An elaborate structure investigation of the chiral polymorph A-enriched zeolite beta

Author affiliations

Abstract

Polymorph A-enriched zeolite beta was hydrothermally synthesized from an extremely concentrated system using tetraethylammonium hydroxide (TEAOH) as an organic structure-directing agent (OSDA) in the presence of fluoride. The sample was investigated by powder X-ray diffraction (XRD), 29Si magic angle spinning nuclear magnetic resonance (MAS NMR), 19F MAS NMR, and high-resolution transmission electron microscopy (HRTEM). The polymorph A enrichment was confirmed by the characterization, and the percentage of polymorph A was determined to be approximately 66% by DIFFaX simulation and HRTEM analyses. A pure polymorph A stacking area was detected by HRTEM, and the chiral structure of polymorph A in the zeolite beta was investigated on the basis of the HRTEM images.

Graphical abstract: An elaborate structure investigation of the chiral polymorph A-enriched zeolite beta

Back to tab navigation

Supplementary files

Publication details

The article was received on 07 Jan 2016, accepted on 03 Feb 2016 and first published on 03 Feb 2016


Article type: Paper
DOI: 10.1039/C6CE00043F
CrystEngComm, 2016,18, 1782-1789

  •   Request permissions

    An elaborate structure investigation of the chiral polymorph A-enriched zeolite beta

    M. Tong, D. Zhang, L. Zhu, J. Xu, F. Deng, R. Xu and W. Yan, CrystEngComm, 2016, 18, 1782
    DOI: 10.1039/C6CE00043F
