Photonic crystal enhanced microscopy for imaging of live cell adhesion

Author affiliations

Abstract

A form of microscopy that utilizes a photonic crystal biosensor surface as a substrate for cell attachment enables label-free, quantitative, submicron resolution, time-resolved imaging of cell–surface interactions without cytotoxic staining agents or temporally-unstable fluorophores. Other forms of microscopy do not provide this direct measurement of live cell–surface attachment localization and strength that includes unique, dynamic morphological signatures critical to the investigation of important biological phenomena such as stem cell differentiation, chemotaxis, apoptosis, and metastasis. Here, we introduce Photonic Crystal Enhanced Microscopy (PCEM), and apply it to the study of murine dental stem cells to image the evolution of cell attachment and morphology during chemotaxis and drug-induced apoptosis. PCEM provides rich, dynamic information about the evolution of cell–surface attachment profiles over biologically relevant time-scales. Critically, this method retains the ability to monitor cell behavior with spatial resolution sufficient for observing both attachment footprints of filopodial extensions and intracellular attachment strength gradients.

Graphical abstract: Photonic crystal enhanced microscopy for imaging of live cell adhesion

Back to tab navigation

Supplementary files

Publication details

The article was received on 18 Jun 2013, accepted on 19 Aug 2013 and first published on 19 Aug 2013


Article type: Paper
DOI: 10.1039/C3AN01541F
Analyst, 2013,138, 5886-5894

  •   Request permissions

    Photonic crystal enhanced microscopy for imaging of live cell adhesion

    W. Chen, K. D. Long, M. Lu, V. Chaudhery, H. Yu, J. S. Choi, J. Polans, Y. Zhuo, B. A. C. Harley and B. T. Cunningham, Analyst, 2013, 138, 5886
    DOI: 10.1039/C3AN01541F
