High performance robust F-doped tin oxide based oxygen evolution electro-catalysts for PEM based water electrolysis

Abstract

Identification and development of non-noble metal based electro-catalysts or electro-catalysts comprising compositions with significantly reduced amounts of expensive noble metal contents (e.g. IrO₂, Pt) with comparable electrochemical performance to the standard noble metal/metal oxide for proton exchange membrane (PEM) based water electrolysis would signify a major breakthrough in hydrogen generation via water electrolysis. Development of such systems would lead to two primary outcomes: first, a reduction in the overall capital costs of PEM based water electrolyzers, and second, attainment of the targeted hydrogen production costs (<$3.00/gge delivered by 2015) comparable to conventional liquid fuels. In line with these goals, by exploiting a two-pronged theoretical first principles and experimental approach herein, we demonstrate for the very first time a solid solution of SnO₂:10 wt% F containing only 20 at.% IrO₂ [e.g. (Sn_0.80Ir_0.20)O₂:10F] displaying remarkably similar electrochemical activity and comparable or even much improved electrochemical durability compared to pure IrO₂, the accepted gold standard in oxygen evolution electro-catalysts for PEM based water electrolysis. We present the results of these studies.
