Förster resonance energy transfer within the neomycin aptamer

Abstract

Förster resonance energy transfer (FRET) measurements between two dyes is a powerful method to interrogate both structure and dynamics of biopolymers. The intensity of a fluorescence signal in a FRET measurement is dependent on both the distance and the relative orientation of the dyes. The latter can at the same time both complicate the analysis and give more detailed information. Here we present a detailed spectroscopic study of the energy transfer between the rigid FRET labels Ç_m^f (donor) and tC_nitro (quencher/acceptor) within the neomycin aptamer N1. The energy transfer originates from multiple emitting states of the donor and occurs on a low picosecond to nanosecond time-scale. To fully characterize the energy transfer, ultrafast transient absorption measurements were performed in conjunction with static fluorescence and time-correlated single photon counting (TCSPC) measurements, showing a clear distance dependence of both signal intensity and lifetime. Using a known NMR structure of the ligand-bound neomycin aptamer, the distance between the two labels was used to estimate κ² and, therefore, make qualitative statements about the change in orientation after ligand binding with unprecedented temporal and spatial resolution. The advantages and potential applications of absorption-based methods using rigid labels for the characterization of FRET processes are discussed.

---

Introduction

Ribonucleic acids (RNAs) play a central role in cellular regulation such as transcription, translation and gene expression.¹ This includes functional non-coding RNAs, such as riboswitches that often target the 5′-untranslated regions of bacterial mRNA.² A riboswitch contains two interacting domains, an aptamer region that binds with high affinity and specificity to a metabolite and the expression platform.^3–5 These two domains act in concert to activate or repress gene expression through a conformational change that is triggered by ligand binding.^2,6–9

RNA aptamers can be readily generated by the technique of systematic evolution of ligands by exponential enrichment (SELEX)^10–13 and have found use as diagnostic agents,^14,15 biosensors,^16,17 and therapeutics.^18–20 It is of great interest to create artificial riboswitches for regulation of gene expression using ligands of choice, but only a few RNA aptamers have been utilized for creating non-natural riboswitches.^6,7,21–23 Increased understanding of the structure–function relationships of aptamers and riboswitches is required to be able to purposefully design new functional riboswitches.^24–26

Of the several methods that have been established for studying the structure and dynamics of RNA, fluorescence spectroscopy is particularly valuable.^27,28 It has the advantages of being highly sensitive, nondestructive for the sample of interest and offers the ability to conduct experiments under native conditions. It is a very useful tool to detect the dynamics of biomolecules through various approaches. In addition to unraveling detailed information about RNA dynamics, fluorescence spectroscopy is a powerful method to study structure, even of single molecules, through Förster resonance energy transfer (FRET). This high-resolution fluorescence technique can obtain information about both distance and relative orientation of FRET pairs.^29–33

The relative orientation between the donor and the acceptor is described with κ², which is not easy to determine. For free moving labels a κ² of 2/3 is usually assumed, which is valid in the dynamic isotropic regime.³⁴ However, this assumption is in many cases insufficient,^30,35–39 especially for rigid FRET pairs, where this assumption is considered invalid.^35,40 On the flip side, rigid FRET labels can provide more structural details through interrogation of the relative orientation of the dyes.

The structural elements of nucleic acids provide a good framework for rigid labels, in particular when the labels are nucleobase analogues. When embedded in helical regions, they provide accurate distance measurements and the possibility to study relative orientations.⁴¹

We have previously prepared and evaluated the fluorescent nucleobase analogue Ç_m^f (Fig. 1b), which forms a base pair with guanine, as a fluorescent probe for RNA.⁴² It was shown that Ç_m^f does not perturb the structure of RNA duplexes and that it is highly sensitive to its microenvironment. Moreover, it was used to study ligand binding by the neomycin aptamer.

Fig. 1 (a) Secondary structure of the N1-aptamer in its free state (left) and when bound to its ligand (right).⁴⁴ (b) Structure of the rigid labels Ç_m^f and tC_nitro.

Interestingly, the fluorescent label Ç_m^f has multiple emitting states. This makes Ç_m^f even more interesting as a donor in FRET-studies, since the energy transfer can take place from multiple states.⁴³

Here we present a detailed spectroscopic study of the energy transfer between the rigid labels Ç_m^f (donor) and tC_nitro (quencher/acceptor) (Fig. 1b) inside the neomycin aptamer N1 (Fig. 1a). The neomycin aptamer was chosen because both its structure and dynamics have been well studied and because this aptamer is one of the few aptamers that functions as an active riboswitch.^{6,26,42,44–46} We found that the energy transfer between Ç_m^f and tC_nitro extends over several orders of magnitude, from nanoseconds to the low picosecond range. This required application of different methods, to adequately describe the energy transfer over this large time-range. In general, static fluorescence measurements can be used to determine whether FRET occurs and on what time scale. Once this is known, it can be decided whether TCSPC or TAS is suitable to obtain temporal information about the energy transfer, depending on how fast the process proceeds.

By combining different spectroscopic and data evaluation methods, we provide new approaches to gain a deeper understanding of the distance and orientation dependence of rigid labels in RNA, specifically to precisely determine structural changes with unprecedented temporal and spatial resolution, even at donor–acceptor distances below 2 nm.

Results & discussion

Preparation of oligonucleotides/labeling strategy

We have previously labeled the N1-aptamer at positions C6, U8 and U15 with Ç_m^f to study the kinetics of ligand binding.⁴² Since the label was well accommodated in these positions, we used the same labeling strategy for Ç_m^f in this FRET study and chose the C3 position for tC_nitro. Thus, this labeling strategy yielded three different samples, N1-tC_nitro3-Ç^f_m6, N1-tC_nitro3-Ç^f_m8 and N1-tC_nitro3-Ç^f_m15 (N-N3C6, N-N3C8 and N-N3C15, respectively) (Fig. 2), with increasing distance between donor and acceptor in this order.

Fig. 2 Positions of the donor (Ç_m^f) and acceptor (tC_nitro) within the N1-aptamer, outlined in PDBID:2KXM(NDB/PDB).⁴⁴Ç_m^f is highlighted in blue and tC_nitro in red. The ligand neomycin is shown in black. Donor acceptor distances (center to center) from the modified NMR structure indicated on the side of the samples and the K_D values are shown below.

To investigate the binding capabilities of the doubly labeled aptamers, we initially performed ITC experiments (ESI,† Fig. S1). The dissociation constants of the doubly labeled aptamers are generally larger than the K_Ds of the unlabeled aptamer (ESI,† Table S1). However, the K_Ds of the doubly- and singly-labeled aptamers are in the same order of magnitude.⁴² This demonstrates that the incorporation of tC_nitro as a second label does not significantly affect the binding capabilities to the ligand.

FRET: data collection and analysis. The donor and the acceptor used in this study were covalently linked to the backbone of the N1-aptamer and thus, both the distance (r) and the relative orientation of the transition dipole moments determine the efficiency of the FRET process. Since tC_nitro acts as an efficient quencher, the fluorescence signal originates exclusively from the Ç_m^f chromophore, which greatly simplifies the evaluation of the FRET data. We began by investigating the static fluorescence behavior.

Static FRET characterization

The singly Ç_m^f-labeled N1-aptamers N-C6, N-C8 and N-C15,⁴² have previously been shown to have slightly different fluorescence intensity, due to the different flanking bases of Ç_m^f (Fig. 3a).⁴² Upon ligand binding, the microenvironment of the Ç_m^f changed, leading to an increased fluorescence signal for N-C6, N-C8 and to a decrease for N-C15.⁴² For the doubly-labeled aptamers (N-N3C6, N-N3C8 and N-N3C15), all signal intensities were significantly lower than the singly Ç_m^f-labeled aptamers (Fig. 3b). Moreover, the fluorescence signals show a clear correlation with the distance between donor and acceptor: It is almost completely quenched for the shortest distance (N-N3C6), but the signals get stronger as the chromophores are further apart.

Fig. 3 Time-integrated fluorescence spectra of (a) Ç_m^f labeled neomycin aptamers published by Gustman et al.⁴² (b) Ç_m^f and tC_nitro labeled neomycin aptamers. The fluorescence spectra of the aptamers without neomycin (− Neo) are shown as a segmented line.

Ligand binding only resulted in a minor change in fluorescence for both N-N3C6 and N-N3C15. In contrast a large relative change was observed for N-N3C8, which was even larger than for the singly labeled aptamer N-C8.

For a quantitative analysis, the FRET efficiencies can be calculated. The reduction of the FRET efficiency (E) is dominated by the donor–acceptor distance, but also the relative orientation of the transition dipole moments (eqn (1)):

Here, R₀ (eqn (2)) corresponds to the Förster radius, r to the distance between donor and acceptor, τ_D to the fluorescence lifetime of the donor alone and k_FRET(r) (eqn (3)) to the transfer rate.

The relative orientation between the transition dipole moments of the donor and acceptor is described by κ² (eqn (4)). Here, J_DA is the overlap integral between the emission spectrum of the donor and the absorption spectrum of the acceptor, n corresponds to the refractive index of the solvent and φ_D to the fluorescence quantum yield of the donor.³⁰

κ² = (sin θ_Dsin θ_Acos ϕ − 2 cos θ_D cos θ_A)² (4)

The static FRET efficiencies (E_sta) can be determined using the integrated donor fluorescence signal of the donor only (I_D) and the doubly labeled (I_DA) aptamers (eqn (5), Table 1). The Förster radii R_0,sta for the FRET pair labeled aptamers were determined by use of these estimated distances between donor and acceptor (Fig. 2, eqn 1 and Table 1).

Table 1 Experimentally determined static FRET efficiencies E_sta for the doubly labeled N1-aptamers (eqn (5)), donor–acceptor distances from the NMR structure r_DA and calculated Förster radii R_0,sta (eqn (1)). Values given in percent and Ångström, respectively

	Neo	E sta [%]	r DA [Å]	R 0,sta [Å]
N-N3C6	−	99.1	12.3	26.8
	+	98.2		23.8
N-N3C8	−	97.1	20.1	36.1
	+	83.5		26.3
N-N3C15	−	61.9	24.6	26.6
	+	64.0		27.0

---

Overall, high static FRET efficiencies (E_sta) were obtained for all samples (Table 1). The most drastic change of E_sta upon ligand binding can be seen for N-N3C8 (14%). For N-N3C6 and N-N3C15, the FRET efficiencies change by only 1% and 2%, respectively. The absolute FRET efficiencies, as well as their change due to ligand binding, are strongly dependent on the distance and κ² (see below). Since the largest flexibility is expected at position 8, it is reasonable that the actual distance between donor and acceptor for the aptamer without ligand is different from the modelled one. Moreover, the comparatively large Förster radius for N-N3C8 (− Neo) could also suggest a more favorable orientation between donor and acceptor for the energy transfer (eqn (1) and (2)).

Time-resolved FRET characterization

In conjunction with the static experiments, it is essential to characterize the energy transfer by time-resolved fluorescence measurements. Time-resolved FRET efficiencies (E_trf) can be obtained by measuring the respective amplitude weighted averaged fluorescence lifetimes τ_D and τ_DA (eqn (6), Table 2).³⁰

Table 2 Amplitude weighted averaged fluorescence lifetimes of the donor alone (τ_D), the measured fluorescence lifetimes of the donor in presence of the acceptor (τ_DA), the time-resolved FRET efficiencies E_trf (eqn (6)) and the calculated Förster radii R_0,trf (eqn (1))

	Neo	τ D [ns]^42	τ DA [ns]^a	E trf [%]	R 0,trf [Å]
a Amplitude weighted averaged fluorescence lifetime for the time-resolved fluorescence signals from Fig. 4.
N-N3C6	−	4.06	0.02	99.5	29.2
	+	4.97	0.12	97.5	22.6
N-N3C8	−	4.14	0.30	92.8	30.7
	+	3.73	1.09	70.7	23.3
N-N3C15	−	4.35	1.42	67.3	27.7
	+	5.96	1.64	72.6	28.9

---

Time-correlated single photon counting (TCSPC) and E_trf

We performed TCSPC measurements to monitor the fluorescence decay of the doubly labeled aptamers and to determine the corresponding fluorescence lifetimes.

Similarly to the static fluorescence measurements, the time-resolved fluorescence data (Fig. 4) show a faster decay of the fluorescent state compared to the singly labeled aptamers.⁴²

Fig. 4 Time-resolved fluorescence signals for N-N3C6, N-N3C8 and N-N3C15 (−/+ Neo). Data points are shown as dots, the fits are shown as solid lines.

Fitting the data with two respectively three exponential functions results in the averaged fluorescence lifetimes shown in Table 2 (τ_D, τ_DA, for further information see ESI,† Table S2).⁴² It should be noted that the fast decays from N-N3C6 (−/+ Neo) and N-N3C8 (− Neo) were deconvoluted from the IRF (Instrument response function) of the used spectrometer.

Using the averaged fluorescence lifetimes of the donor in presence of the acceptor (τ_DA) and the donor alone (τ_D),⁴² the time-resolved FRET efficiencies E_trf can be derived mathematically using eqn (6) (Table 2).^30,47 The efficiencies from the static measurements (E_sta, Table 1) are in good agreement with those from the time-resolved measurements (E_trf), within an error of roughly 10%.

The energy transfer rate k_FRET,sta(r) was subsequently calculated from the donor fluorescence lifetime τ_D and the static FRET efficiencies E_sta, using eqn (1). The reciprocal of this transfer rate, τ_FRET,sta (in ns), indicates the time scale in which the energy transfer predominantly takes place. Likewise, the FRET efficiencies (E_trf), determined by TCSPC, yielded k_FRET,trf(r) and τ_FRET,trf. The transfer-rates and -times from the static and the time-resolved measurements are in good agreement (Table 3).

Table 3 Calculated transfer rates by static and time-resolved fluorescence measurements (k_FRET,sta(r) and k_FRET,trf(r)) and the respective FRET times given in ns (τ_FRET,sta and τ_FRET,trf)

	Neo	k FRET,sta(r) [ns^−1]^a	τFRET,sta [ns]^b	k FRET,trf(r) [ns^−1]^a	τ FRET,trf [ns]^b
a Determined transfer rates for the energy transfer using eqn (1) and the FRET efficiencies Esta from Table 1 or Etrf from Table 2. b Reciprocal of kFRET,sta(r) and kFRET,trf(r) correspond to the FRET time given in ns.
N-N3C6	−	27.06	0.04	45.63	0.02
	+	10.94	0.09	7.85	0.13
N-N3C8	−	8.20	0.16	3.11	0.32
	+	1.36	0.74	0.65	1.54
N-N3C15	−	0.37	2.68	0.47	2.11
	+	0.30	3.35	0.44	2.25

---

For high static FRET efficiencies (E_sta), when the fluorescence of Ç_m^f in the doubly labeled samples is strongly quenched, it is possible that the weak signals can be distorted by signals from impurities or detector noise. For high time-resolved FRET efficiencies (E_trf, determined by TCSPC), the fluorescence lifetimes were so short that they had to be deconvoluted from the IRF. The fact that FRET takes place in the picosecond time-range (e.g. for N-N3C6, Table 3), shows that both experimental methods are at their limits, although the derived FRET times are similar with both methods. The dependence of the FRET times on the distance between the FRET pairs is also evident. However, we decided to examine the energy transfer more closely with femtosecond transient absorption experiments in order to resolve the FRET process for the high FRET rates.

Ultrafast FRET dynamics

Ultrafast measurements were performed to characterize energy transfer processes that are at the edge of the time-resolution limit of the TCSPC setup. This is especially important for the N-N3C6 and N-N3C8 samples, both of which have high FRET efficiencies and thus ultrafast FRET dynamics. The transient absorption data (Fig. 5) were fitted by global lifetime analysis (GLA) to obtain the lifetimes of the observed states.⁴⁸

Fig. 5 Transient absorptions maps (left) and decay associated spectra (DAS) (right), top to bottom N-N3, N-N3C6, N-N3C8 and N-N3C15: left column without neomycin, right column with neomycin. τ₂ for the decay of the directly excited tC_nitro is shown in violet, τ₃ for one emitting state of Ç_m^f is shown in orange, τ₄ for later emitting states is shown in red. For the samples N-N3 (−/+ Neo), N-N3C6 (−/+ Neo), and N-N3C8 (− Neo) an additional residual lifetime (inf.) is needed to fit the data properly (shown in brown).

The aptamer that was singly labeled with tC_nitro (N-N3) served as a control. tC_nitro shows a ground state absorption in the range of 350 to 550 nm.⁴¹ Therefore, a fraction of the acceptor is always directly excited at the same time as Ç_m^f, when irradiating at 388 nm. Upon excitation, tC_nitro shows an excited state difference absorption signal (ESA1_A) between 450 and 530 nm with a maximum at 505 nm and a second signal (ESA2_A) above 600 nm. The directly excited tC_nitro (−/+ Neo) decays with a lifetime of 5.1 and 3.8 ps, respectively. Due to the co-excitation, the dynamics of the directly excited acceptor are visible in all the measurements. The Ç_m^f donor shows similar excited state dynamics as the free chromophore, with several emitting states that decay with different lifetimes (Fig. 5).⁴³

Next to the transient absorption measurements (Fig. 5) are the corresponding decay associated spectra (DAS), along with the most importantant decay times. A positive signal for ESA1_D, between 410 to 490 nm, partially overlaps the signal of the directly excited tC_nitro. A second positive signal, between 590 and 650 nm, also overlaps the signal of the directly excited tC_nitro (ESA2_A/D).

For Ç_m^f, a negative signal is expected between the two ESA bands at 490 to 590 nm, which is assigned to the stimulated emission difference signal (SE_D). Due to the high FRET efficiency for N-N3C6 (− Neo) and the simultaneous overlap by the dynamics of the directly excited acceptor (ESA1_A & ESA2_A), the SE_D signal only contributes with a small amplitude to this measurement. However, for the other measurements, the stimulated emission is clearly identifiable.

The decay of the excited state of Ç_m^f in the FRET system follows an identical path for each sample; only the corresponding lifetimes are different (Table 4 and ESI,† Fig. S3). The decay occurs in a multi-exponential fashion. The smallest lifetime (τ₁) corresponds to an internal relaxation process after excitation, which leads to the formation of several emitting states.⁴³ The formation of the emitting states is described with τ₃ and τ₄, while the lifetime τ₂ describes the decay of the directly excited tC_nitro.

Table 4 Decay lifetimes derived from transient absorption measurements

	Neo	τ 1 [ps]	τ 2 [ps]	τ 3 [ps]	τ 4 [ps]
N-N3C6	−	0.5	3.1	14	380
	+	0.4	5.6	52	290
N-N3C8	−	0.7	4.7	110	1300
	+	0.3	3.9	160	1500
N-N3C15	−	0.3	5.2	840	3000
	+	0.3	4.3	350	1800

---

Comparing the lifetimes of the emitting states of Ç_m^f with k_FRET,trf(r), and consequently τ_FRET,trf (Table 3), shows that the τ_FRET,trf value is either closer to the lifetime τ₃ or τ₄. It can thus be deduced that, depending on the efficiency, FRET tends to occur predominantly from one of the first or the later emerging emitting states of Ç_m^f. However, it must be kept in mind that in all cases, energy transfer starts from the first emitting state, but since this state decays rapidly, the transfer progressively shifts towards a second state at lower efficiencies.

In the DAS of τ₃ and τ₄ of the individual transient absorption measurements (Fig. 5), a shoulder at 505 nm (ESA1_A) can be observed. When tC_nitro was directly excited, the excited state decayed within approximately 5 ps, indicating that the decay of tC_nitro in the FRET system occurs after the energy transfer. This shoulder is more recognizable in the normalized DAS of the emitting states (ESI,† Fig. S4) further supporting a FRET process from several emitting states.

To further analyze the ultrafast measurements, the transients at 428 nm (ESA1_D) and 505 nm (ESA1_A) were plotted (Fig. 6). The transients at 428 nm correspond to the decay of the excited state of the Ç_m^f. It is evident that the excited state of Ç_m^f is longer-lived at relative greater DA distances and therefore at lower FRET efficiencies.

Fig. 6 Transients of the samples N-N3 (black), N-N3C6 (blue), N-N3C8 (yellow) and N-N3C15 (pink) without (− Neo) and with neomycin (+ Neo). 428 nm corresponds to the wavelength of the excited state of Ç_m^f. 505 nm corresponds to the wavelength where tC_nitro shows its strongest signal.

The transients at 505 nm, associated with the decay of the excited state of tC_nitro, also include the SE_D signal of Ç_m^f. The transient of the directly excited tC_nitro (− Neo) (black) is almost identical to the transient of N-N3C8 (− Neo) (yellow). This also applies to the transients of the directly excited tC_nitro (+ Neo) and N-N3C6 (+ Neo) (blue). For these labeling positions, the FRET occurs after 50 ps, so the transient reflects the decay of the directly excited acceptor up to approximately 10 ps. The transient of N-N3C6 (− Neo) (blue) decays later than for N-N3 (− Neo), because of the superposition of the signal for both the directly excited tC_nitro and the excited tC_nitro after FRET, due to the high efficiency of the energy transfer. The transients of N-N3C8 (+ Neo) (yellow) and N-N3C15 (−/+ Neo) (pink) show a superposition of the positive signal of the directly excited tC_nitro and the negative signal of the stimulated emission of Ç_m^f. Thus, it appears that the signal of the directly excited acceptor decays faster. Taken together, the transients clearly elucidate the distance dependence of the energy transfer within the aptamer.

An averaged lifetime τ_DA(TAS) can also be derived from the transient absorption measurements, specifically using the amplitudes of the two DAS spectra (associated with τ₃ and τ₄) for the emitting states of Ç_m^f. The respective lifetimes were weighted by percentage according to their amplitudes to obtain τ_DA(TAS) (Table 5 and Table S3, ESI†). Despite small deviations, the averaged lifetimes are in good agreement with those obtained by the TCSPC.

Table 5 Averaged lifetimes of the donor in presence of the acceptor achieved by means of TAS experiments (τ_DA(TAS)), the FRET efficiencies derived from the TAS experiments (E_TAS), the time-resolved FRET efficiencies (E_trf), and the static FRET efficiencies (E_sta)

	Neo	τ DA(TAS) [ps]	E TAS [%]	E trf [%]	E sta [%]
a Averaged fluorescence lifetime obtained using the amplitudes in the respective DAS of the two observed emitting states for Çm^f (Fig. 5).
N-N3C6	−	110	97.3	99.5	99.1
	+	224	95.5	97.5	98.2
N-N3C8	−	411	90.1	92.8	97.1
	+	1032	72.3	70.7	83.5
N-N3C15	−	1427	67.2	67.3	61.9
	+	1475	75.3	72.6	64.0

---

With τ_DA(TAS) (Table 5) and τ_D (Table 2) the FRET efficiency can now be derived from the transient absorption measurements (E_TAS, Table 5). When comparing the FRET efficiencies derived from the three different methods, it can be seen that similar energy transfer efficiencies are obtained for all three.

Discussion of the label movement and orientation in the aptamer

The FRET efficiency (E) for the labeled aptamers can be experimentally determined, with steady state fluorescence, time-resolved fluorescence (TCSPC) or transient absorption experiments (Table 5). From eqn (1) and (2), it is obvious that E depends on the donor–acceptor distance (r_DA) and the relative orientation of the transition dipole moments (κ²). Therefore, it is not possible to determine this relative orientation, without independent knowledge about the distance r_DA and vice versa.^38,49

Nevertheless, the donor–acceptor distance r_DA can be extracted with reasonable accuracy (see Table 6) from the NMR structure of the ligand-bound N1-aptamer.⁴⁴ Thus the Förster radius R₀ and the orientation factor κ² can be calculated from E (Table 6; the time-resolved FRET efficiencies E_trf from Table 5 are used for the calculation).

Table 6 Donor–acceptor distances r_DA from the NMR structure, calculated Förster radi R_0,trf and κ² for the different samples. E_trf is used for the calculations

	Neo	r DA [Å]	R 0,trf [Å]	κ ^2
N-N3C6	−	12.3	29.2	0.40
	+		22.6	0.07
N-N3C8	−	20.1	30.7	0.49
	+		23.3	0.06
N-N3C15	−	24.6	27.7	0.29
	+		28.9	0.36

---

The three-dimensional structure of N1 without the ligand is not available and, therefore, it is not possible to calculate κ² from the distance r_DA for the FRET pair in this case. However, using eqn (1) and (2) and keeping E_trf constant, the distance r_DA can be plotted as a function of orientation κ² (Fig. 7). These value pairs result in the corresponding FRET efficiency (here E_trf, Table 5). For the ligand-bound aptamer the data from Table 6 is marked in Fig. 7 with crosses.

Fig. 7 Dependence of the distance between donor and acceptor (r_DA) on the orientation κ² for a given FRET efficiency (E_trf), areas marked in grey indicate the region of value pairs between r_DA and κ².

For N-N3C15, it is obvious that the resulting curves from the combinations between r_DA and κ² are almost identical in the absence and presence of the ligand (Fig. 7). This is in agreement with previous a EPR study in which the distance between positions 4 and 15 did not change upon ligand binding.⁵⁰ This indicates that the small changes in FRET efficiency could be due to a slight change in the relative orientation between donor and acceptor in the ligand-bound state.

Assuming the same behavior for N-N3C6 and N-N3C8, the corresponding values for κ² in the unbound state can be calculated (Table 6). Although the structure in the unbound state is unknown, the value pairs (r_DA and κ²) and the FRET curves (Fig. 7) for both forms of the aptamer can be used to construct areas (gray regions in Fig. 7) that reflect the range of motion of the labels relative to each other. The flexibility of the RNA is accounted for by the construction of the gray areas. This flexibility and the resulting slight differences in κ² lead to changes in the FRET efficiency. The gray areas take this into account, with the measured FRET efficiencies corresponding to the average FRET efficiencies in the ensemble.

Based on this analysis, neither distance nor orientation changes significantly for N-N3C15 upon ligand binding. For N-N3C6, a more significant change in both distance and orientation can be observed, which is in agreement with a previous NMR study.⁴⁶ The greatest range of changes is seen for N-N3C8, which is to be expected, because the Ç_m^f is located at the edge of the binding pocket where ligand binding should result the most pronounced movement. Therefore, our results are consistent with previous studies that have indicated that the N1-aptamer is already prefolded to a significant extent; the binding pocket conformation primarily adapts to the ligand, with little change in the rest of the aptamer.⁴²

Conclusions

We have presented a detailed spectroscopic study of the energy transfer process between Ç_m^f and tC_nitro using experimental methods that can address a range of time-scales. The FRET efficiency was determined for FRET times from about 20 ps to 3 ns (Table 3). While methods using steady state fluorescence (E_sta) and TCSPC (E_trf) are commonly used, the third method, transient absorption spectroscopy (E_TAS), allowed determination of fast FRET processes (e.g.N-N3C6) with appropriate time-resolution; even small changes at very high FRET efficiencies (and therefore very small distances) can be determined, for which TCSPC is not sensitive enough.

We were able to evaluate several emitting states for Ç_m^f and showed that the resulting FRET efficiencies, from the three methods that we used, E_sta, E_trf and E_TAS are identical within a range of 10%. It should be noticed that for the transient absorption method it is not necessary for the donor to be a strong-emitting fluorophore with high quantum yield, as for the evaluation, exclusively the absorption data is used. A lower quantum yield results in lower FRET efficiency and also makes TCSPC experiments difficult to perform, because the method depends on emitted photons. In the case presented here, TAS can be used to study the ultrafast (excited state) dynamics of the donor and the change in dynamics due to energy transfer.This extends the toolbox for the experimentalist.

We have shown that the FRET pair Ç_m^f and tC_nitro is highly efficient whereby the fluorescence of the donor can be almost completely quenched. However, as with other pairs, it is not possible to determine the exact distance and orientation for this pair from the FRET efficiency E alone. Using a known NMR structure of the ligand-bound N1-aptamer, a distance can be approximated to determine κ² and, therefore, make qualitative statements about the change in orientation after ligand binding.

It is clear that the normal approximation of κ² having the value of 2/3 is insufficient when rigid labels are incorporated. A distinct advantage of rigid labels is the possibility to reveal the dynamic binding behaviour of aptamers.

This study also highlights the importance of the photophysical properties of both the donor and the acceptor in a FRET pair. Ideally, the acceptor should fluoresce spectrally separately from the donor. This would enable measurements of the angle between donor and acceptor using anisotropy measurements.⁵¹ With the procedure described here, in particular using transient absorption experiments, the determination of the angle between donor and acceptor is also possible without fluorescence. This requires a different acceptor than tC_nitro, whose excited state lives longer and is spectrally separated from the signal of the excited state of the donor.
