over an implicit treatment of solvation effects. In case of the harmonic and Numerov approaches a further extension of the model to explicit solvent molecules plus implicit solvation yields similar results as to treating just the solute in implicit solvation. Thus, the best predictions of the Numerov approach are obtained when using the explicit CCl₄ model, the resulting deviations from experiment amounting to 5, 20 and 18 cm⁻¹ in case of the fundamental bands and 10, 39 and 40 cm⁻¹ for the first overtone of methanol, phenol and thymol, respectively. Thus, the deviation from experimental data is on the order of 0.5% or less which can be attributed to the approximations inherent to density functional theory.

Table 4 Predicted wavenumbers in cm⁻¹ under different consideration of solvent effects obtained via a normal mode OH scan at B3LYP level of theory (h_0m harmonic; a_0m* anharmonic – only OH mode; a_0m anharmonic – entire system; n_0m Numerov)

		Vacuum		Carbon tetrachloride
		Theoretical	Experimental	Implicit solvent	Explicit CCl4	Explicit CCl4 + implicit	Experimental
a This work.
Methanol	h01	3846	3681^31	3825	3823	3830	3645^31
	a01*	3651		3641	3601	3592
	a01	3650		3639	—	—
	n01	3677		3657	3650	3657
	a02*	7122	7196^31	7109	7025	7002	7121^31
	a02	7120		7105	—	—
	n02	7190		7151	7131	7147
Phenol	h01	3832	3654, 3657^54,55	3803	3803	3809	3612,^a 3611^54,56
	a01*	3629		3636	—	—
	a01	3633		3643	—	—
	n01	3665		3638	3632	3638
	a02*	7079	7141^54	7107	—	—	7056,^a 7053, 7052^54,56
	a02	7088		7120	—	—
	n02	7168		7112	7095	7111
Thymol	h01	3834	—	3808	3808	3810	3616^a
	a01*	3642		3631	—	—
	a01	—		—	—	—
	n01	3667		3641	3634	3640
	a02*	7110	—	7099	—	—	7060^a
	a02	—		—	—	—
	n02	7172		7118	7100	7116

---

Using the VPT2 approach wave numbers of similar accuracy are predicted, however, the best agreement with experiment is obtained in case of implicit solvation without consideration of explicit solute–solvent contacts. The influence of the latter could only be tested for the smallest system due to the dramatic increase in computational demand of the VPT2 approach upon inclusion of two CCl₄ molecules. A significant decrease in the wavenumbers yielding a deviation of more than 1.0% is obtained, that is further increased by combining explicit solvent molecule with implicit solvation. The reason for this deviation in the methods can be explained by the mechanics of the different approaches. While the potential energy scan required for the Numerov approach has to include regions of high potential, the VPT2 method employs curvature information close to the minimum structure to construct the potential energy curve. This is also the reason why the VPT2 method requires a significantly higher computational effort even when restricted to just a single active normal mode.

To provide an experimental confirmation of the hypothesis of structural motifs in CCl₄ measurements in a solvent unable to form explicit interactions with the solute, should yield a notable shift in frequency. Thus, additional measurements of phenol and thymol in n-hexane have been performed, since its permittivity of ε(C₆H₁₄ = 1.882) is close to that of carbon tetrachloride (ε(CCl₄) = 2.228). Although an overlap of n-hexane bend- and stretch vibrations with those of the analyte, especially thymol, can be observed, the OH excitation energies are well isolated in both, the MIR and NIR regions, thus enabling an investigation of this mode despite the presence of the CH signals of the solute.

The OH-stretch peaks of the corresponding spectra are shown in Fig. 3. A decrease of the experimentally determined frequency of 8 and 12 cm⁻¹ for the fundamental and 16 to 20 cm⁻¹ for the overtone have been obtained for phenol and thymol. These changes in wave number agree well with the predicted decrease of 6 to 7 cm⁻¹ for the fundamental and 17 to 18 cm⁻¹ in case of the first overtone when changing from implicit solvation to the explicit solvation model shown in Table 4.

Fig. 3 Measured MIR (left) and NIR (right) spectra of the OH vibration of phenol (top) and thymol (bottom).

Fig. 4 Thymol in vacuum interacting with two molecules of carbon tetrachloride to estimate the influence of structural motifs between solute and solvent.

3.4 Simplified Morse model

Since analytic solutions of Schrödinger's equation for the Morse potential are available, a simple yet effective strategy to account for anharmonicity is to fit a Morse model to the point wise potential energy scan (PES). However, this approach suffers from an inherent uncertainty, resulting from the actual number of data points used in the fitting procedure. In order to obtain the three parameters of the Morse potential a minimum of three data points is required. Even if the minimum position is constrained to the equilibrium distance of the PES (thus formally only requiring two data-points for the fit), the inclusion of the minimum and two neighbouring points is essential to account for the observed anharmonicity. Such a 3-point fit results in the most accurate representation of the potential close to the minimum, but typically suffers for larger displacements and thus in the prediction of higher order excitations. Any choice to include more than three points can be expressed via an arbitrarily chosen threshold, for instance including all data points below a pre-selected maximum energy E_max in the fitting procedure. Thus, in addition to the 3-point fitting a systematic increase of E_max in the range of 5, 10, 15, 25 and 50 kJ mol⁻¹ have been carried out. This strategy highlights the arbitrary character of the “best-fit” Morse approach, which is even further complicated if a weighting scheme is chosen to adjust the impact of data points in the fitting procedure.

All fits have been carried out using gnuplot⁵¹ without any additional weighting of data points, the employed initial values of D and α have been chosen as 500 kJ mol⁻¹ and 2.2 Å⁻¹. The predicted wave-numbers for the fundamental and first overtone of the OH vibrational mode for methanol, phenol and thymol in implicit solvent are summarised in Table 5. It can be seen that the Morse approach yields data of similar accuracy as the Numerov procedure, but the actual values are highly sensitive to the chosen energy threshold. Furthermore, it is not possible to improve the predicted wave numbers of the fundamental and first overtone simultaneously – while the overtone frequency is increasing upon increase of E_max, the same applies to the wavenumber of the fundamental excitation.

Table 5 Wavenumbers in cm⁻¹ obtained via a Morse fit to the potential energy scan in implicit solvation at B3LYP level using different threshold critera. The 3-point model considers only the three lowest data points, while for Tx all points below x kJ mol⁻¹ are included in the fitting procedure. The best agreement with experiment was achieved by ensuring that the same number of points are included in the attractive and repulsive branch

		Harmonic	Morse fit implicit solvent							Numerov	Experimental
			3 point	T5	T10	T15	T25	T50	Best	Implicit solvent
a This work.
Methanol	01	3825	3665	3658	3667	3676	3677	3693	3657	3657	3645^31
	02	7650	7131	7117	7134	7153	7154	7186	7115	7151	7121^31
Phenol	01	3803	3876	3665	3667	3674	3673	3682	3625	3638	3612,^a 3611^54,56
	02	7606	7552	7131	7134	7149	7146	7164	7051	7112	7056,^a 7053, 7052^54,56
Thymol	01	3808	3706	3661	3668	3676	3674	3681	3626	3641	3616^a
	02	7616	7212	7123	7137	7152	7149	7162	7053	7118	7060^a

---

A further aspect that has been noted during the fitting procedure is the fact that due to its steep increase the repulsive branch is underrepresented when compared to the attractive part of the potential. Thus, instead of employing the intuitive E_max threshold a selection of data points based on the distance was employed, thereby ensuring that the number of included data points in the attractive and repulsive branch is equal. In this case the accuracy in the predicted wave numbers was noticeably improved, leading to the most accurate prediction termed “best” in Table 5. However, similar as in the case of E_max the ideal number of data points to achieve this best prediction is unknown and was found to be different for the three different systems, namely ±17, 49 and 47 data points in case of methanol, phenol and thymol, respectively.

Despite the overall good predictive properties of a Morse model great care has to be taken in actual applications. The comparison of the potential energy scan with three different Morse fits (3-point, T10 and best) in the thymol case shown in Fig. S4 (ESI†) demonstrates that the differences in the predicted wave numbers results from considerably small deviations in the fitted Morse potentials. These minor differences result in deviations of up to 80 and 160 cm⁻¹ in the fundamental and first overtone wave numbers, due to the high sensitivity of the eigenvalues to the smallest change in the repulsive branch of the potential. The comparison in Fig. S4 (ESI†) also reveals a wrong asymptotic behaviour at large distances and predictions of overtone frequencies beyond the first can be expected to show large deviations. The reason for this is that although the Morse model employs three parameters to represent the anharmonic character of the potential, the attractive as well as the repulsive branch depend on the same α coefficient and it is not possible to take steepness and curvature of the two branches independently into account. In this case a potential using four or more parameters is required, however, analytical solutions of Schrödinger's equation are typically not available for this more general case.

Another situation requiring a careful assessment of a best-fit Morse model arises in potentials subject to different kinds of anharmonicity such as quartic and higher order oscillators.^52,53 In these cases a Morse approach will prove as a bad choice, since the properties of the energy eigenvalues will display a characteristic comparable to the “particle-in-the-box” model systems, i.e. subsequent energy levels will show an increase in separation. Vibrational modes in more complex systems may also display a Morse-like potential while at the same time a dominant higher order contribution (quartic, sextic,…) is present close to the minimum. In such a case the influence of Morse and higher order anharmonicity may even compensate. While such effects cannot be properly described by a Morse fit approach, Numerov's procedure will properly consider such effects if the grid-spacing is properly chosen as discussed above.

4 Conclusion

The data presented clearly demonstrates that the Numerov procedure is a reliable approach for the determination of vibrational frequencies of localised normal modes. The generalisation to higher order stencils enable a significant reduction in the number of data points of the associated vibrational potential, thus greatly improving the overall computational demand. Using a 9-point stencil to approximate the second derivative of the wave function in Schrödinger's equation, a spacing of approximately 0.05 Å to 0.06 Å was found to be sufficient, which can be further increased by extending to even higher order formulations. The comprehensive tests carried out with various analytically solvable model potentials also indicated that the approach shows equal scaling and performance in the harmonic and anharmonic case.

In conjunction with well-established density functionals and a suitable basis set the predicted OH wave numbers proved to be in excellent agreement with experiment for both fundamental and first overtone. This is especially true in case of the gas-phase. The influence of solvent can be represented in fair agreement with experiment by application of an implicit solvation model and the explicit consideration of solute–solvent contacts resulted in a further improvement of the prediction. The respective shift in wave numbers agrees well to the observed changes when moving from CCl₄ to n-hexane despite the very similar permittivity of the two solvents. The combination of explicit solvent molecules together with implicit solvation did not provide any improvement, however. This is most likely due to the approximation inherent to implicit solvation models which can be expected to be the limiting factor in such a computational setup.

Fitting of a Morse potential to predict the resulting wave numbers via the corresponding analytical solution of Schrödinger's equation proved to be a successful strategy for the investigated systems. However, a number of potentially limiting factors have been highlighted, namely the arbitrary choice of data points included in the fitting procedure and the wrong asymptotic properties for large distances. A further potential limitations the requires a careful consideration will occur in case of potentials showing different kind of anharmonicity as observed in quartic and higher order oscillators.

As a further strategy to reduce the associated computational effort the performance of constructed normal modes for the OH vibration was investigated based on the consideration that this modes are in general highly localised. This conjecture was also confirmed by vibrational perturbation theory including all normal modes and alternatively just the OH mode into the VPT2 treatment. The resulting wave numbers showed only a deviation of 1 to 2 wave numbers when compared to those predicted using the analytical normal mode.

These results confirm that it is possible to avoid the normal mode analysis to formulate the direction of the potential energy scan. For this localised vibrational state the demanding frequency computation is not required. This is of particular benefit for large systems, in which the computational effort of the normal mode analysis is increasing dramatically with the number of atoms. As can be expected the approximation proved more reliable in case of phenol and thymol, which can be attributed to the higher mass of the organic residue. Thus it can be concluded that the higher the mass of the moiety bound to the oxygen atom the better the performance of the constructed normal mode. A typical application of this advantage are investigations of hydroxyl groups on metal and metal oxide surfaces, since the respective difference in mass is typically even higher compared to the case of organic molecules. Since the application of the Numerov procedure is independent of the quantum chemical computation of the potential, an extension to periodic DFT approaches is straightforward and will be pursued in future work.
