Fabrication of monodispersed hollow flower-like porous In2O3 nanostructures and their application as gas sensors

Wei Xu, Jinwei Li and Jianbo Sun*
Key Laboratory for Photonic and Electronic Bandgap Materials, Ministry of Education, School of Physics and Electronic Engineering, Harbin Normal University, Harbin 150025, P. R. China. E-mail: xiaohan2298@163.com

Received 7th August 2015 , Accepted 18th September 2015

First published on 18th September 2015


Abstract

The solvothermal method using L-lysine as a surfactant and ethylene glycol as an efficient auxiliary was used to prepare mono-dispersed, hollow, flower-like porous (HFP) In2O3. The morphology of the materials was characterized through scanning electron microscopy (SEM) and transmission electron microscopy (TEM). In addition the structure and composition were analysed using X-ray powder diffraction (XRD) and high-resolution transmission electron microscopy (HRTEM). The sensing performance of the In2O3 material for 500 ppb NO2 was evaluated at near room temperature 40 °C. The results revealed that the HFP-In2O3 exhibited better gas-sensing properties, indicating its practical potential for detecting NO2 at lower concentrations and temperatures.


1. Introduction

Indium oxide (In2O3) is an important direct wide-band-gap (Eg = 3.55–3.75 eV), n-type semiconductor material and has various applications. For instance it has been used in displays,1,2 photocatalysis,3–5 thermoelectrics,6–8 solar cells,9–12 and detectors.13 In gas-sensing detection applications the material has been attracting a great deal of attention. In2O3 gas sensitive properties are closely related to its morphology and structure. In2O3 nanostructures with various morphologies from 0D to 3D have been synthesized and examples include nanoparticles, nanofibers, thin-films, nanowires, nanosheets, and hollow microspheres. The synthetic strategies to fabricate these structures are diverse and include physical methods such as evaporation, physical vapour deposition (PVD), and magnetron sputtering. In addition chemical methods such as chemical vapor deposition (CVD), sol–gel,14 hydrothermal, and electrospinning15–17 have been widely reported.18–20 For the current study results, hierarchical structure, and especially hierarchical hollow structures has an obvious reinforced effect upon In2O3 gas sensitive properties. This is because hierarchical structures have a higher surface area that promotes mass transport and gas diffusion in the sensor material. The traditional synthetic strategy for hollow, hierarchical structures utilise hard and soft templates and are multi-purpose as a synthetic strategy among hydrothermal synthesis methods of hollow spheres. The hard template and soft template methods dominate the chemical synthesis methods for hollow spheres. Wenjea J. Tseng et al. synthesized mono-dispersed In2O3 hollow spheres using commercial polymeric beads as a colloidal hard template and applied this to photocatalysis and gas sensing.21 The soft template method uses polymeride or surfactants. For example, Benxia Li et al. synthesized In2O3 hollow microspheres via the “formamide-resorcinol-water” system.22 However, these methods all have their own advantages and disadvantages. On the one hand, uniform-sized hollow spheres can be obtained and on the other, the material morphology may be damaged and introduce impurities when using the hard template method. The soft template method has no disadvantages that are mentioned above but can lead to an inhomogeneous size. Therefore, it is even more important to develop a more reasonable strategy to synthesize uniform and monodispersed hollow spheres for gas sensor applications. A uniform size can work well for material structure and the performance of gas sensitive material that the material is not easy to reunite during the synthesis process, which can make the sensitive material pore richer and facilitate the gas diffusion.

In our work, we used the solvothermal method to get the desired monodispersed hollow flower-like porous (HFP) In2O3 nanostructures with L-lysine as the surfactant and ethylene glycol serving as an auxiliary. Fabrication of a gas sensor using these nanostructures allowed greater sensitivity and room temperature operation.

2. Experimental

2.1 Synthesis of materials

All chemical reagents (analytical-grade purity) used during the experiment were not modified or subject to further purification. In(NO)3·4.5H2O, absolute ethyl alcohol, L-lysine, and the ethylene glycol obtained from Sigma Aldrich, which are based in the USA. The synthetic method was as followed. In(NO)3·4.5H2O (0.195 g) and L-lysine (0.041 g) were successively dissolved in ethylene glycol whilst continuously stirring for 3 min. Next, anhydrous ethanol solution was added into the above transparent solution and stirring continued for a further 2 min. The volume ratio of anhydrous ethanol and ethylene glycol is 9[thin space (1/6-em)]:[thin space (1/6-em)]1. Finally, the 80% mixture was sealed in a Teflon-lined stainless-steel autoclave of 44 mL capacity and kept at 120 °C for 18 h. After heating it was allowed to cool down to room temperature naturally. After the hydrothermal procedure, the primrose brownness precipitates were collected by centrifugation (8000 rpm, 5 min), washed several times with distilled water and ethanol, and dried in air at 60 °C for 24 h. The sintering was performed by slowly heating to 400 °C at a rate of 1 °C min−1. The hollow flower-like porous In2O3 (HFP-In2O3) structures were obtained after maintaining the precipitates at 400 °C for 2 h in an air atmosphere.

2.2 Characterization

The morphologies were directly investigated by SEM (SU70 Hitachi, Japan), at an accelerating voltage of 15 kV and TEM (FEI Tecnai TF20), working at 200 kV. The structures were measured using XRD analysis (D/max-2600 PC, Rigaku, Japan) with Cu Kα radiation (λ ≈ 1.5418 Å) over a 2θ range of 10–70°. HRTEM was also performed. The gas sensor characteristics were measured using a static test system.

2.3 Sensor fabrication

The gas sensor device includes two parts: a ceramic tube in which a pair of gold electrodes was covered and a Ni–Cr heating wire that was passed through the tube. The gas sensor device preparation of the hollow flower-like porous In2O3 nanostructures is as followed. The as-prepared powder was mixed together with deionized water producing a paste, which was placed onto the ceramic tube.

The gas sensor properties were influenced for external environmental conditions (10% RH), and measured by a static test system. The volume of the test system was 10 L. The response of the device is defined to be:

S = Rg/Ra for which test gases were oxidizing gases and Ra/Rg for reducing gases. Here, Ra and Rg represent the resistances of the sensor in the air and target gas, respectively. The response and recovery times of sensitive performance were defined as the time taken by the sensor to approach to 90% of the last stable resistance in the situation of adsorption and desorption, respectively.

3. Result and discussion

3.1 Structure and morphology

The fabricated products were measured using XRD and SEM techniques. XRD was performed to investigate the crystal phases of the as-fabricated indium oxide powders resulting from heat treatment (HT) of the precursors and sintering at 400 °C for 2 h (Fig. 1a). It is clear from the results that the as-prepared In2O3 is consistent with the standard data file (JCPDS file no. 71-2194). After calcification at 400 °C, the precursors were converted into a pure cubic structure of In2O3 with space group Ia[3 with combining macron] (no. 206) and lattice parameters a = 10.117 Å with characteristic peaks at (2 2 2), (4 0 0) and (4 4 0). No diffraction peaks from any other impurities were observed, indicating the high purity of the products. This suggests that the precursor is being completely transformed into the In2O3 phase and the high intensity of the diffraction peaks in XRD pattern suggests that the sample is of high crystallinity.
image file: c5ra15832j-f1.tif
Fig. 1 (a) XRD pattern and (b) morphological characterization of hollow flower-like porous In2O3 nanostructures after annealing the precursors at 400 °C for 2 h.

Fig. 1b shows a SEM image detailing the morphology of the as-prepared indium oxide (400 °C for 2 h). The low magnification SEM image (Fig. 1b) clearly displays flower-like In2O3 nanostructures with a uniform sphere size of ∼800 nm and are assembled with nanosheets that form a highly agglomerated structure. The inset shows a higher magnification image and indicates that the prepared In2O3 nanostructures are hollow and the nanosheets are constructed from a few nanometers of nanoparticles (5–10 nm). The morphology of the In2O3 was relatively unified, showing a uniform size of the HFP-In2O3.

More information can be found in Fig. 2. The hollow structures were characterized by TEM and shown in Fig. 2a. This results in an image where the edge is black and the center has a light color. TEM gives a more accurate size of the sphere at approximately 867 nm. The edge of the spherical shell can be seen to be made of nanosheets and some nanoparticles, which is consistent with results obtained from the SEM (Fig. 1b). Selecting nanosheets from the edge of the spherical shell and taking a further magnified image as shown in Fig. 2b reveals the nanoparticle (approximately ranged from 5–10 nm) make-up of the nanosheets. The high-resolution transmission electron microscopy (HRTEM) image (Fig. 2c) of the nanosheet shows fringe distances of 0.29 nm and 0.21 nm, corresponding to the lattice distances of the (222) and (332) planes of cubic In2O3. So, it can be clearly seen that nanosheets are made up of single crystal particles. The HRTEM (Fig. 2b and c) confirms that the porous In2O3 flower-like structures are polycrystalline in nature.


image file: c5ra15832j-f2.tif
Fig. 2 (a) TEM image of HFP-In2O3 nanostructures. (b) High-magnification TEM images of the nanosheets. (c) HRTEM image of part of the nanosheets.

3.2 Materials synthesis mechanism

Fig. 3a shows that with no added L-lysine the material consists of 50 nm particles of relatively uniform size and no sheet structure. The product is a size-inhomogeneous aggregate and composed of nanosheets when the solution only has anhydrous ethanol with no ethylene glycol (Fig. 3b). This is consistent with the result of Kwon-Il Choi et al.23 Fig. 3c shows that the materials are uniformly sized hollow spheres assembled from nanosheets and nanoparticles. By comparing Fig. 3a and b it can be seen that L-lysine plays a crucial role of connecting indium. Comparison of Fig. 3b and c reveals that ethylene glycol has dispersive effects upon the system. The probable mechanism is shown in Fig. 4. The positive NH3+ and negative COO may come from NH2 and COOH radicals derived from lysine. Thanks to the electrostatic interaction, the negative end of the lysine absorbs the In3+ ion that constructed a unit subassembly and these units form sheets because of oriented absorption among ions as a result of irregular reunion (when adding no ethylene glycol). Growth and integration between other sheet layers results in disorderly reunion of sheets. This can be explored from a thermodynamic point of view.24–26 The lower surface energy is more stable than the higher one and the surface energy is higher for single particles or sheets. Therefore the aggregate of particles and sheets decrease the surface energy to a stable condition. The ethylene glycol increases surface energy of units, which are composed of indium and lysine in order to influence their aggregate. This leads to the material growing to form relatively mono-disperse microsphere structures. Fig. 3c further shows that the ethylene glycol not only influences the aggregate of spheres but also the units in Fig. 3c. Both pieces and particles (they do not assemble into sheets) can be seen because of the property of ethylene glycol which seems to oil encase the water droplet and prevents it to grow.27
image file: c5ra15832j-f3.tif
Fig. 3 SEM images of various precursors: (a) no L-lysine; (b) no ethylene glycol; (c) anhydrous ethanol and ethylene glycol.

image file: c5ra15832j-f4.tif
Fig. 4 The synthetic mechanism of the materials.

In addition, this HFP-In2O3 material synthesis mechanism also conforms to Ostwald ripening of porous secondary particles and the Kirkendall effect. The outer primary units will swallow up the inner ones through Ostwald ripening when the outer ones are bigger or packed in a thicker manner than those on the inner parts. Zeng28 reviewed the main factors in the synthesis of hollow structures by Ostwald ripening. Meanwhile, during the oxidation of dense and crystalline indium particles, hollow structures can be formed by the Kirkendall effect when the outward diffusion of indium cations is faster versus the inward diffusion of oxygen to the metal core.29–31 Generally, the development of the shell layers is mainly due to the Kirkendall effect rather than Ostwald ripening.

3.3 Gas sensing properties

The working temperature apparently influenced the response of a sensor material,32–34 regulation of adsorption/desorption processes at equilibrium and the competition for chemisorption between the test gas and atmospheric oxygen O2 for active surface sites. Thus, the response corresponding to the operating temperature curve was measured. Fig. 5a shows the variation of the response of the In2O3 sensors that were exposed to 500 ppb NO2 gas at different operating temperatures. The response is confirmed to be very strongly dependent on the operating temperature. When the operating temperature is greater, the gas response value increases sharply, but as the operating temperature gets higher than 40 °C, the response slowly decreases. The maximum response value to NO2 is approximately 50.5 at 40 °C. Therefore the optimal operating temperature of 40 °C was chosen for the sensor based HFP-In2O3 to further measure the characteristics of the gas sensors. The response result increases with temperature initially due to the acceleration of the surface reaction rate with operating temperature. However, in contrast very high temperatures may be detrimental since it may lead to low diffusion depth and therefore decrease the overall response to NO2.35–39 With the optimal temperature, the diffusion depth and reaction rate to NO2 reaches a maximum.40,41 The relationship between the total time for a complete test (response and recovery) and the working temperature was explored (Fig. 5b). The figure illustrates that faster response can be obtained by increasing the operating temperature because of the enhanced activation energies which is associated with an increased temperature. Moreover, Fig. 5a and b illustrates that the hollow structure is more suitable for working under lower temperature. This also can be illustrated in Table 1 which comparison in term of operating temperature, sensitivity and selectivity between results of the literature and the present work.43–48
image file: c5ra15832j-f5.tif
Fig. 5 (a) Correlations between the operating temperature and the gas response; (b) correlations between the operating temperature and operating time (response and recovery time at one cycle time).
Table 1 Comparison in term of operating temperature, sensitivity and selectivity between results of the literature and the present work (hierarchical: HI; hollow: HO)
Materials Temp. (°C) Sensor response Selectivity Con. (ppm) Ref.
In2O3 (HI) 150 74 NO2 0.5 43
In2O3 (HO) 350 0.91 C3H6O 50 44
In2O3 (HI) 140 ∼41.1 NO2 0.2 45
In2O3 (HO) ∼200 7 CO 1 46
WO3 (HIHO) 140 ∼18 NO2 0.1 47
WO3 (HIHO) 100 89 NO2 1 48
In2O3 (HIHO) 40 50.5 NO2 0.5 Present work


The response transient characteristics of the HFP-In2O3 nanostructures sensors to 500 ppb NO2 were investigated at a lower temperature of 40 °C (10% RH) (Fig. 6a). The response and recovery times to 500 ppb NO2 are approximately 11 and 18 min, respectively. Fig. 6b shown the three times repeated response transients curves to 500 ppb for the sensor NO2 at 40 °C and the three times response/recovery times were basically consistent indicating a repeatable and stable characteristic of sensor based on HFP-In2O3. The sensitivity behaviors were further investigated by exposing the sensor to different concentrations of NO2 at room temperature (10% RH). The results were displayed in Fig. 6c. When the sensor was exposed to 10 ppb NO2, the response was about 3. With increasing concentration of NO2, the responses greatly increased and no saturation phenomenon. The responses were about 6.3, 15, 25, 50.5, 62, 73.2, 159 and 220 to 30, 80, 200, 500 ppb, 800 ppb, 1000 ppb, 3000 ppb and 5000 ppb NO2, respectively.


image file: c5ra15832j-f6.tif
Fig. 6 (a) Response transients resistance of the sensor. (b) The repeated response transients curves to 500 ppb for the sensor NO2 at 40 °C. (c) The gas responses to different concentrations of NO2 for the sensor using the HFP-In2O3 at 40 °C. (d) Comparison of responses of In2O3 sensors to various gases at 40 °C (10% RH).

Selectivity is a necessary parameter for gas sensors in both practical and research applications. Fig. 6d shows the cross-sensitivity of a sensor that is coated in flower-like In2O3 nanostructures. In this case the gases and volatile liquids had concentrations of 500 ppb and 100 ppm respectively. The molecules tested included CO, H2, NH3, C2H6O, CH2O and C3H6O. All of the gasses were tested at an operating temperature of 40 °C. It is expected that the In2O3 sensor will exhibit a higher response to NO2 among the operated gases and lower response to the other gases. The results did indeed show that the sensor using the HFP-In2O3 nanostructures exhibits an excellent selectivity to NO2 and little to the other tested gases.

3.4 Gas sensing mechanism

The response of the sensor is a reflection of the change in the material resistance. The change of resistance for HFP-In2O3 sensors is due to the adsorption and desorption of test gas molecules on the surface of the materials. Its gas sensing mechanism can be explained using the modulation model of the depletion layer.42 At room temperature, sensors located in the air adsorb oxygen on the surface of material which, with the associated electrons of the material, form O2 (adsorbed oxygen).

When the sensor is exposed to an oxide gas such as NO2, it takes the electrons from the adsorbed oxygen because the oxidizability of NO2 is higher than that of oxygen. Furthermore, the test gas captures electrons from the conduction band of In2O3 and increases the material surface depletion layer thickness. Therefore the resistance rapidly increases during the adsorption process. When the In2O3-based sensor comes back to air gases, the NO2 partial pressure is reduced and the NO2 molecules desorb from the material leading to a reduction in the depletion layer thickness and the sensor returns to its original state. The desorption and absorption of test gases are accompanied by oxidation–reduction reactions, which require energy. Therefore is likely that a low working temperature may be the cause of the slower desorption. The surface of HFP-In2O3 is rich in nanoparticles. These nanoparticles possess nanosize quantum confinement effects that results in producing many active sites and these active sites could improve the sensitivity of materials. The HFP-In2O3 hierarchical nanostructures and the accumulation of nanosheets can form the pore passageways that allow the gas quickly access and break away from active sites on the inner and outer surface of the hollow spherical material. The abundant pore passageways are beneficial to NO2 rapidly transmitting and the response speeded up. Therefore this special geometry is also helpful to in order to improve the gas sensing properties.

The morphology and structure of material can clearly affect the performance of gas sensitivity. The response of different In2O3 structures is shown in Fig. 7. The experimental investigation shows the sensing properties of materials at 500 ppb NO2 and 40 °C with (a) no L-lysine (NL) and (b) no ethylene glycol (NEG) and (c) anhydrous ethanol/ethylene glycol (AE/EG). The response values of NL, NEG and AE/EG are 1.08, 7.5 and 50.5 respectively which correspond to a response time of 33 min, 32 min, 11 min respectively. The recovery times associated with NL, NEG and AE/EG are 82 min, 45 min, and 18 min respectively. The response of the materials with NL almost had no change because these particles aggregate to reduce the surface area. In addition the NEG system had a little response with its sheets structure increasing the surface area. The response of the AE/EG (HFP-In2O3) system has a greatly improved response due to its hollow structure with larger surface area, which can provide more active sites. The surface of these materials is composed of a sheet each of which is made up of particles with active sites providing many passageways and chances to gas sensitivity. In addition, it is obvious that a hollow structure allows efficient diffusion of gas into and out of the structure allowing a fast response. In Fig. 7 the HFP-In2O3 material has a higher response and shorter response/recovery time to NO2.


image file: c5ra15832j-f7.tif
Fig. 7 The normalized response with (a) NL; (b) NEG; (c) AE/EG.

4. Conclusion

Solvothermal synthesis is used to fabricate uniform size HFP-In2O3 with L-lysine, ethylene glycol and annealing of the precursors at 400 °C/2 h. Its gas properties were investigated through cross-comparison and showed that 500 ppb NO2 at 40 °C with a response value of about 50.5 is far higher than other gases. The material exhibited a much higher selectivity to NO2. This method of ethylene glycol assisting L-lysine at a relatively low temperature to prepare HFP-In2O3 offers an effective strategy to prepare uniform size hollow flower-like porous spheres.

Acknowledgements

This work was partially supported by the Natural Science Foundation of China (No. 61403110).

References

  1. K. S. Park, W. Sato, G. Grause, T. Kameda and T. Yoshioka, Thermochim. Acta, 2009, 493, 105–108 CrossRef CAS PubMed.
  2. X. G. Xu, J. Chen, S. Z. Deng, N. S. Xu and J. Lin, J. Vac. Sci. Technol., B: Microelectron. Nanometer Struct.--Process., Meas., Phenom., 2010, 28, 490–494 CrossRef CAS.
  3. L. Y. Chen, Y. Liang and Z. D. Zhang, Eur. J. Inorg. Chem., 2009, 7, 903–909 CrossRef PubMed.
  4. B. X. Li, Y. Xie, M. Jing, G. X. Rong, Y. C. Tang and G. Z. Zhang, Langmuir, 2006, 22, 9380–9385 CrossRef CAS PubMed.
  5. H. G. Sun, W. L. Fan, Y. L. Li, X. F. Cheng, P. Li, J. C. Hao and X. Zhao, Phys. Chem. Chem. Phys., 2011, 13, 1379–1385 RSC.
  6. M. Ohtaki, D. Ogura, K. Eguchi and H. Arai, J. Mater. Chem., 1994, 4(5), 653–656 RSC.
  7. W. Xu, Y. Liu, B. Chen, D. B. Liu, Y. H. Linc and A. Marcellide, Phys. Chem. Chem. Phys., 2013, 15, 17595–17600 RSC.
  8. Y. Liu, W. Xu, D. B. Liu, M. Yu, Y. H. Lin and C. W. Nan, Phys. Chem. Chem. Phys., 2015, 17, 11229–11233 RSC.
  9. T. O. L. Sunde, M. Lindgren, T. O. Mason, M. A. Einarsrud and T. Grande, Dalton Trans., 2014, 43, 9620–9632 RSC.
  10. S. Calnan and A. N. Tiwari, Thin Solid Films, 2010, 518, 1839–1849 CrossRef CAS PubMed.
  11. R. A. Ismail, O. A. Abdulrazaq and K. Z. Yahya, Surf. Rev. Lett., 2005, 12, 515–518 CrossRef CAS.
  12. R. Sharma, R. S. Mane, S. K. Min and S. H. Han, J. Alloys Compd., 2009, 479, 840–843 CrossRef CAS PubMed.
  13. H. Meng, W. Yang, X. H. Yan, Y. G. Zhang, L. Feng and Y. F. Guan, Sens. Actuators, B, 2015, 216, 511–517 CrossRef CAS PubMed.
  14. X. S. Niu, H. X. Zhong, X. J. Wang and K. Jiang, Sens. Actuators, B, 2006, 115, 434–438 CrossRef CAS PubMed.
  15. Z. X. Cheng, X. B. Dong, Q. Y. Pan, J. C. Zhang and X. W. Dong, Mater. Lett., 2006, 60, 3137–3140 CrossRef CAS PubMed.
  16. A. Qurashi, E. M. El-Maghraby, T. Yamazaki and T. Kikuta, J. Alloys Compd., 2009, 480, 9–12 CrossRef PubMed.
  17. T. Hyodo, H. Inoue, H. Motomur, K. Matsuo, T. Hashishin, J. Tamaki, Y. Shimizu and M. Egashira, Sens. Actuators, B, 2010, 151, 265–273 CrossRef CAS PubMed.
  18. C. Y. Wang, M. Ali, T. Kups, C. C. Rohlig, V. Cimalla, T. Stauden and O. Ambacher, Sens. Actuators, B, 2008, 130, 589–593 CrossRef CAS PubMed.
  19. T. Hyodo, H. Inoue, H. Motomur, K. Matsuo, T. Hashishin, J. Tamaki, Y. Shimizu and M. Egashira, Sens. Actuators, B, 2010, 151, 265–273 CrossRef CAS PubMed.
  20. M. Q. Huang, Z. D. Cui, X. J. Yang, S. L. Zhu, Z. Y. Li and Y. Q. Liang, RSC Adv., 2015, 5, 30038–30045 RSC.
  21. W. J. Tseng, T. T. Tseng, H. M. Wu, Y. C. Her and T. J. Yang, J. Am. Ceram. Soc., 2013, 96, 719–725 CrossRef CAS PubMed.
  22. B. X. Li, Y. Xie, M. Jing, G. X. Rong, Y. C. Tang and G. Z. Zhang, Langmuir, 2006, 22, 9380–9385 CrossRef CAS PubMed.
  23. K. I. Choi, H. R. Kim and J. H. Lee, Sens. Actuators, B, 2009, 138, 497–503 CrossRef CAS PubMed.
  24. C. Li, D. H. Zhang, S. Han, X. L. Liu, T. Tang and C. W. Zhou, Adv. Mater., 2003, 15, 143–146 CrossRef CAS PubMed.
  25. J. Y. Liu, T. Luo, F. L. Meng, K. Qian, Y. T. Wan and J. H. Liu, J. Phys. Chem. C, 2010, 114, 4887–4894 CAS.
  26. X. M. Xu, D. W. Wang, W. B. Wang, P. Sun, J. Ma, X. S. Liang, Y. F. Sun, Y. G. Ma and G. Y. Lu, Sens. Actuators, B, 2012, 171–172, 1066–1072 CrossRef CAS PubMed.
  27. Z. Q. Sun, T. Liao, Y. H. Dou, S. M. Hwang, M. S. Park, L. Jiang, J. H. Kim and S. X. Dou, Nat. Commun., 2014, 5, 3813 CAS.
  28. H. C. Zeng, J. Mater. Chem., 2006, 16, 649–662 RSC.
  29. Y. Yin, R. M. Rioux, C. K. Erdonmez, S. Hughes, G. A. Somorjai and A. P. Alivisatos, Science, 2004, 30, 711–714 CrossRef PubMed.
  30. H. J. Fan, Y. Gosele and M. Zacharias, Small, 2007, 3, 1660–1671 CrossRef CAS PubMed.
  31. B. Liu and H. C. Zeng, J. Am. Ceram. Soc., 2004, 126, 16744–16746 CrossRef CAS PubMed.
  32. T. Hyodo, H. Inoue, H. Motomur, K. Matsuo, T. Hashishin, J. Tamaki, Y. Shimizu and M. Egashira, Sens. Actuators, B, 2010, 151, 265–273 CrossRef CAS PubMed.
  33. P. C. Xua, Z. X. Cheng, Q. Y. Pan, J. Q. Xu, Q. Xiang, W. J. Yu and Y. L. Chu, Sens. Actuators, B, 2008, 130, 802–808 CrossRef PubMed.
  34. C. Q. Wang, D. Chen, X. L. Jiao and C. L. Chen, J. Phys. Chem. C, 2007, 111, 13398–13403 CAS.
  35. N. Yamazoe, G. Sakai and K. Shimanoe, Catal. Surv. Asia, 2003, 7, 63–75 CrossRef CAS.
  36. G. Sakai, N. Matsunaga, K. Shimanoe and N. Yamazoe, Sens. Actuators, B, 2001, 2, 125–131 CrossRef.
  37. A. M. Andringa, N. Vlietstra, E. C. P. Smits, M. J. Spijkman, H. L. Gomes, J. H. Klootwijk, P. W. M. Blom and D. M. Leeuw, Sens. Actuators, B, 2012, 171–172, 1172–1179 CrossRef CAS PubMed.
  38. N. Matsunaga, G. Sakai, K. Shimanoe and N. Yamazoe, Sens. Actuators, B, 2003, 96, 226–233 CrossRef CAS.
  39. N. Yamazoe and K. Shimanoe, Sens. Actuators, B, 2008, 128, 566–573 CrossRef CAS PubMed.
  40. P. Bogdanov, M. Ivanovskaya, E. Comini, G. Faglia and G. Sberveglieri, Sens. Actuators, B, 1999, 57, 153–158 CrossRef CAS.
  41. J. Ding, T. J. McAvoy, R. E. Cavicchi and S. Semancik, Sens. Actuators, B, 2001, 77, 597–631 CrossRef CAS.
  42. Z. H. Jing and J. H. Zhan, Adv. Mater., 2008, 20, 4547–4551 CrossRef CAS PubMed.
  43. X. M. Xu, P. L. Zhao, D. W. Wang, P. Sun, L. You, Y. F. Sun, X. S. Liang, F. M. Liu, H. Chen and G. Y. Lu, Sens. Actuators, B, 2013, 176, 405–412 CrossRef CAS PubMed.
  44. H. X. Dong, Y. Liu, G. H. Li, X. W. Wang, D. Xu, Z. H. Chen, T. Zhang, J. Wang and L. Zhang, Sens. Actuators, B, 2013, 178, 302–309 CrossRef CAS PubMed.
  45. X. M. Xu, X. Li, H. J. Zhang, C. H. Feng, C. Wang, F. M. Liu, Y. F. Sun, P. Sun and G. Y. Lu, RSC Adv., 2015, 5, 30297–30302 RSC.
  46. A. Shanmugasundaram, P. Basak, S. V. Manorama, B. Krishna and S. Sanyadanam, ACS Appl. Mater. Interfaces, 2015, 7(14), 7679–7689 CAS.
  47. J. W. Li, X. Liu, J. S. Cui and J. B. Sun, ACS Appl. Mater. Interfaces, 2015, 7, 10108–10114 CAS.
  48. C. Wang, C. H. Feng, M. Wang, X. Li, P. F. Cheng, H. Zhang, Y. F. Sun, P. Sun and G. Y. Lu, RSC Adv., 2015, 5, 29698–29703 RSC.
