A highly sensitive and water soluble fluorescent probe for rapid detection of hydrogen sulfide in living cells

Abstract

A highly sensitive and specific fluorescent probe has been developed for the rapid detection of H₂S in living cells. This probe exhibits the unique qualities of quick response, low detection limit, excellent water solubility and good membrane permeability. Its potential for biological applications has been demonstrated by imaging H₂S in living cells.

---

Hydrogen sulfide (H₂S) is traditionally viewed as a toxic gas with the characteristic odor of rotten-eggs. However, more recent studies have established it as the third gaseous transmitter after nitric oxide (NO) and carbon monoxide (CO).¹ H₂S at physiological levels exerts fine modulatory control over cellular functions by signaling an array of processes such as neuromodulation in the brain and smooth muscle relaxation in the vascular system.^2,3 Endogenous H₂S is synthesized in mammalian tissues in a controlled fashion and dysregulation of H₂S production or metabolism is reported to be linked to a variety of disease phenotypes including Alzheimer's disease,⁴ diabetes,⁵ hypertension,⁶ etc. To date, many details on the physiological and pathological roles of H₂S are still under active investigation. Therefore, it is important to have robust assays for H₂S detection in its native environment to facilitate detailed biological function studies.

Current methods available for the detection of H₂S, including colorimetric, electrochemical,⁶ and gas chromatography assays,⁷ are limited by low resolution, complicated requirements for sample preparation and poor biocompatibility, which forbid the real time monitoring of H₂S production, trafficking, and consumption in living cells, tissues, and whole organisms. As such, fluorescent molecular probes offer an appealing approach for the detection of H₂S attributed to their nondestructive attribute and high sensitivity.^8,9 A number of fluorescent probes have recently been developed to measure H₂S in living cells or in whole blood. These probes, judiciously designed by making use of the nucleophilic or reducing properties of H₂S, undergo chemoselective reactions with H₂S in the native cellular environment and their fluorescence properties are altered as a consequence.^10,11 However, most of these probes are limited by two substantial challenges. One is their sluggish reaction kinetics with H₂S, as exemplified by our previous probe ZS1, which utilized an aldehyde–acrylate group to trap H₂S and required 50 minutes to reach its highest fluorescent response.¹² The other is their poor water-solubility. Being poor water-soluble, most probes can only be used in mixed solvents containing a large portion of non-biocompatible organic solvents for fluorescent spectrometry analysis, which greatly limits their application. Given the diffusive and highly reactive nature of H₂S, more sensitive probes with faster response and improved water-solubility are still highly desirable.

In the present work, we are interested in devising new probes by taking advantage of the extremely strong affinity and facile kinetic profile between S²⁻ and Cu²⁺. Indeed, several fluorescent probes have been developed employing this strategy, including HSip-1 from Nagano group, L1Cu from Zeng group and Cu-1 from Shen group (Fig. 1).¹³ However, they are limited by their poor membrane permeability or poor water solubility.¹³ Herein we disclose a highly sensitive and selective H₂S probe, namely ZS2-Cu, with good water solubility and excellent membrane permeability. The probe was assembled by complexing Cu²⁺ with the BODIPY-based ligand ZS2 (Fig. 1). Our design of ZS2-Cu was based on the following facts: (1) BODIPY fluorophore represents a desirable fluorescent scaffold for the design of live-organism imaging probes owning to its prominent photophysical properties and excellent membrane permeability;¹⁴ (2) N, N-bis(2-pyridylmethyl)ethylenediamine may serve as a coordinating group for Cu²⁺ to quench the fluorescence of ZS2 after binding Cu²⁺ because of the paramagnetic character of the cation;¹⁵ (3) in the presence of S²⁻, Cu²⁺ would be rapidly de-coordinated from the probe to release ligand ZS2 and therefore restore the strong fluorescence of the system, yielding a quick and sensitive response towards S²⁻; (4) in addition to its function to chelate Cu²⁺, N, N-bis(2-pyridylmethyl)ethylenediamine also helps to improve the water solubility of the probe. Besides, fluorescent ligand ZS2 is readily accessible due to the well documented nucleophilic reaction between α-chloroBODIPY and N-centered nucleophiles.¹⁶

Fig. 1 Structures of reported probes and the philosophy of our design.

With all these considerations, ZS2 and ZS2-Cu were synthesized as outlined in Scheme 1. Nucleophilic substitution of α-chloro-BODIPY (1) with N, N-bis(pyridin-2-ylmethyl)ethane-1,2-diamine (2), both of which were prepared according to literature procudeures,^17,18 readily yielded ZS2. Treatment of ZS2 with copper(II) chloride in THF in the dark gave ZS2-Cu quantitatively. The 1 : 1 stoichiometry of the complex was confirmed by both mass spectrometry and a Job's plot (Fig. S1†). The nitrogen atom directly attached to the BODIPY core in ZS2 was speculated being involved in the chelation by UV-vis spectra analysis. ZS2 alone in PBS showed an absorption band with the maximum peak centered at 494 nm (ε 17 150), which can be assigned to the lowest-lying π–π* transition of the BODIPY core, while the addition of Cu²⁺ caused a blue-shift of 18 nm (λ_max 476 nm, ε 17 940), presumably due to the decreased donation effect of the lone pair electrons on the N atom to the π system of BODIPY after chelation (Fig. S2†).

Scheme 1 Synthetic procedures for ZS2 and ZS2-Cu.

With these probes in hand, we first measured their water solubility employing the UV spectrometry method. As expected, ZS2-Cu exhibited an improved water solubility of 1.28 ± 0.02 g L⁻¹. This advantage greatly facilitated following cuvette-based experiments which were carried out solely in aqueous solution without the need for organic co-solvent. The fluorescent properties of ZS2 without or with the presence of Cu²⁺ were then investigated. As shown in Fig. 2, ZS2 alone in PBS exhibited an intense emission centered at 546 nm (λ_ex 480 nm, Φ 0.1040), which was gradually attenuated by the addition of increasing amount of Cu²⁺, indicating the coordination of ZS2 with Cu²⁺. The system reached 90% quenching when 1.0 eq. of Cu²⁺ in total was added, in agreement with the 1 : 1 complexation stoichiometry. Significantly, the fluorescent turn-off response of ZS2 was specific to Cu²⁺ with other cations including Ca²⁺, Cd²⁺, Cr³⁺, Fe³⁺, K⁺, Na⁺, Ni²⁺, Pb²⁺, Sn⁴⁺, Zn²⁺ and Fe²⁺ triggering no obvious responses (Fig. S3†). Besides, ZS2 was able to respond to Cu²⁺ even in the presence of the above mentioned metal ions, implying it could be utilized as a Cu²⁺-selective fluorescent sensor.

Fig. 2 The turn-off responses of ZS2 towards Cu²⁺. The addition of increasing concentrations of Cu²⁺ gradually quenched the fluorescence of ZS2 (0.5 μM). Spectra were taken in PBS (10 mM, pH 7.4, 25 °C) immediately after the addition of Cu²⁺ (λ_ex 480 nm). The slit width was 5 nm for both excitation and emission. Inner panel: correlation between the emission intensity at 546 nm of the system (y) and the molar ratio of Cu²⁺ to ZS2 (x).

Next, probe ZS2-Cu was examined for its ability to sense S²⁻ with NaHS as an aqueous sulfide source. As expected, ZS2-Cu alone in PBS was almost nonfluorescent (Φ 0.004), while the addition of NaHS triggered an immediate increment in fluorescence intensity. A maximum fluorescence enhancement factor of 19 was achieved at 546 nm when 2.0 eq. of NaHS was added. Interestingly, the fluorescent spectrum of the system taken right after the addition of NaHS could overlap with that taken after an incubation time of 30 minutes, verifying rapid response of the probe. Moreover, both the shape and intensity of the emission band of the system resembled those of ZS2, indicating the de-coordination of Cu²⁺ from the probe and therefore the release of ZS2 from the complex because of the higher affinity between Cu²⁺ and S²⁻. Noteworthy, the fluorescence enhancement of the system was linear to the concentration of NaHS up to 20 μM, with the detection limit to be as low as 250 nM, indicating the great potential of ZS2-Cu to quantify H₂S (Fig. 3).

Fig. 3 The turn-on fluorescence responses of ZS2-Cu towards NaHS. The gradual addition of NaHS restored the fluorescence of the system. Spectra were taken in PBS buffer (10 mM, pH 7.4, 25 °C) instantly after the addition of NaHS with excitation to be 480 nm. The slit width was 3 nm for both excitation and emission. Concentration of ZS2-Cu was 10 μM and those of NaHS ranged from 0 to 30 μM. Inner panel: regression equation between the fluorescence intensity at 546 nm (y) and the corresponding concentration of NaHS (x).

Furthermore, the specificity of ZS2-Cu was evaluated by measuring its response after exposure to various common anions and biothiols in PBS buffer. As shown in Fig. 4, among all the anions tested, including bio-relevant F⁻, Cl⁻, Br⁻, I⁻, H₂PO₄⁻, NO₃⁻, CO₃²⁻, ClO⁻, and sulfur oxyanions such as SO₃²⁻, SO₄²⁻, S₂O₃²⁻, etc., no species other than S²⁻ was able to induce a fluorescence enhancement. Moreover, common biothiols such as reduced glutathione (GSH) and L-cysteine (L-cys) which are the major interferents jeopardizing the specificity of reported H₂S probes, proved to be innocent in this case. Actually, ZS2-Cu exhibited more than 30-fold selectivity towards sulfide over other anions and biothiols. Based on these preliminary results, we next investigated whether the fluorescent response of ZS2-Cu towards NaHS could be affected by the presence of other anions or biothiols. Much to our delight, ZS2-Cu was still able to respond to NaHS with 15–18 fold fluorescence increasement in the coexistence of other anions or biothiols and the resultant fluorescent profile was pretty much the same as that without the presence of other competitive analytes (Fig. S4†). These results taken together demonstrated the high selectivity and sensitivity of ZS2-Cu for H₂S and its feasibility to detect H₂S in the complex biological samples.

Fig. 4 Fluorescence emission spectra of ZS2-Cu (10 μM) in PBS buffer (10 mM, pH 7.4, 25 °C) right after the addition of NaHS or other biologically relevant anions and biothiols (all were kept at a final concentration of 20 μM) (λ_ex = 480 nm). The slit width was 3 nm for both excitation and emission. Inner panel: emission intensity at 546 nm (y) when different species (x) were added.

Finally, the ability of ZS-2Cu to visualize H₂S in living cells was assessed. HeLa cells were incubated with ZS-2Cu (5 μM) for 15 min and weak fluorescence was observed (Fig. 5a). The medium was then removed and cells were washed with PBS to remove any extracellular probe. The cells were then treated with NaHS (100 μM) for 15 min which resulted in a dramatic increase in intracellular fluorescence (Fig. 5c). These results illustrated the excellent membrane permeability of ZS2-Cu and its ability to detect H₂S sensitively in living cells. It is noteworthy that live-cell imaging experiments also demonstrated that ZS2 could act as a dual sensor for both Cu²⁺ and H₂S with the former gave a turn-off response and the latter restoring the strong fluorescent signal (Fig. S5†).

Fig. 5 Imaging H₂S in live cells with ZS-2Cu. Intact HeLa cells were treated with ZS-2Cu (5 μM) for 15 min before imaging (a and b). Cells were then washed with PBS and incubated with NaHS (100 μM) for a further 15 min (c and d). Images were collected on a fluorescence microscope (LEICA DMI 4000B) upon excitation at 488 nm (a and c) or under bright field (b and d).

Conclusions

In summary, we have devised a highly specific and sensitive fluorescent probe for the rapid detection of H₂S in living cells employing the inorganic chemistry-based principle of precipitating copper with sulfide from the copper-complexing quenched probe and therefore releasing the fluorescent signal of the probe. Representing an appealing tool for H₂S analysis in biological samples, this probe exhibited rapid response towards H₂S, good water solubility and excellent membrane permeability. Besides, it responded to NaHS with a linear fluorescent enhancement and thus has the potential to be utilized for H₂S quantification. Its feasibility to monitor H₂S in living cells was also confirmed.

Acknowledgements

This work was supported by NSFC (30901858) and the Fundamental Research Funds for the Central Universities (2014FZA7016).

Notes and references

1. (a) R. Wang, Antioxid. Redox Signaling, 2003, 5, 493; (b) L. Li and P. K. Moore, Biochem. Soc. Trans., 2007, 35, 1138; (c) L. Li, P. Rose and P. K. Moore, Annu. Rev. Pharmacol. Toxicol., 2011, 51, 169.
2. K. Qu, S. W. Lee, J. S. Bian, C. M. Low and P. T. H. Wong, Neurochem. Int., 2008, 52, 155.
3. (a) R. Hosoki, N. Matsuki and H. Kimura, Biochem. Biophys. Res. Commun., 1997, 237, 527; (b) W. Zhao, J. Zhang, Y. Lu and R. Wang, EMBO J., 2001, 20, 6008; (c) D. J. Elsey, R. C. Fowkes and G. F. Baxter, Cell Biochem. Funct., 2010, 28, 95.
4. K. Eto, T. Asada, K. Arima, T. Makifuchi and H. Kimura, Biochem. Biophys. Res. Commun., 2002, 293, 1485.
5. Y. Kaneko, Y. Kimura, H. Kimura and I. Niki, Diabetes, 2006, 55, 1391.
6. G. Yang, L. Wu, B. Jiang, W. Yang, J. Qi, K. Cao, Q. Meng, A. K. Mustafa, W. Mu, S. Zhang, S. H. Snyder and R. Wang, Science, 2008, 322, 587.
7. U. Hannestad, S. Margheri and B. Sörbo, Anal. Biochem., 1989, 178, 394.
8. V. S. Lin and C. J. Chang, Curr. Opin. Chem. Biol., 2012, 16, 595.
9. W. Xuan, C. Sheng, Y. Cao, W. He and W. Wang, Angew. Chem., Int. Ed., 2012, 5, 2282.
10. (a) Y. Qian, J. Karpus, O. Kabil, S. Zhang, H. Zhu, R. Banerjee, J. Zhao and C. He, Nat. Commun., 2011, 2, 495; (b) C. Liu, J. Pan, S. Li, Y. Zhao, L. Y. Wu, C. E. Berkman, A. R. Whorton and M. Xian, Angew. Chem., Int. Ed., 2011, 50, 10327; (c) C. Liu, B. Peng, S. Li, C. M. Park, A. R. Whorton and M. Xian, Org. Lett., 2012, 14, 2184.
11. (a) A. R. Lippert, E. J. New and C. J. Chang, J. Am. Chem. Soc., 2011, 133, 10078; (b) H. Peng, Y. Cheng, C. Dai, A. L. King, B. L. Predmore, D. J. Lefer and B. Wang, Angew. Chem., Int. Ed., 2011, 50, 9672; (c) F. Yu, P. Li, P. Song, B. Wang, J. Zhao and K. Han, Chem. Commun., 2012, 48, 2852; (d) L. A. Montoya and M. Pluth, Chem. Commun., 2012, 48, 4767; (e) S. Chen, Z. Chen, W. Ren and H. Ai, J. Am. Chem. Soc., 2012, 134, 9589; (f) S. K. Das, C. S. Lim, S. Y. Yang, J. H. Han and B. R. Cho, Chem. Commun., 2012, 48, 8395.
12. X. Li, S. Zhang, J. Cao, N. Xie, T. Liu, B. Yang, Q. He and Y. Hu, Chem. Commun., 2013, 49, 8656.
13. (a) K. Sasakura, K. Hanaoka, N. Shibuya, Y. Mikami, Y. Kimura, T. Komatsu, T. Ueno, T. Terai, H. Kimura and T. Nagano, J. Am. Chem. Soc., 2011, 133, 18003; (b) F. Hou, L. Huang, P. Xi, J. Cheng, X. Zhao, G. Xie, Y. Shi, F. Cheng, X. Yao, D. Bai and Z. Zeng, Inorg. Chem., 2012, 51, 2454; (c) X. Qu, C. Li, H. Chen, J. Mack, Z. Guo and Z. Shen, Chem. Commun., 2013, 49, 7510.
14. (a) A. Loudet and K. Burgess, Chem. Rev., 2007, 107, 4891; (b) G. Ulrich, R. Ziessel and A. Harriman, Angew. Chem., Int. Ed., 2008, 47, 1184; (c) N. Boens, V. Leen and W. Dehaen, Chem. Soc. Rev., 2012, 41, 1130.
15. T. Koike, T. Watanabe, S. Aoki, E. Kimura and M. Shiro, J. Am. Chem. Soc., 1996, 118, 12696.
16. T. Rohand, M. Baruah, W. Qin, N. Boens and W. Dehaen, Chem. Commun., 2006, 3, 266.
17. L. Jiao, C. Yu, M. Liu, Y. Wu, K. Cong, T. Meng, Y. Wang and E. Hao, J. Org. Chem., 2010, 75, 6035.
18. K. Kiyose, H. Kojima, Y. Urano and T. Nagano, J. Am. Chem. Soc., 2009, 131, 10077.

---

Footnote

† Electronic supplementary information (ESI) available: Experimental details for the syntheses of ZS2, ZS2-Cu, NMR traces, biological methods and additional figures. See DOI: 10.1039/c4ra05430j

---
