Footprints of scanning probe microscopy on halide perovskites

Abstract

Scanning probe microscopy (SPM) and advanced atomic force microscopy (AFM++) have become pivotal for nanoscale elucidation of the structural, optoelectronic and photovoltaic properties of halide perovskite single crystals and polycrystalline films, both under ex situ and in situ conditions. These techniques reveal detailed information about film topography, compositional mapping, charge distribution, near-field electrical behaviors, cation–lattice interactions, ion dynamics, piezoelectric characteristics, mechanical durability, thermal conductivity, and magnetic properties of doped perovskite lattices. This article outlines the advancements in SPM techniques that deepen our understanding of the optoelectronic and photovoltaic performances of halide perovskites.

Graphical abstract: Footprints of scanning probe microscopy on halide perovskites

Article information

Article type
Feature Article
Submitted
22 Jul 2024
Accepted
10 Sep 2024
First published
10 Sep 2024

Chem. Commun., 2024,60, 11685-11701

Footprints of scanning probe microscopy on halide perovskites

S. Gupta and S. Bhattacharyya, Chem. Commun., 2024, 60, 11685 DOI: 10.1039/D4CC03658A
