Study and quantification of the enantiodiscrimination power of four polymeric chiral LLCs using NAD 2D-NMR

Abstract

Identifying and understanding the role of key molecular factors involved in the orientation/discrimination phenomena of analytes in polymer-based chiral liquid crystals (CLCs) are essential tasks for optimizing computational predictions (molecular dynamics simulation) of the existing orienting systems, as well as designing novel helically chiral polymers as new enantiodiscriminating aligning media. From this perspective, we propose to quantify and compare the enantiodiscrimination power of four homochiral polymer-based lyotropic liquid crystals (LLCs) toward a given chiral solute using their ²H residual quadrupolar couplings (²H-RQCs) measured by anisotropic natural abundance deuterium 2D-NMR (ANAD 2D-NMR). Two families of chiral polymers are investigated in this study: (i) poly-peptide polymers (PBLG and PCBLL), and (ii) polyacetylene polymers (PDA and L-MSP, a new system never published so far). As model solute, we investigate the case of camphor, an interesting rigid bicyclic chiral molecule possessing ten ²H-RQCs (10 inequivalent monodeurated isotopomers per enantiomer). In order to analyse the orientational behaviour of each enantiomer in a single oriented sample, while simplifying the identification of the (D/L)-isomer signals on spectra, a D-isomer enriched scalemic mixture (ee(D) = 30%) was used. Orientational data of camphor in each mesophase were calculated for the first time using the computer program ConArch⁺, modified to accept ²H-RQCs as anisotropic data input. Differences in enantiodiscriminations provided by the four aligning systems are examined and discussed in terms of structural and chemical features between polymers. The new L-MSP mesophase described in this work exhibits very promising enantiodiscrimination capacities.

---

1. Introduction

All data highlighting the factors/parameters involved in the molecular orientation processes and/or the chiral discrimination mechanisms (noted in short CDMs) in polymer-based lyotropic liquid crystals (LLCs) are key for three reasons: (i) to understand the molecular shape recognition phenomena in helical systems (polypeptide or other types of polymers) and their contribution to the global phenomenon;^1–8 (ii) to optimize the computer simulation of the solute orientational behavior, and the prediction of their anisotropic observables (by molecular dynamics, for example)^9–14 with the final aim of determining the absolute configuration of chiral molecules;^15,16 and (iii) to structurally design novel helically chiral polymers as new efficient enantio-discriminating aligning media.^17–22

Collecting these data experimentally by all possible anisotropic 1D/2D-NMR methods, in order to assess/quantify their respective roles/effects on the enantiodiscrimination properties, therefore deserves special attention.^22,24

In a recent work, we have qualitatively examined the enantiodiscriminating abilities of a polyacetylene-based chiral polymer (PLA) compared with the historical polypeptide-based polymer (PBLG), by screening a large collection of mono- (or per-)deuterated chiral analytes, covering several aspects of enantiomorphism.²¹ The ²H-NMR data based analysis pointed out that the enantiodiscriminating abilities (EDAs) of PLA were globally more efficient than those of PBLG, especially for chiral secondary alcohols (see the analysis presented in the ESI† (SI-I)), but also for an apolar solute such as 3-methylhexane, a very challenging chiral molecule.

A simple evaluation of EDAs of deuterated enantiomers (at a given site, as a stereogenic center) can be achieved by determining the local “differential ordering effect” (DOE factor) calculated as ΔΔν_Q(²H) over their mean values:^24,25

This DOE(²H) factor can be considered as a local quantification of the orientational deviation for a given site in the R/S isomers with the situation that would be observed in an achiral mesophase where no discrimination is possible.²⁵ As seen in Section SI (ESI†), in the case of a series of secondary chiral alcohols, it can be correlated with various molecular parameters such as the molecular shape anisotropy regarding the difference of the persistent volume substituents around the asymmetric carbon.^26–28

This local analysis can be extended to a more global evaluation by comparing the average molecular orientation of each enantiomer via their alignment tensors. This approach provides a more insightful and reliable comparison of EDAs. In practice, this description is achieved by calculating the molecular Saupe matrix of each enantiomer, {S_αβ}^R,S, derived from three types of NMR interactions:^22,23 (i) the residual chemical shift anisotropies (RCSAs);^29–32 (ii) the residual dipolar couplings (RDCs);^33–38 and (iii) the residual quadrupolar couplings (RQCs) of nuclei with spin quantum number I > ½ as deuterium (I = 1).^39,40 These matrices can be then compared by calculating the generalized 9D β angle (eqn (2)), or its cosine value (GCB value).^41,42

The generalized β angle or its cosine (β) (GCB value) can be used to quantity the efficiency of the enantiodiscrimination of a pair of enantiomers: the closer this GCB value is to 1, the closer the positions of the alignment tensor axes are in space. Conversely, the closer this value is to 0, the more the positions of the alignment tensor axes are different; this second situation corresponds to an optimum EDA.

In this article, we exploited the analytical potential of ²H-RQCs extracted from the Anisotropic Natural Abundance Deuterium 2D-NMR (ANAD 2D-NMR) spectra^22,23,43 to quantify the EDAs of two important families of enantiodiscriminating helical polymers: (i) two polyacetylene-based LLCs: (D)-valine-based polyacetylene, PDA (poly-1),^21,44 and L-serine-based polyacetylene, L-MSP (poly-2), reported for the first time in this work (synthesis described below and in the ESI†), and (ii) two polypeptide-based LLCs: poly-γ-benzyl-L-glutamate, PBLG (poly-3),^33–35,45 and poly-ε-carbobenzyloxy-L-lysine, PCBLL (poly-4) (see Fig. 1).⁴⁶

Fig. 1 (a) Structure of the four helical polymers investigated: PDA (poly-1), L-MSP (poly-2), PBLG (poly-3), PCBLL (poly-4). Note the difference in the position of the stereogenic center; (b) structure of (D)-(1R,4R)-(+)-camphor and (L)-(1S,4S)-(−)-camphor (5) including their atomic numbering; the red and blue colors are used for identifying them. All ¹H/²H NMR data related to the methyl, methylene (sp³) and methine (sp³) groups are identified by the green, pink and black colors, respectively.

The choice of these two polymer families (see Fig. 1a) is motivated by their common global characteristics such as their rod-like shape (persistence length ≫ persistence diameter), the helical structure of their scaffold and the complex conformational dynamics of their side chains. On the other hand, they are chemically different and possess notable structural differences such as the flexibility of their helical backbones or the position of their stereogenic centers (side chain versus backbone). In all cases, the complex array of analyte–polymer interactions for a given solute, and the chemically very different side chains (steric factors, electronic profiles, and positioning of functional groups relative to the helix) produce highly versatile orientational and discriminative “responses” to electrostatic contributions, to shape anisotropy and conformational behaviour of the solute. In practice, the subtle balances between all molecular factors involved makes it difficult to qualitatively or empirically establish an “overall” superiority of a given chiral polymer over another (polypeptide versus polyacetylene). However, given the current set of analytes, the polyacetylenes could appear to be superior in enantiodiscriminating capability.^21,44

Generally, all studies dedicated to the EDA are based on the analysis of (¹H–¹H)-RDCs and/or (¹³C–¹H)-RDCs of each isomer in two distinct ordered samples to avoid the peak overlaps met with a mixture of two enantiomers. Given the fact that ²H-RQCs are about a factor of ten larger than (¹³C–¹H)-RDCs, it becomes possible to analyze both enantiomers of a chiral analyte in the same oriented sample. In this work, a scalemic mixture (ee(D) = 30%) is used to simplify the identification of the (D/L)-isomer signals in the anisotropic NMR spectra. This strategy is advantageous for two reasons: (i) a single oriented NMR sample and a single set of NMR experiments is prepared and performed, respectively, and (ii) the orientational behavior of the enantiomers can be compared under strictly identical experimental conditions.

As a model analyte, we focus our attention on a small chiral bicyclic molecule, (D)-(1R,4R)-(+)-camphor and (L)-(1S,4S)-(−)-camphor (denoted as R-(5) and S-(5), respectively), NMR-spectroscopically well characterized,^47,48 for which the detection of ten pairs of monodeuterated enantiomeric isotopomers is expected (see Fig. 1b). In order to compare the EDAs of four chiral mesophases, the differences of intrafamily (e.g. polypeptide/polypeptide) and interfamily (e.g. polypeptide/polyacetylene), enantiomeric orientational behavior of camphor is examined and discussed.

Moreover, we also highlight the promising enantiodiscrimination capability of the new L-MSP orienting system in comparison to the three other chiral LLCs.

2. Theoretical considerations, NMR approach, and computational tool

Specificities of ANAD 2D-NMR

Despite the low receptivity of deuterons at natural abundance (∼1.5 × 10⁻²% with respect to ¹H), measuring ²H-RQCs on isotopically normal analytes is analytically relevant.^22,43 First, the ²H-RQCs are ten times more sensitive to an anisotropic environment as compared to (¹³C–¹H)-RDCs or even more so with ¹³C-RCSAs.⁴³ Second, the ²H spectral enantiodiscrimination in CLCs is easily revealed because two ²H quadrupolar doublets (²H-QDs) are observed with δ^aniso,S ≈ δ^aniso,R, with equal to^22,43where K_Di is the ²H quadrupolar coupling constant (150 to 300 kHz), assumed to be identical for R and S isomers, and S_C–Di is the local order parameter of the C–D_i bond.^22,43 High dynamics of analytes coupled with a low degree of orientation (S_C–Di = 10⁻² to 10⁻⁴) in polymer-based LLCs warrant ²H-RQC values varying from 0–1000 Hz and reasonable linewidths (<5–6 Hz).

From the local order parameters, , of various (noncolinear) internuclear C–D_i directions (r_C–Di), we can derive the Saupe matrix elements, S^S or R_αβ, expressed in an initial molecular axis system, IAS, (a, b, c)^S or R according to eqn (4):^22,43

where the terms, , are the director cosines of vectors, r_C–Di, in the IAS.

From an analytical point of view, any deuterons present at natural abundance can be detected with a reasonable amount (<50 mg) of chiral solute (with MW about 300 g mol⁻¹). The use of ²H cryogenic NMR probes is a valuable aid but is not necessary for low molecular weight compounds.⁴⁹ When the spectral analysis of enantiomers occurs in a scalemic mixture the preparation of two distinct samples can be avoided and the identification of the two enantiomers in QUOSY-type 2D experiments is unproblematic.^22,43 Moreover, this guarantees an easy assignment of the absolute configuration for all ²H-QDs observed, based on the difference of their respective peak intensities. Also, due to the dilute nature of NAD spin systems, the determination of ²H-RQC values for diastereotopic protons in methylene groups are not affected by second order effects as in the case of (¹³C–¹H)-RDCs (¹D_CH couplings) for which strong ¹H–¹H coupling effects can hamper their accurate determination.⁵⁰ However, even if the measurement of ²H-RQCs in CH₂ groups is direct and accurate, the determination of their signs requests the analysis of associated ¹H-coupled ¹³C signals whose structure is sometimes complex when both enantiomers are present in the sample. An adapted protocol to determine their signs, when a scalemic mixture is used, is discussed below.

Data analysis by ConArch⁺

So far, the recent exploitation of ²H-RQCs has been performed using the MSpin-RQC program,^51,52 a variant of MSpin, initially able to manage RDCs or RCSAs as input data.^30,53 In this work, another computational approach delivering orientational data of a solute has been explored, the ConArch⁺ (Configurational Architect) software package.^54,55

Like MSpin, the ConArch⁺ program computes the Saupe order parameters, S_αβ, (via an algorithm based on the principle of singular value decomposition (SVD)) in order to minimize the difference between the experimental values (²H-RQC^Exptl.) and the back-calculated values (²H-RQC^Calc.) from the order matrix for a given geometry. A schematic description of the operating principle of the ConArch⁺ program using ²H-RQC data is presented in Fig. S4 (ESI†).

Although not used in the current investigation, the main difference between ConArch⁺ and MSpin is the distance geometry module of the former.⁵⁶ The determination of the alignment or the Saupe tensor from RDCs or RQCs does not differ substantially in both programs. The decisive strength of ConArch⁺ is that it is able to let structures evolve under the influence of the NMR data. This means that ConArch⁺ does not rely on structural comparisons between precalculated structures (from DFT, for example) and measured data; it generates structures from the data.

Therefore, using a good data set, ConArch⁺ is able to determine correct relative configurations from an input structure of arbitrary configuration. This is possible because “wrong” configurations can change during a molecular dynamics simulation in 4D space with a pseudo-force field restraining only observables from NMR data and distance ranges from the constitution.^54–59

In the course of the investigation it turned out that it is not necessary to compute the ²H quadrupolar coupling constants, K_Di, (see eqn (3)) for each site. Instead, three selected values depending on the type of carbon hybridization were used for the computations, namely K_Di (C_sp³–D) = 170.0, K_Di (C_sp²–D) = 185.0 and K_Di (C_sp–D) = 210.0 kHz. DFT seems to overestimate the electric field gradients (EFGs) at the deuterium sites, so the computed EFGs are too large, but this is compensated by a downscaling of the corresponding alignment tensor. In total, there seems to be no or very little difference between the RQCs using the computed EFGs or the “default” quadrupolar coupling constants for the different hybridization modes (sp³, sp², and sp) of carbon atoms. Finally, the agreement between the values of Δν^Expt._Q and Δν^Calc._Q is evaluated by the well-known Cornilescu quality factor, Q,⁶⁰ or the root mean square deviation (RMSD) parameter (see eqn (S3) and (S4) in Section SII, ESI†).

3. Results and discussion

NAD specificities of camphor

Camphor (5) possesses two stereogenic centers of defined absolute configuration leading to ten non-equivalent hydrogenated (deuterated) sites and including eight diastereotopic positions associated with the three prochiral methylene groups and one pair of diastereotopic methyl groups. The remaining two sites are the methine proton at position 4 and the methyl group at position 1.

For a scalemic (or a racemic) mixture of 5 (see Tables in the ESI†), the maximum number of theoretically expected ²H-QDs to be observed on an ANAD 2D-NMR map is 20 when all non-equivalent positions in the enantiomers are spectrally differentiated by the chiral oriented phase.

Two typical examples of tilted/symmetrized ANAD 2D spectra (Q-resolved type) of 5 recorded in PDA and L-MSP (T_exp = 15 hours) are presented in Fig. 2a and b;^22,43,61 spectra obtained in the PBLG and PCBLL mesophases are given in Fig. S9 and S10 (ESI†). Whatever the mesophase used, the NAD signals of polymer and organic co-solvent (chloroform) do not interfere with the NAD signals of 5. Additionally, for each mesophase, the pairs of enantioisotopomers are spectrally discriminated, except for the site H_3ex in the PDA phase where two identical ²H-RQCs are measured (see Fig. 2a). Due to the modulated peak intensities associated with the ee(D), the identification of NAD signals belonging to the major (D) and the minor enantiomer (L) is direct and unambiguous. All ²H-QDs experimentally measured were exploited for the determination of orientational data.

Fig. 2 92.1 MHz NAD-{¹H} Q-resolved Fz 2D spectrum (tilted and symmetrized) of 5 (ee(D) = 30%) in (a) PDA/CHCl₃ phase and (b) L-MSP/CHCl₃, showing the assignment of ²H-QDs accordingly to atomic numbering see (figure 2) and the associated stereodescriptors for each pair of ²H-QDs assigned according to the difference of peak intensity between the major (D)- and minor (L)-enantiomer. In the central panel a magnification of the methyl region is displayed. The peak labelled with an asterisk is assigned to the NAD signal of ethanol added as a stabilizer of CHCl₃.

Analysis of methylene groups

Although the measurement of the ²H-RQC magnitude on ANAD tilted 2D-NMR spectra can be read directly on maps, the determination of their absolute signs remains unknown.²² Determination of the sign of ²H-RQCs relative to the heteronuclear (¹³C–²H)-RDCs, is possible using ²H Q.E.COSY 2D experiments,⁶² but for sensitivity reasons, this approach is difficult to achieve experimentally when applied to non-isotopically enriched molecules.⁶³ Another possibility could be to explore all possible combinations of signs for each inequivalent site, using a screening-protocol computational approach.⁵² Currently, the experimental approach used in this work consists in exploiting additional ¹³C data (¹T_CH) extracted from the analysis of simple proton-coupled 1D experiments (inverse gate/single pulse) with the help of heteronuclear (¹T_CH/2)- or (¹T_CH/4)-resolved heteronuclear 2D spectra (see Fig. S7 and S8, ESI†).²² The reason for using a phase-sensitive (¹T_CH/4)-resolved sequence is to simplify the signal multiplicity in the F₁ dimension by avoiding long-range ¹³C–¹H couplings, and thus ease the determination of ¹T_CH values. The combined analysis of ²H-RQC and one-bond (¹³C–¹H)-RDC data extracted from ²H–{¹H} and ¹³C spectra, respectively, is possible because the order parameter S_CH and S_CD (for a given site) can be assumed to be equal within variations of about 5%. Hence the Δν_Q(CD)/¹D(CH) ratio is independent of any order parameter, and is approximately equal to (for each enantiomer):⁶⁴

Depending on the ²H quadrupolar coupling constant, q_CD, and the inter-atomic distance C–H, a value of −11.5 is a good compromise to get an estimate of the magnitude of ¹D_CH (¹D^Estim._CH). Comparison of ¹D^Estim._CH and ¹D^Exptl._CH values (even approximatively evaluated) allows for a determination of the sign of ²H-RQCs. In the case of a scalemic mixture of enantiomers, the correlation between ²H-RQCs and ¹D_CH (¹D_CH = [¹T_CH − ¹J_CH]/2) for both CH and CH₃ groups is generally trivial. In contrast, the situation is generally more complex for CH₂ groups due to the inequivalence of diastereotopic positions, endo/exo, (leading to two pairs of ²H-QDs centered on two ²H chemical shifts), while enantiomers can be discriminated by the ¹³C-RCSA difference in the ¹³C spectra. In this case, we have to correlate the ²H-RQC data for each of the diastereotopic positions (endo or exo) with the (¹³C–¹H)-RDC data for each enantio-isotopomer (L or D).

Fig. 3 depicts the schematic principle applied to correlate the ²H-RQC and (¹³C–¹H)-RDC spectral patterns (and associated data) in the complex case of the methylene group at C5 to determine the sign of ²H-RQCs, in a scalemic mixture. Here the spectral ²H and ¹³C situations shown correspond to the case of the methylene group 5 of 5 dissolved in L-MSP, but other situations are encountered with the inversion of ¹³C resonances of minor and major enantiomers in the F₂ dimension and/or ¹³C–¹H dipolar or ²H quadrupolar splitting in the F₁ dimension (see the ESI†). The same correlation approach was applied for the analysis of the two methylenes located at positions 3 and 6 of 5 (see Fig. S16 and S18, ESI†) in L-MSP, but also in the three other CLCs. Thus, the coherence between experimental RQC and RDC data enables the determination of the sign of the ²H-RQCs.

Fig. 3 (a) Stereochemical relationships existing between the four isotopomers associated with a methylene group in a chiral molecule (here a scalemic mixture where the major enantiomer is D). The color code (minor/major isomers and diastereotopic sites A/B) shown is used in Fig. 4b. (b) Schematic description of the principle leading to correlation of ²H-RQC and one-bond (¹³C-¹H)-RDC data in order to determine of the sign of ²H-RQCs for two diastereotopic directions (exo and endo) of a CH₂ group. Correlation is done by combining ²H-RQC data extracted from NAD tilted Q-resolved 2D experiments (left) and (¹³C–¹H)-RDCs from ¹³C (¹T_CH/4)-resolved 2D experiments (right). The situation shown here corresponds to the methylene group 5 of 5 in L-MSP.

The consistency of the two (L/D)-isomer datasets with respect to the exo/endo positions in CH₂ groups as well as for CH and CH₃ groups, leading to the sign of any ²H-RQC can be scrutinized in Tables S5, S7, S9 and S11 (ESI†). Moreover, the small Q-factors (Q < 0.07) obtained with all the mesophases definitively validate the determined signs by correlation of the ²H-RQCs.

Analysis of results in four chiral mesophases

All experimental and back-calculated ²H-RQC data (Δν^Exptl._Q and Δν^Calc._Q) as well as all pertinent spectral (¹³C/²H) data for (R)-5 and (S)-5 oriented in mesophases poly-1 to poly-4 are listed in Tables S5/6, S7/8, S9/10 and S10/11 (ESI†), respectively, while the key order-based molecular data, as the generalized degree of order (GDO) or eigenvalues of the Saupe tensor, for instance, associated with each isomer are summarized in Table 1. Whatever the CLC, the small Q values (from 0.02 to 0.06) calculated for each enantiomer indicate an excellent agreement between experimental and back-calculated values. Associated correlation graphs (Δν^Exptl._Qvs. Δν^Calc._Q) as well as column bar plots showing comparisons between Δν^Exptl._Q and Δν^Calc._Q values for each enantiomer in the four CLCs are presented in the ESI.†

Table 1 Key Order-based molecular data of 5 in the four chiral mesophases

Parameters	PDA (poly-1)	L-MSP (poly-2)	PBLG (poly-3)	PCBLL (poly-4)
a Factor of quality, Q, according to Cornilescu's definition for the best-fit (SVD) (see text and SI and SII, ESI). b RMSD: standard root mean square deviation (see the text and SI and SII, ESI). c GDO: generalized degree of order. d Value of generalized 9D-angle β between the L- and D-enantiomeric Saupe matrices for the best-fit (see eqn (2)). e GCB: “Cosine of generalized 9D-angle β”.
Configuration of the repeating unit	R/(D)	S/(L)	S/(L)	S/(L)
Polymer abs. conf.	M	M	M	M

---

Solute abs. conf.	R,R/(D)	S,S/(L)	R,R/(D)	S,S/(L)	R,R/(D)	S,S/(L)	R,R/(D)	S,S/(L)
Q factor^a	0.0656	0.0417	0.0606	0.0603	0.0171	0.0173	0.0194	0.0241
RMSD (Hz)^b	5.0	3.5	6.4	4.8	7.7	7.7	2.7	2.5
Eigenvalues of {Sαβ} Sx′x′, Sy′y′, Sz′z′ (×10^−4)	+3.75	+3.48	−0.64	−1.86	−20.08	−20.80	+0.81	+0.98
	+4.35	+5.35	−9.19	−6.19	−27.87	−27.10	+11.90	+10.77
	−8.10	−8.83	+9.83	+8.05	+47.96	+47.90	−12.71	−11.74
GDO (×10^−3)^c^42	0.81	0.89	1.10	0.84	4.82	4.80	1.42	1.30
Axial comp. (×10^−3)^42	−0.81	−0.88	+0.98	+0.81	+4.80	+4.79	−1.27	−1.17
Rhombic comp. (×10^−3)^42	−0.04	−0.12	+0.57	+0.29	+0.52	+0.42	−0.74	−0.65
Rhombicity par. (×10^−1)^42	0.50	1.41	5.80	3.58	1.08	0.88	5.82	5.56
Asymmetric par. (×10^−1)^42	0.74	2.12	8.70	5.37	1.62	1.31	8.73	8.33
β angle [L,D]^d^42	8.4°		78.0°		4.3°		61.5°
GCB [L,D]^e^42	0.9893		0.2078		0.9972		0.4767

---

In terms of orientational behavior, the analysis of GDO values calculated in the four CLCs clearly shows that 5 is much more strongly oriented in PBLG (GDO(poly-3) ≈ 4.8 × 10⁻³) than in the PDA, L-MSP and PCBLL mesophases for which the GDO values vary from 0.8 to 1.5 × 10⁻³, thus confirming the range of ²H-RQCs measured in each mesophase (up to 1100 Hz in PBLG, and up to 250 Hz in the other CLCs). With regard to the chemical structure of the PBLG sidechain, this result is quite surprising. Indeed, the latter does not seem favorable to promote strong analyte–polymer interactions compared to the other polymers which exhibit one hydrogen-bond donor site (see Fig. 1a). In fact, the high GDO value of 5 in the PBLG mesophase is probably related to a better packing effect of PBLG fibers (inducing a stronger solute orientation) due to (i) a higher rigidity of the helical backbone of PBLG (stabilized by internal H-bonds in the peptide chain) that does not exist for polyacetylenic polymers; and (ii) a weaker flexibility of the (short) side chains of PBLG (only six rotors) compared to the sidechain of PCBLL, PDA and L-MSP polymers that explore larger 3D volumes during their conformational dynamics, thus reducing the degree of order of the polymer.

In terms of the molecular enantiodiscrimination process, the comparison of β angles or GCB values (see Table 1) provides a quantitative description of the differences of enantiomer orientation in the four lyotropic CLCs. These differences can also be visualized with graphical representations of R/S-tensors using 3D surfaces as depicted in Fig. 4. Thus, the analysis of GCB values shows that the eigenvectors of the diagonalized Saupe matrix (PAS) of (D) and (L)-5 are relatively close in PDA and PBLG mesophases, while they are strongly different in the L-MSP and PCBLL mesophases. Thus, in terms of differentiation, the newly reported aligning system, a polyarylacetylene with modified serine sidechains (L-MSP) provides the best EDAs as highlighted by the value of the intertensor angle β respectively its GCB (Table 1). Although limited to a single example, it may be stated that L-MSP is a promising chiral system for the analysis of chiral rigid solutes of average polarity exhibiting hydrogen-bond acceptors (e.g. camphor).

Fig. 4 Visualization of the alignment tensors as a 3D surface for (D)-5 and (L)-5 in the four chiral mesophases. Blue colour codes for negative and red for positive values. Color scaling is adapted to the maximum scaling of the ²H-RQCs in the corresponding directions (for vectors pointing from the center of the tensor plot to the individual surface points). Note the large difference of orientation in L-MSP and PCBLL.

The comparison of enantiomer discrimination abilities between the four CLCs leads also to interesting insights into the mechanisms of enantiodiscrimination occurring in the chiral environments. First, values of GDO versus GCB calculated for L-MSP and PBLG selectors demonstrate no clear correlations between the degree of order and the EDAs, even if high degrees of order are generally favorable to separate the quadrupolar doublets associated with each enantiomer (i.e. increasing the |ΔΔν_Q(²H)|).

Furthermore, the absence of a global trend in GCB between polypeptide and polyacetylene based polymers suggests that both (i) the location of the stereogenic center (within the helix or in the side chain), and (ii) the dynamics of the helical scaffold (less flexible in the case of polypeptides) are not of major importance. Then, the lower GCB obtained with L-MSP versus PDA might be explained by a highly sterically hindered stereogenic center in the first one, but this remains a working hypothesis at this stage.

In summary, it can be stated that from such an intra- and interfamily comparison, there is no major factor that governs the CDMs, but rather multiple molecular parameters acting in a synergistic way. This highlights the complexity of CDMs and how small functional changes in the polymer structure can affect the whole analyte's orientational behavior. Under these conditions, the design of new enantiodiscriminating polymer structures associated with a given organic solvent remains a challenging but exciting task. Accumulation of comparative experimental data paves the way to a global understanding of this complex phenomenon.

4. Conclusion and prospects

With the aim of gaining new and deeper insights into the mechanism of enantiodifferentiation caused by lyotropic CLCs, we have exploited the analytical potential of ANAD 2D-NMR to investigate and quantify the enantiodiscrimination power of two families of chiral helical polymers in oriented phases: (i) the “historical” polypeptide-based polymers (PBLG and PCBLL) abundantly used in many analytical applications;^22,23 and (ii) the new CLC systems based on polyarylacetylenes bearing amino acid derived lateral groups such as PDA or PLA recently reported,^21,44 and L-MSP described in this work for the first time.

In contrast to many investigations reported so far, using ¹H/¹³C-RDCs or ¹³C-RCSAs for evaluating the enantiodiscriminating power of new mesophases from two separated samples, one per enantiomer,^{17,44,65–67} the use of ²H-RQCs allows the simultaneous analysis of each enantiomer dissolved in a single oriented sample preferentially when a scalemic mixture is studied. This new approach, exploiting the approximately ten times larger ²H-RQCs as compared to the ¹H/¹³C-RDCs, circumvents possible small variations of the mesophase properties that cannot be excluded when two samples are prepared.

Inter- and intra-family comparisons of results show that the L-MSP and PCBLL mesophases possess higher enantiodiscrimination power (toward the enantiomers of camphor), irrespective of the position of the chiral centers with respect to the helical backbone of the chiral polymers (backbone or side chains). This result clearly indicates that although the electronic/structural characteristics of a chiral solute strongly influences the propensity for the enantiomers to be discriminated, this phenomenon also depends on the characteristics of the chiral polymer used in combination with the organic co-solvent.

The outcomes and insights obtained from this study clearly highlight the complex interplay between the solute and the polymer. The high dimensionality of these interactions at the same time makes the design of global chiral descriptors able to reliably model all recognition phenomenon, and then the prediction of the NMR results, very difficult.

This new study demonstrates that it is mandatory to understand the fine intermolecular interactions between enantiomers and the chiral selectors in the case of a series of analogous chiral molecules. With regard to the results obtained with camphor, it should be pertinent, for instance, to examine the case of isoborneol (1S-endo)-1,7,7-trimethyl-bicyclo[2.2.1]heptan-2-ol), that possesses a molecular structure very close to that of camphor while the hydroxyl group is susceptible to hydrogen bonding with LLC as PBLG.

Moreover, the NMR studies of transitory polymer–analyte complexes would be beneficial to in the further understanding of CDMs. NMR methods, such as Saturation Transfer Difference (STD) NMR,⁶⁸ which provide insights into the spatial proximity of the analyte and the polymer side chains at the atomic level (epitope mapping), could be used to screen potential differences in the binding process between enantiomers toward the polymer side chain. Such an approach is currently in progress with promising preliminary results.

Finally, polymer–polymer interactions could also play an important role in the recognition process, which is certainly worth investigating.

5. Experimental section

Helically chiral polymers used

The degree of polymerization (DP) of polymers poly-1, poly-2, poly-3 and poly-4 is equal to 750, 750, 768 and 778 respectively.

Synthesis of PDA (poly-1)

Description of the synthesis of PDA can be found in ref. 21 and 44.

Synthesis of L-MSP (poly-2)

The synthesis of monomer 2 (L-MSP) was achieved in seven steps with an overall yield of 64% starting from 4-bromobenzoic acid 6, L-serine 7, p-anisoyl chloride 8 and n-decanol 9 (Scheme 1; for a more detailed description see the ESI†). The L-MSP monomer (2) was subsequently polymerized using a ternary triphenylvinyl rhodium-based initiator, originally introduced by Misumi and Masuda.⁶⁹ As detailed in the ESI† the polymerization of 9 g of L-MSP 2 with a monomer/initiator ratio of 750 : 1 yielded poly-2, quantitatively. The polymer showed a very low dispersity and its helical chirality in chloroform was confirmed by CD spectroscopy (ESI†). We found that poly-2 forms a lyotropic liquid crystalline phase above a critical concentration of 8–9% (w/w) in CDCl₃ solutions. Thus, this new alignment medium generates anisotropic phases at significantly lower concentrations compared to the already established valine-derived poly(phenylacetylene) PLA (poly-1); c_crit = 15 wt%).^21,70–72

Scheme 1 Synthesis and polymerization of monomer 2.

PBLG and PCBLL

These polymers were not synthesized but purchased from Sigma-Aldrich company. They were used without any further purification of the materials.

Oriented sample preparation

Analyte 5 (C₁₀H₁₆O; MW = 152.2 g mol⁻¹). The scalemic mixture of 5 was prepared with an ee(D) of 30% by mixing approximately 26 mg (0.17 mmol) of the D-isomer with 14 mg (0.09 mmol) of the L-enantiomer. Polymer-based LLC samples (poly-1, poly-2, poly-3, and poly-4) were prepared as 19% (w/w) solutions in an appropriate solvent CHCl₃. The exact compositions, ratio and ee(%) of samples are given in Table S2 (ESI†).

Oriented samples (fire-sealed, high-precision 5 mm NMR tubes) were homogenized by centrifugation (up and down at about 600 rpm during about 10 s). FWHM < 3–5 Hz is required to maximize the signal-to-noise ratio, SNR. Note here that attempts to measure ²H-RQCs of 5 with PCBLL dissolved in chlorinated organic solvents (CHCl₃ and CH₂Cl₂) were not successful.

ANAD 2D-NMR

Anisotropic NAD QUOSY 2D spectra (Q-resolved Fz 2D experiments) were recorded at 14.1 T (92.1 MHz for ²H) on a Bruker Avance II spectrometer equipped with a 5 mm o.d. selective cryogenic ²H probe (see details in the ESI†). All ²H–¹H scalar and dipolar couplings were removed by the WALTZ-16 composite pulse decoupling (CPD) sequence. The recycling delay and the number of points of the 2D matrix (t₂, t₁) and scans per t₁ increment of Q-resolved Fz 2D experiments were optimized to record spectra within 20–23 hours. Adapted exponential filtering (LB_1,2 = 1.5 Hz) and zero-filling to 4k(t₂) × 4k(t₁) were applied prior to the two-dimensional Fourier transform. The resulting 2D maps were finally tilted clockwise and then symmetrized.

Isotropic and anisotropic ¹³C NMR

Isotropic and anisotropic ¹³C 1D/2D spectra were obtained @ 9.4 T (100.3 MHz for ¹³C) using a Bruker Avance I (5 mm QXO NMR probe). Analysis and assignment of ¹³C resonances were made using classical approaches (COSY, HSCQ, and HMBC) in combination with data from the literature.^47,48 Evaluation of scalar couplings, ¹J_CH, and total spin–spin couplings, ¹T_CH, of 5 were obtained by the analysis of ¹H coupled ¹³C spectra and (T_CH/4)-resolved experiments (see the ESI†).

All NMR 1D/2D spectra (NAD and ¹³C) were recorded at 300 K and controlled with a stability of ± 0.1 K.

Computational methodology

The molecular geometry of (D)-(−)-camphor was DFT optimized at the B3LYP/6-311+G(d,p) level of theory, using the solvent chloroform as a polarizable continuum model (PCM). All RQCs were back-calculated for this structure using the same frame of reference for tensor comparisons.

Conflicts of interest

The authors declare no competing financial interest and have given approval to the final version of the manuscript.

Acknowledgements

P. L. acknowledges the CNRS for its recurrent funding of fundamental research and the Université Paris-Saclay (previously Université Paris-Sud) for its support, as well as Ms Fofana Djeneba for her participation in this project in the frame of her first year of her Master student's internship. M. R. thanks the DFG (Re 1007/9-1) and CAPES (418729698) for financial support.
