Synthesis and crystal characteristics of nirmatrelvir

Abstract

Several synthetic routes of nirmatrelvir (the ingredient of a new drug to treat COVID-19 made by Pfizer) have been reported. We focused on a second route to improve the synthetic method of nirmatrelvir with a methodology that included different steps. The first step was an analysis of reaction byproducts using acetonitrile as a solvent of the condensation reaction to improve the inversion rate. Then, we used isobutyl acetate as a crystalline solvent to obtain the key intermediate as a solvate, which was a stable crystal product with high purity. Complementarily, we also used trifluoroacetic anhydride as the primary-amide dehydrating agent, and 2-methyl tetrahydrofuran as the solvent to prepare nirmatrelvir, which led to an overall yield of 48% via four steps and a purity of 99.5% according to high-performance liquid chromatography. We also investigated the crystal form of nirmatrelvir: the single-crystal features and transformation from a crystal form to nirmatrelvir were dependent upon temperature. Our data have great value for study of the synthetic method and crystal stability of nirmatrelvir.
