The tandem hydrogenation of CO2 to fuels and chemicals using bifunctional oxide/zeolite catalysts offers a promising strategy for reducing anthropogenic CO2 emissions while generating sustainable alternatives to fossil fuels. Despite significant advancements in this field, fundamental gaps remain in understanding the inflence of active site-proximity, intermediate transport rates, and the metal oxide migration and their ion-exchange with zeolitic Brønsted acid sites (BAS) on the reaction rates and hydrocarbon (HC) product selectivities. Challenges also include high CO selectivity and understanding the complexities of hydrocarbon pool (HCP) propagation in zeolite pore channels. This perspective integrates insights from analogous bifunctional catalytic systems, such as alkane hydrocracking and isomerization, to refine our understanding of site-proximity and transport artifacts on reaction rates and product selectivities. We examine diffusion-reaction formalisms for elucidating site-proximity effects on rates and HC selectivity, discuss methods to suppress CO selectivity using surface organometallic chemistry (SOMC) approaches, and explore strategies for suppressing ion-exchange and tuning HCP dynamics. By addressing these challenges, we outline a conceptual roadmap for advancing tandem CO2 hydrogenation chemistry, providing potential strategies to enhance catalytic efficiency of bifunctional oxide/zeolite systems.
Tandem reactions typically involve bifunctional catalytic cascades, with an intermediate forming over one active site and its subsequent conversion over a different active site. Kumar et al. demonstrated that in such cascading systems, the two distinct functionalities (e.g., metal and acid sites, metal and metal-support interface sites, etc.) exhibit different Brønsted–Evans–Polanyi (BEP) scaling relationships for the same intermediates along the reaction pathway and can potentially enhance reaction rates by leveraging separate mechanistic contributions, thereby breaking the selectivity-activity limits.6 While the idea of breaking selectivity-activity limits and converting CO2 to carbon-neutral fuels and chemicals seem appealing, designing efficient catalysts that maximize the utilization of all active sites and enhance selectivity toward desired product is challenging.
During tandem reactions, including CO2 hydrogenation, over bifunctional catalytic systems, the two catalytic functions are linked via the shuttling of reaction intermediates, thus requiring “site-proximity”, which ensures that active sites are spatially arranged to facilitate sequential transformations by minimizing the diffusion distance of intermediates. As such, the transport of intermediates between active sites (e.g., redox and Brønsted acid sites) can influence overall rates and selectivities,31 complicating the interpretation of intrinsic kinetics and reaction mechanism.
In tandem CO2 hydrogenation to hydrocarbons (HCs) in the methanol (CH3OH)-mediated route, CH3OH initially forms over redox sites (or oxygen vacancies) or alloys on metal oxides and then subsequently undergoes dehydration and C–C coupling over Brønsted acid sites (BAS) of zeolites to form HCs.32 This sequential reaction steps make site-proximity particularly crucial for this chemistry as the intermediate CH3OH must efficiently transport from redox sites to BAS for the methanol-to-hydrocarbon (MTH) conversion. Recent studies, including our own, have demonstrated that the efficacy of bifunctional oxide/zeolite systems is largely dictated by the efficiency of CH3OH transport and its consumption over BAS.16,33,34 As such, the catalytic efficiency can be enhanced by improving the site proximity between redox sites and BAS.31 However, at the closest proximity (i.e., nanoscale distance), two key problems exist; (1) the catalytic performance could be hindered by the migration of metal oxides inside zeolite framework and their cation exchange with BAS,17,26,27,35–38 and (2) the improvement in hydrocarbon (HC) yields and formation rates do not necessarily scale with the rate of CH3OH transport.31 As such, the molecular underpinnings of proximity-effects are convoluted and yet not understood for this conversion.
Additional key challenge associated with the CH3OH mediated route is the high CO selectivity caused by the endothermic side reaction of reverse-water–gas-shift (RWGS), which reduces hydrocarbon yield.32 While CO selectivity can be reduced by conducting reactions at low temperatures, the low reaction rates make it difficult to achieve appreciable single-pass CO2 conversions. In addition to that MTH is favored at higher reaction temperatures.32 Therefore, increasing HC yield while keeping CO selectivity low becomes a formidable challenge in this route and requires better CH3OH synthesis catalysts.
It is to be noted that while HC yields can potentially be enhanced by increasing CH3OH yield, achieving precise control over HC selectivity requires a fundamental understanding of how hydrocarbons form within zeolite pore channels.39 The reaction proceeds via a chain carrier mechanism consisting of three distinct phases: initiation, propagation, and termination (Fig. 1).39,40 During the initiation phase, unsaturated hydrocarbons form within the micropores of zeolite. These intermediates then participate in the propagation phase, following the well-established “dual cycle” or hydrocarbon pool (HCP) mechanism, which consists of two interconnected pathways: (1) the olefin cycle, where olefins undergo sequential methylation and cracking, and (2) the aromatic cycle, where aromatic species undergo methylation and demethylation. The interplay between these two cycles occurs through the aromatization of olefins and the dealkylation of aromatics to olefins, ultimately governing hydrocarbon selectivity.39 Although extensive research has focused on modulating the HCP mechanism in MTH conversion through changing reaction conditions, such as co-feeding H2 or CO, or changing zeolite composition, such as adjusting the Si/Al ratio of the zeolite or tuning acid site strength,41 the reaction conditions and catalytic system employed for tandem CO2 hydrogenation is different. A deeper understanding of the factors influencing the HCP mechanism in CO2 hydrogenation is therefore essential for achieving selective conversion to targeted hydrocarbon products.
![]() | ||
Fig. 1 Hydrocarbon pool (HCP) mechanism of methanol-to-hydrocarbon (MTH) conversion inside zeolite pore channels including initiation, propagation, and termination phases. The propagation encompasses multiple steps, including olefin methylation, cracking, hydrogen transfer, aromatization, aromatic methylation, and aromatic dealkylation. Adapted with permission from Mahnaz, F. & Shetty, M. et al.38 Copyright J. Catal. 2024. |
Overall, despite advances in bifunctional catalyst design, the efficiency of CO2 hydrogenation to selective HC remains constrained by critical knowledge gaps. Key unresolved questions include: (i) What does the “site-proximity” effect entail in tandem CO2 hydrogenation? (ii) What is the role of site-proximity in the transport of reaction intermediates? (iii) Can advection-diffusion-reaction formalisms be leveraged to interpret the proximity effect and its impact on reaction rates and selectivity? (iv) How do metal oxide migration and cation exchange occur at intimate proximities, and what are their effects on reactivity? (v) What strategies can reduce CO selectivity to enhance hydrocarbon yields? and (vi) How can HC selectivity be controlled through modulating HCP?
To address these challenges, this perspective explores insights into proximity effects derived from analogous bifunctional catalytic systems, such as alkane hydrocracking and isomerization chemistry, which share mechanistic parallels with tandem CO2 hydrogenation. We examine seminal work by Weisz42–44 and Iglesia45,46 on n-heptane isomerization, applying diffusion-reaction mathematical formalisms to different proximity length scales to elucidate intermediate transport effects. Additionally, we analyze how catalyst modifications at intimate proximities-via metal oxide migration and cation exchange at redox and acid sites can influence reaction pathways and propose strategies to mitigate these effects. Furthermore, we discuss approaches to overcoming the intrinsic challenge of CO selectivity by employing surface organometallic chemistry (SOMC) to enhance CH3OH selectivity and yield.47,48 Finally, we explore methods to modulate HCP to control HC selectivity. By integrating these perspectives, we aim to provide a roadmap for advancing CO2 hydrogenation through fundamental insights into site-proximity effects, catalyst design, and reaction engineering strategies.
![]() | (1) |
![]() | (2) |
![]() | (3) |
![]() | ||
Fig. 2 (A) Schematic of n-heptane isomerization over Pt/SiO2 and SiO2–Al2O3 catalyst. (B) Influence of temperature and particle size on the selectivity of iso-heptane in the product. (C) Influence of particle size on iso-heptene selectivity. Adapted with permission from Weisz.42 Copyright Adv. Catal. 1962. |
Applying this criterion, Weisz demonstrated that for an intermediate species with a partial pressure of 10−3 atm (as might be observed in olefin production during hydrocarbon reactions), the maximum catalyst particle size should be around 50 μm to avoid diffusion constraints in mesoporous catalysts (Fig. 3). Interestingly, even when an intermediate exists at a partial pressure of 10−10 atm, a stepwise reaction could still proceed without diffusion limitation, provided that the catalytic sites are within ∼100 Å (10 nm) of each other.44 This finding underscores the critical role of site proximity in bifunctional catalysis, where intermediate transport between distinct active sites governs overall catalytic performance.
![]() | ||
Fig. 3 Proximity requirement, in terms of component particle size, for typical conditions of reaction rate (10–6 moles s−1 cm−3), as a function of equilibrium vapor pressure of intermediate. Adapted with permission from Weisz.42 Copyright Adv. Catal. 1962. |
Akin to hydrocarbon hydroisomerization and hydrocracking reactions, for tandem CO2 hydrogenation, there is a consensus that the HC selectivity could be enhanced by improving CH3OH transport from active sites on metal oxides (e.g., oxygen vacancy sites) to BAS by improving their proximity.18,49,50 However, the improvement in hydrocarbon yields and formation rates do not necessarily scale with the rate of intermediate CH3OH transport (estimated from the ratio of linear velocity and distance between the active sites).31 It is our conjecture that a possible reason could be the diffusional restriction of HC inside microporous zeolites as the acid sites reside within voids of molecular dimensions, restricting their diffusional egress. Therefore, the physical characteristics of the diffusive medium, such as channel size, connectivity, crystal size, and the number of acid sites can become consequential for measured reaction rates.41 We emphasize that using microporous zeolites makes it difficult to apply Weisz's proximity criterion to find a critical length scale with negligible diffusion limitation, as the constituent reactions in MTH involving bulkier hydrocarbons would be inherently mass transport limited. In such systems, where transport artifacts influence selectivity in complex reaction networks, the Thiele modulus (ϕA) emerges as a fundamental non-dimensional parameter for analysis.51,52
![]() | (4) |
Thiele modulus naturally arises from a mole balance on the reactive domain of a catalyst and is defined as the ratio of the intrinsic reaction rate (in absence of mass transport limitation) to the diffusion rate when the driving force is at its maximum (eqn (4)). A low ϕA value (<1) indicates minimal mass transport limitations, allowing measured reaction rates to reflect intrinsic kinetics.51,52 As reactant concentration gradients become more pronounced, ϕA increases and leads to diffusion constraints that suppress observed reaction rates (rA, meas) relative to their kinetic counterparts (rA, kinetic). This discrepancy can be quantitatively estimated through the effectiveness factor (ηA) (eqn (5)),51,52 which measures the fraction of the intrinsic reaction rate achieved under diffusion-limited conditions.
![]() | (5) |
The application of these principles to tandem or cascading catalytic systems, however, presents unique challenges. For example, in such systems, if secondary reaction rates are faster than primary reaction rates and/or if the molecular diffusivities of primary products are low (i.e., ϕA ≫ 1), diffusion limitations can obscure product identity.46 For example, secondary reactions may take place before primary products can be detected in the bulk phase, complicating efforts to elucidate reaction networks and mechanisms.53 Such occurrences necessitate careful diagnostic strategies to ensure accurate interpretation of catalytic performance. A classic example of this phenomenon is n-heptane isomerization over Pt/zeolite catalysts, where reactivity is influenced by the proximity of metal and acid sites.45 The reaction sequence involves the formation of linear heptenes (nH=) as a mixture of equilibrated regioisomers from n-heptane dehydrogenation on Pt sites. These nH= species subsequently undergo isomerization at acid sites to form 2-methylhexenes (2MH=) and 3-methylhexenes (3MH=), which can further isomerize into dimethylpentenes (DMP=) (Fig. 4A). The DMP= isomers act as the precursors to β-scission products.45 Iglesia and co-workers demonstrated that the selectivity toward β-scission products increases with increasing distance between metal and acid sites, highlighting the role of site-proximity on product selectivity.45 Specifically, by dispersing Pt nanoparticles within zeolite crystals thus by increasing the intracrystalline Pt–H+ distance (via decreasing Pt loading), they observed higher n-heptane conversion turnover rates (per H+ site) and shifts in β-scission selectivity. To assess these transport effects on rates and selectivities, Iglesia and coworkers applied mathematical diffusion–reaction formalisms that account for intracrystalline gradients in reactant and product concentrations and for the local equilibration of alkene interconversion steps.45,46 These descriptions were then embedded within a plug-flow convection-reaction formalisms to describe the distribution of products formed as concentration gradients developed within crystallites and along the packed-bed reactor. This rigorous diffusion-convection-reaction analysis (Fig. 4B) linked the product selectivities to Thiele moduli, ultimately revealing that intrinsic selectivities were largely governed by diffusion-enhanced secondary reactions (Fig. 4C). These insights underscore the critical interplay between transport limitations and reaction kinetics in tandem/cascading systems. We emphasize that such analytical frameworks are equally critical for deciphering transport artifacts and the mechanistic intricacies involved in tandem CO2 hydrogenation.
![]() | ||
Fig. 4 (A) Isomerization and β-scission reaction network for C7 alkenes on bifunctional physical mixtures of Brønsted acid catalyst and Pt/SiO2. Dashed boxes around isomers with the same degree of branching indicate facile interconversion and isomers treated as a kinetic lump. (B) Schematic depiction of the coupled diffusion–convection–reaction system for bifunctional isomerization and -scission cascades. Acid domains are represented by the inset solid rectangles, the catalyst bed is denoted by the surrounding dashed rectangle. Metal functions and acid sites (H+) are also displayed. (C) Selectivities to methyl hexenes (MH=), dimethyl pentenes (DMP=) and -scission products (C3= + C4=) as a function of Thiele modulus, observed by modulating intracrystalline Pt–H+ site distance by confining Pt in MFI. Adapted with permission from Hu, W. & Iglesia, E. et al.45 Copyright J. Catal. 2023. |
We note that, while evaluating the applicability of the Thiele modulus (ϕA) to tandem CO2 hydrogenation system, one may question its relevance given the relatively small size of key intermediates, CH3OH, unlike bulky intermediates encountered in alkane isomerization (e.g., n-heptene). Notably, the first step of CH3OH synthesis over metal oxide catalyst can be operated in kinetic regime without mass transport limitation.54 Additionally, for the initiation step of MTH conversion, intermediate CH3OH have smaller kinetic diameter (3.6 Å)55 than typically used zeolite pore size (3.8 Å for CHA, 3.8 Å for AFX, 8.35, 4.8 Å for LEV, 5.6 Å for MFI),56 therefore, CH3OH transport in zeolite pores should not be diffusion limited (assuming negligible external mass transport effects). However, the propagation and termination sequences during MTH are mediated by active chain carriers (e.g., dienes, branched olefins, aromatics etc.), which are transport-limited to varying extents depending on zeolite morphology, pore structure, and crystal size.57,58 The presence of these species and their mass transport limitations impose spatial gradients during MTH on both bed and zeolite crystallite scales, complicating the interpretation of HC selectivity solely based on intrinsic kinetics.57 In such scenarios, the observed volumetric formation rate for bulkier HC (CmHn), robs, CmHn, includes contributions from the intrinsic volumetric rates (rint,p) for a reaction p (i.e., aromatic dealkylation, olefin methylation etc.) in the absence of mass transport limitations and an overall effectiveness factor (ηp) that quantitatively assesses diffusional constraints.57
![]() | (6) |
![]() | (7) |
![]() | ||
Fig. 5 (A) Instantaneous ethylene and 2MB (2-methylbutane, 2-methyl-2-butene) selectivity, ethylene-to-2MB ratio versus![]() |
For small cage zeolite with CHA framework, the influence of diffusional constraints was reflected on catalyst lifetime, assessed in terms of cumulative turnover number (TON), where the total turnovers decreased with increasing diffusional constraints regulated by see (Fig. 5B).41,58 Additionally, reaction-transport analysis of the MTO reaction network over SAPO-34 revealed that the effect of diffusional constraints on total turnovers was caused by dehydrocyclization reactions, which experience stronger diffusional constraints than olefins methylation, methanol transfer hydrogenation, and aromatics dealkylation.58
We note that the diffusional influence on HC product selectivity can further be probed by employing zeolites with varying undulation factor (Ω), which represent the ratio of the maximum diameter HC that can diffuse from zeolite pore to that which can be occluded. Such techniques were utilized to probe diffusional effect on alkene oligomerization and β-scission.53 Iglesia and coworkers revealed that both 1-D 10 membered-ring (MR) TON and mesoporous Al-MCM-41 mitigated β-scission reactions having less diffusional effect (Ω∼1) while zeolites with smaller undulation factor, like MFI and FAU, had broad product distributions, including significant amounts of β-scission products due to diffusion limitation (Fig. 6).60 As such, using zeolites with different undulation factor during CO2 hydrogenation can provide valuable mechanistic insights by distinguishing between primary, secondary and diffusion enhanced reaction pathways.
![]() | ||
Fig. 6 Selectivity to oligomers (i.e., not β-scission products) as a function of the diffusion pathway in zeolites. The undulation factor is defined as the ratio of the largest cavity to pore-limiting diameters. Adapted with permission from Sarazen, M. L. et al.60 Copyright ACS Catal. 2016. |
![]() | ||
Fig. 7 Gibbs free energy changes at different temperatures for CH3OH synthesis from CO2 hydrogenation, CO2 to lower olefins (ethylene), CO2 to aromatics (toluene), and the reverse water-gas shift reaction. Simulated conditions for equilibrium CO2 conversion: H2/CO2 = 3, total pressure 4 MPa. Adapted with permission from Jones and coworkers.64 Copyright J. CO2. Util. 2021. |
The hydrogenation of CO2 to CH3OH is typically performed by catalysts consisting of copper and zinc (Cu/ZnO/Al2O3), and the reaction is commonly reported to proceed via formate and methoxy intermediates.73–75 However, the formate species can also undergo decomposition to produce CO.76,77 Based on these insights, we infer that the stabilization of methoxy species can potentially enhance CH3OH selectivity. A standout report in this context is the recent work by Copéret and coworkers where they incorporated Lewis acidic surface sites at the periphery of Cu to stabilize methoxy intermediates, thereby improving CH3OH selectivity by employing surface organometallic chemistry (SOMC) approach.47 The authors synthesized a series of analogous catalysts containing Cu nanoparticles supported on SiO2 decorated with metal centers of different Lewis acid strength (Cu/M@SiO2, where M = Ti, Zr, Hf, Nb, Ta).47 In this process, first, isolated M sites, free of organic ligands, were generated on SiO2 by grafting a molecular precursor, e.g., M(OSi(OtBu)3)m(OiPr)n, followed by thermal treatment under vacuum to remove organic ligands (Fig. 8A). In the second step (Fig. 8B), Cu nanoparticles were generated on M@SiO2 materials by grafting the copper precursor, [Cu(OtBu)]4 onto these M@SiO2 materials, followed by a reductive thermal treatment. Interestingly, their investigation revealed that while CO formation rates (Fig. 8C) on these materials were nearly identical, CH3OH formation rates varied as a function of the identity of the M atom. The authors demonstrated that the promotion of CH3OH formation rates reflect the increasing acid strength of metal centers in SiO2 support, probed by measuring 13C chemical shift of methoxy surface intermediates from solid-state NMR (Fig. 8D) and pyridine adsorption enthalpies (Fig. 8E). These findings corroborated that the Lewis acid M sites of these catalysts stabilize surface intermediates (formate and methoxy) at the periphery of Cu nanoparticles and influence CH3OH formation rates.47
![]() | ||
Fig. 8 Surface organometallic chemistry (SOMC) approach of catalyst synthesis. (A) Isolated M sites, free of organic ligands, were generated on SiO2 by grafting a molecular precursor, e.g., M(OSi(OtBu)3)m(OiPr)n, followed by thermal treatment under vacuum to remove organic ligands. (B) Cu nanoparticles were generated on M@SiO2 materials by grafting the copper precursor, [Cu(OtBu)]4 onto these M@SiO2 materials, followed by a reductive thermal treatment. (C) Formation rate of CH3OH and CO over different Cu/M@SiO2 catalyst. (D) 13C solid-state NMR of formate and methoxy groups over different Cu/M@SiO2 catalyst. (E) 13C chemical shift of methoxy surface intermediates from solid-state NMR plotted against pyridine adsorption enthalpies to probe Lewis acid strength. Adapted with permission from Copéret and coworkers.47 Copyright Angew. Chem. 2021. |
In a similar SOMC approach, Copéret and coworkers showed that CuGax alloy formed by grafting Cu on silica containing GaIII sites was highly active and selective for CO2 hydrogenation to CH3OH (∼90% selectivity at a conversion of ∼3%).48 Their investigation reported that under reaction conditions, the silica-supported CuGax de-alloys yielding Cu nanoparticles and GaIII sites, which likely increased interfacial area between Cu0 and GaIIIOx promoting CH3OH formation. Interestingly, only methoxy surface species were observed as intermediates probed via NMR and IR spectroscopy.48 These findings highlight that stabilizing surface intermediates can improve CH3OH yields, offering a potential strategy to increase hydrocarbon yields during tandem CO2 hydrogenation.
Despite advances in bifunctional catalyst design, high CO selectivity remains an intrinsic challenge in CO2 hydrogenation. While CO is often considered an undesired byproduct, recent insights from MTH chemistry suggest that it may play an active role in tuning HCP. Bhan and coworkers demonstrated that CO is mechanistically relevant in increasing ethylene-to-propylene (1.5–3×) and ethylene-to-methylbutenes (1.7×) ratio, both of which indicate a shift in the relative propagation of the aromatic to olefin cycle.78 Additionally, CO can participate in Koch carbonylation reactions with DME, promoting aromatic-cycle propagation and enabling ethylene formation via methyl acetate intermediates.41 Despite these insights, the influence of CO in HCP and HC product selectivity in CO2 hydrogenation remain largely unexplored, warranting the need for targeted investigations into how CO can be leveraged as a potential tuning parameter for HC selectivity.
Regarding the influence of H2 on hydrocarbon selectivity, our recent study has shown that during CO2 hydrogenation, the presence of H2 promotes olefin cycle propagation over the aromatic cycle by facilitating secondary hydrogenation of olefins to paraffins.38 This suppresses olefin aromatization and the formation of deactivation-inducing polycyclic aromatics, thereby mitigating the deactivation of acid function, which is an advantage compared to MTH conversion where zeolites deactivate via coking.79 However, we anticipate that this may also present a stability-selectivity tradeoff, as the suppression of olefin aromatization will likely reduce aromatic selectivity during CO2 hydrogenation to aromatics. Therefore, a detailed understanding of the role of H2 on HCP is essential for optimizing targeted hydrocarbon selectivity.
The composition of zeolites also plays a critical role in shaping HCP and influencing HC selectivity. In this context, our recent study examined the impact BAS strength within the chabazite (CHA) framework on olefin selectivity during CO2 hydrogenation by employing aluminosilicate SSZ-13 and silicoaluminophosphate SAPO-34, both possessing similar acid site densities.38 When integrated as an interpellet admixture with In2O3, SSZ-13 predominantly facilitated secondary hydrogenation of olefins, yielding ∼93% paraffins. In contrast, the In2O3/SAPO-34 admixture produced ∼67% olefins, as the weaker acid strength of SAPO-34 resulted in a lower degree of secondary hydrogenation.38 These findings underscore acid site strength as a crucial parameter for regulating HCP composition and hydrocarbon selectivity. We note that beyond acid strength, acid site density (represented by the Si/Al ratio), also influences HCP dynamics. In this regard, Chen et al. investigated SSZ-13 with varying Si/Al ratios integrated with ZnZrOx and demonstrated that SSZ-13 with only isolated acid sites (i.e., high Si/Al ratio ∼125) effectively mitigated the over-hydrogenation of light olefins to alkanes, thereby enhancing light olefin selectivity (∼89%) compared to lower Si/Al ratio (∼9, yielded ∼93% paraffins) counterpart.28 These findings highlight the tunability of zeolite acidity as a powerful tool for modulating HCP composition and optimizing hydrocarbon selectivity during CO2 hydrogenation.
![]() | ||
Fig. 9 Schematic of two possible mechanism of SSIE. Top scheme: NaCl molecule diffuse, bottom scheme: Na+ and Cl− counter diffuse. Adapted with permission from Karge, H. G.92 Copyright Catal. Today 2008. |
In this regard, previous studies suggested that for medium-pore zeolite ferrierite, H-FER, SSIE was not observed with LaCl3 as LaCl3 molecule was too bulky to be able to penetrate the 8 MR pore openings of H-FER.90–93 This indicates that the mechanism of molecular diffusion is more likely to hold. This assumption was further supported by experiments of SSIE of H-ZSM-5 with molecules containing bulky anions (e.g., salts of heteropoly acids such as Cs3[PW12O40]).90–93 Compared to the exchange CsCl, SSIE with Cs3[PW12O40] occurred only to a minor extent, due to partial decomposition of the salt. These studies suggested that the molecules did not dissociate but rather migrated as an intact species for SSIE (top scheme of Fig. 6).
![]() | ||
Fig. 10 Factors affecting SSIE including volatility-driven gasphase transport (adapted with permission from Redekop, E. A. et al.98), contact-induced migration (adapted with permission from Wang, Y. et al.17 Copyright Angew. Chem. Int. Ed. Engl. 2021), reduction-assisted SSIE (adapted with permission from Mahnaz, F. et al.82 Copyright Chem. Catal. 2024), and moisture-assisted SSIE. |
Contact-induced SSIE can be assessed by varying the proximity between redox and acid sites, as evidenced by our recent study showing that despite ZnO being highly volatile, SSIE was less prominent when ZnZrOX was integrated at a microscale distance from BAS of SAPO-34 compared to a nanoscale distance, indicating contact-induced diffusion as the dominant mechanism.82 In such cases, core–shell confinement strategies to create diffusive barriers (e.g., silicalite-1, silica, or alumina) between redox and acid sites can potentially mitigate SSIE.100
Additionally, SSIE can be enhanced under reductive conditions, as observed in our studies where SSIE between BAS of SAPO-34 and Inδ+ was more drastic in the presence of H2, as compared to inert environment.82 Moisture may also facilitate SSIE by stabilizing cations, similar to conventional ion exchange process.92,101,102 In certain cases, moisture aids SSIE by disaggregating oxide species or inhibiting their polymerization. For instance, moisture facilitated the SSIE of acid sites in Y-zeolites with MoO3,84 whereas in dry conditions, the MoO3 species were too bulky to effectively undergo SSIE.103 In such cases, employing hydrophobic coatings on metal oxides or zeolites could be a potential strategy to limit the interactions between BAS and oxide species, limiting excessive SSIE.100 By systematically probing these factors, a more robust framework for suppressing SSIE could be developed, preserving the reactivity of oxide/zeolite bifunctional catalysts.
Beyond the effects of active-site proximity and intermediate transport, we emphasize on understanding the implications of SSIE of acid sites on rates and HC selectivities and strategies to mitigate it. While conventional acid site characterization methods can detect ion exchange, we propose utilizing useful metrics, such as the propylene-to-ethylene, ethylene-to-2 methyl-butane, paraffin-to-olefin ratios etc., to get better insights into how SSIE influences HCP mechanisms, altering HC selectivities.
A significant challenge in CO2 hydrogenation is the high CO selectivity caused by the RWGS as a side reaction. To tackle this challenge, we emphasize increasing CH3OH yields. An example is innovative synthesis techniques utilizing surface organometallic chemistry (SOMC) techniques to synthesize catalysts that favor high CH3OH selectivity to increase HC yield.
To summarize, a comprehensive understanding of proximity effects, intermediate transport, active site interactions, and their influence on measured reaction rates and selectivities is paramount for advancing CO2 hydrogenation chemistry. Careful interpretation of these phenomena will continue to be strengthened by increasingly advanced experimental and computational techniques. However, without a strong grasp of these concepts, a lack of comprehension could lead to misleading interpretations. Addressing these fundamental challenges is crucial not only for CO2 hydrogenation chemistry but also for similar sustainable process, such as lignocellulosic biomass conversion, or catalytic upcycling of plastics, both of which contain macromolecules where diffusion constraints and catalyst design remain a critical factor in the production of sustainable fuels and chemicals.
