A first-principles study of the avalanche pressure of alpha zirconium

Abstract

We investigate the stability of a monovacancy in alpha zirconium under various strains and pressures by examining the vacancy formation energy through first-principles calculations. There is a maximum formation energy of 2.35 eV under uniaxial strain corresponding to a c/a ratio of 1.75. Under volumetric strain, the formation energy increases as the strain increases. The formation energy as a function of the volumetric stress or pressure was also examined, with a minimum value of 2.00 eV at zero pressure. Using the equations of state method, we find that the formation volume of the vacancies decreases as the pressure increases, with a value of 0.6 unit-atom-volume at zero pressure. The formation enthalpy increases monotonically as the pressure increases. We predict that the avalanche pressure of alpha zirconium is −15 GPa, where vacancy formation is exothermic, causing avalanche swelling and the failure of the material.

---

1 Introduction

A monovacancy is a basic unit mediating mass transportation in a crystal, generally associated with self-interstitial atoms (SIAs) – another basic unit. Mechanical and kinetic processes in metals, such as dislocation climbs and self-diffusion, are associated with the evolution of vacancies. The mechanical properties of metals are greatly affected by the vacancy concentrations, which are determined by the vacancy formation energy at finite temperatures. Vacancy formation energy, the energy cost to generate a monovacancy, is a measurement of the stability of the monovacancy in the crystal. It also contributes to the self-diffusion coefficient via the monovacancy mechanism in metals.¹ For example, the formation of a large vacancy loop was observed to be much easier in the presence of edge dislocations.² Therefore, the vacancy formation energy serves as an important parameter in the understanding of the mechanical behavior of metals.

On the other hand, strain greatly affects the stability of defects including vacancies. Strains have a profound influence on the properties of materials through changing the atomic structures. In materials with hexagonal-close-packed (HCP) crystal structures, the mechanical properties are anisotropic, and can be enhanced by applied strains. For example, the nucleation probability of the interstitial loops is increased on planes perpendicular to an applied strain compared to parallel ones.^3–5 As a result, strain causes the transportation of atoms from planes parallel to the strain direction, to those perpendicular to the strain direction. In addition, the strain can drive the dislocation glide on planes inclined to the strain direction, as well as the dislocation climb due to the interstitial bias of the dislocations.⁶ More fundamentally, such anisotropic movements of dislocations are a result of the preferred absorption of point-defects under strain.^4,6 A recent molecular dynamics study suggests that the anisotropic diffusion of vacancies becomes a dominant bias over the conventional dislocation bias caused by first order elastic interactions between the point defects and the sink (dislocation core, void, grain boundary, etc.).⁷ The influence of different atomic grain boundaries in the thermodynamic and kinetic properties of defects was also investigated.⁸ Furthermore, strain is widely present in micro-structures, including α zirconium (α-Zr) which has an HCP structure, due to thermal fluctuations, the presence of defects, manufacturing, or use as a structural material. However, a quantitative knowledge of the strain effect on the stability of the monovacancy in α-Zr is still lacking.

In HCP metals, two kinds of strains are important: uniaxial strain along the c direction, and volumetric strain. The volumetric strain is particularly interesting since it is closely related to irradiation swelling.⁹ Under uniaxial strain along the c direction, the c/a ratio of the crystal will change, in addition to the preferred absorption of point defects. There are 29 elements with HCP structures in their α phase, for which the c/a ratio ranges from 1.472 (yttrium) to 1.886 (cadmium). The c/a ratio determines the most close-packed plane in which the dislocation loop nucleation is energetically favorable. The ideal c/a ratio (1.633) corresponds to the c/a ratio in an fcc (face centered cubic) structure, which is more isotropic than an HCP structure. The most close-packed planes in an HCP structure are the prism plane {101̄0} for c/a < 1.633 and the basal planes (0001) for c/a > 1.633.

The structural integrity of zirconium (Zr) and Zr alloys is of great importance due to safety issues as they are commonly used as the cladding material of fuel rods in nuclear reactors. However, due to harsh working conditions with large doses of radiation, in addition to the anisotropic HCP crystal structure, Zr has significant shape changes, even without external stress, known as radiation growth.^4,7,10–18 Knowledge of the mechanism of radiation growth is critical in the design of improved alloys or the prediction of the future behavior of current alloys in service in nuclear reactors. Models based on classical inter-atomic potentials are problematic for the characterization of zirconium;^19–30 part of the reason is that HCP transition metals, particularly those with c/a ratios different from the ideal value of 1.633, are poorly described by empirical inter-atomic potentials.^31–33

Experimentally, it is not easy to determine the formation energy of the monovacancy precisely, because this quantity is affected by the local environment, such as the presence of impurities around the vacancy. Very pure samples are therefore required to obtain reliable results,³⁴ and quantitative studies of the strain effects are even more challenging. Thus precise predictions rely on ab initio density functional theory (DFT) calculations.

The ultimate goal is to investigate the fundamental mechanism of the radiation growth in α-Zr, which is closely related to the stabilities of both the monovacancy and the SIAs. The stabilities of the SIAs were reported in our previous work, in which we concluded that the basal octahedral (BO) configuration is the most stable configuration,³⁵ as confirmed by other first-principles calculations.^36,37 A further study on the axial ratio (c/a) dependence of the stability of SIAs in HCP structures shows that the axial ratio dominates the relative stability of SIAs over volumetric strains.³⁸ Below the ideal value of c/a = 1.633, the basal octahedral configuration is the most stable. Above the ideal value, the off-plane SIAs are more stable than the in-plane ones. In addition, the pressure dependent stabilities were reported recently.³⁹ Furthermore, the diffusion of point defects in α-Zr was also studied.^40–43 This shows that the Zr-vacancy plays a dominant role in the diffusion of helium in the ZrC system.⁴⁴ However, the stabilities of the Zr-vacancies under strain are still elusive.

This work aims to provide accurate and reliable information about the stability of the vacancy in Zr. Therefore we studied the vacancy formation energy under various strains, in both tension and compression, axially along the c direction, and volumetrically using DFT calculations. The paper is organized as follows. Section 2 presents the details of the DFT calculations. Section 3 presents the results and analysis, followed by discussion in Section 4 and the conclusions in Section 5.

2 Density functional theory calculations

We studied the stabilities of vacancies by examining the formation energy using DFT calculations with the super cell method.^45–47 Four super cells with N = 36, 96, 180, and 288 atoms were examined, which contain 3 × 3 × 2, 4 × 4 × 3, 5 × 6 × 3, and 6 × 6 × 4 primitive unit cells, respectively.

Our DFT calculations were carried out using the Vienna Ab initio Simulation Package (VASP),^48,49 which is based on Kohn–Sham Density Functional Theory (KS-DFT),⁵⁰ with the generalized gradient approximation developed by Perdew, Burke and Ernzerhof (PBE) as the exchange–correlation function.⁵¹ The core electrons are replaced by the projector augmented wave (PAW) approach,⁵² which has twelve electrons (4s²4p⁶5s²4d²) explicitly included as valence electrons.

The cutoff energy for the kinetic energy of the wave-functions was carefully selected to be 400 eV after convergence tests. A Gamma-centered k-mesh is required to sample the irreducible Brillouin zone in HCP structures to preserve the HCP symmetry. Here we used 7 × 7 × 7, 5 × 5 × 5, 3 × 3 × 3, and 3 × 3 × 3 Gamma-centered k-meshes for the four systems, respectively. The integration over eigenvalues is performed using the smearing technique with the Methfessel–Paxton function and a smearing width of 0.05 eV,⁵³ which results in a convergence of the total energy with a fluctuation of less than 2 meV per cell.

The vacancy structures are optimized using the conjugate gradient method. The criterion to stop the relaxation of the electronic degrees of freedom is set as the total energy change being smaller than 10⁻⁵ eV. The optimized atomic geometry was achieved through minimizing the Hellmann–Feynman forces acting on each atom until the maximum forces on the ions were smaller than 0.03 eV Å⁻¹. All the parameters selected will ensure the convergence of the formation energies with fluctuations of less than 0.05 eV per cell.

3 Results and analysis

We first examined the convergence of the total energy (E_tot) of the primitive unit cell (2-atom cell) of α-Zr with respect to the kinetic energy cutoff E_cut for the wave functions. A dense k-mesh of 25 × 25 × 17 was used for high accuracy, which corresponds to 585 irreducible k points. The averaged energy per atom (E_tot/atom) converges to −8.456 eV at E_cut = 400 eV.

There is only one configuration for a monovacancy in α-Zr, in contrast to the various configurations of a SIA in α-Zr,³⁵ or a monovacancy in compounds,⁵⁴ or a monovacancy in vacancy clusters.⁵⁵ Due to the layered structure of an HCP crystal, the vacancy is always in a basal plane.

3.1 Elastic properties

The lattice constants are obtained by relaxing the primitive unit cell with a cutoff energy of 1300 eV for wave functions and a cutoff energy of 2000 eV for augmentation charges for high accuracy. The elastic tensor is determined by performing six finite distortions (δε = 0.015) of the HCP lattice and deriving the elastic constants from the strain–stress relationship, where stresses were calculated ab initio by properly applied strains after a convergence test of δε.⁵⁶ All internal relaxations were performed. The bulk modulus B was calculated using⁵⁷with C₆₆ = (C₁₁ − C₁₂)/2.

The results for the lattice constant a, the c/a ratio, the bulk modulus B, and the elastic constants in HCP C₁₁, C₃₃, C₄₄, C₆₆ obtained from ab initio calculations are summarized and compared with previous studies and experiments in Table 1. They are in good agreement with both experiments^58–61 and previous ab initio calculations.^46,62–66

Table 1 Lattice constants and elastic constants of bulk α-Zr from ab initio DFT calculations

	a (Å)	c/a	B (GPa)	C11 (GPa)	C33 (GPa)	C44 (GPa)	C66 (GPa)
Present	3.238	1.600	93.6	142.7	165.3	28.8	38.8
Expt^58	3.23	1.593	97	155	173	36	44
Expt^59	3.231	1.593	96.5	144.0	166.0	33.0	35.0
Expt^60	3.231	1.593	93.3	143.4	164.8	32.0	39.0
Expt^61	3.230	1.594	97.2	155.4	173.0	36.3	41.4
DFT^62	3.23	1.604	92	142	164	29	39
DFT^46	3.23	1.600	94	146	156	28	42
DFT^63	3.232	1.603	94.1	139.4	162.7	25.5	34.0
DFT^64	3.24	1.598	93.4	141.1	166.9	25.8	36.8
DFT^65	3.236	1.597	96.0	146.7	163.3	26.0	39.1
FP-LMTO^66	—	—	100.3	153.1	171.2	22.4	44.9

---

3.2 Vacancy formation energy

In this study a vacancy is generated by removing a single atom from a system with N atom sites while keeping the system’s volume unchanged (constant volume).

The formation energy is the energy cost of generating a defect configuration, which is used to quantify the stability of the vacancy configuration as compared to the ideal system. The vacancy formation energies are calculated at the rescaled constant volume condition with the super cell method as^45–47

where E(N) is the total energy of the ideal bulk (without vacancies) with N atoms and a volume of V. E(N − 1) is the total energy of the system with a vacancy, which has N − 1 atoms and a volume of V.

The vacancy formation energy is 2.06, 2.02, 2.00, and 1.97 eV for N = 36, 96, 180, and 288, respectively. Our results are in good agreement with previous calculations.⁶⁷ With the increase of the system size, the formation energy decreases. However, the formation energy is indistinguishable at N ≥ 96 when the numerical errors in the DFT calculations are considered.

3.3 Strain effects

The effect of strain on the stability of the vacancy is of great importance. We studied two modes of strain: the uniaxial strain along the c direction, and a volumetric strain. In these modes, both compressive and tensile strains are examined. The vacancy formation energy under strain ε is calculated with the super cell method as,^45–47where E(N; V; ε) is the total energy of the ideal bulk (without defects) with N atoms in volume V under volumetric strain , V₀ is the volume in the strain free state, V is the volume after homothetic deformation, and ε could be either uniaxial or volumetric strain. E(N − 1; V; ε) is the total energy of the system with a vacancy, which has N − 1 atoms and the volume is fixed as V first, then a strain ε is applied. The total energies are obtained after the systems are relaxed. It is worth noting that we applied artificially large strains in order to easily find the differentiable energies in the DFT calculations. We exclude the phase change in our model by using a constraint of HCP symmetry once a large strain has been applied.

3.3.1 Uniaxial strain along the c direction. Uniaxial strain is applied along the c direction by changing the length of the super cell along the c direction, while keeping the length of super cell in the a direction constant. The range of the uniaxial strain ε is from −0.0625 to 0.1250 with an increment of 0.03125. Correspondingly, the c/a ratio varies from 1.5 to 1.80, with an increment of 0.05. Since the c/a ratio has a one-to-one mapping relationship with the uniaxial strain, we can use the c/a ratio to express the uniaxial strain.

The formation energies under various c/a ratios calculated from three systems, with system sizes N = 36, 96, and 180, are plotted in Fig. 1. The formation energies increase with the c/a ratio at first, then decrease after a maximum. The maximum formation energy is at a c/a ratio of 1.75 (uniaxial strain of 0.09375), with a value of 2.34, 2.36, and 2.32 eV for N = 36, 96, and 180, respectively.

Fig. 1 Uniaxial strain. The formation energy of a vacancy with respect to the c/a ratio (uniaxial strain). The dashed vertical line is the ideal c/a ratio (1.633).

The behavior of the formation energy with respect to the c/a ratio can be understood as the following. Consider an atom with a unit-atom-volume Ω₀. When the c/a ratio increases, the distance between two neighboring atomic layers enlarges. As a consequence, the Ω₀ stretches along the c direction. The monovacancy formation energy is the energy gain due to the internal electronic structure rearrangement when one atom is removed. The larger Ω₀ provides more space for the rearrangement of the atomic structure and the electronic charge density, which has a greater energy gain. As a result, the vacancy formation energy increases with the c/a ratio.

However, the monovacancy is always in a basal plane. When the c/a ratio becomes larger than the ideal value of 1.633, the electronic charge density decreases with the distance to the basal plane. Thus the energy gain from the rearrangement of the electronic charge density becomes saturated at a certain c/a ratio, which is 1.75 in this study.

3.3.2 Volumetric strain. Instead of conserving the size of the basal plane, we studied the volumetric strain, where all three directions undergo the same amount of strain. The formation energies of vacancies at constant volumes E^f(ε) monotonically increase with respect to the volumetric strain ε, as shown in Fig. 2. The formation energy at zero strain E^f(ε = 0) was reported previously.³⁵ The behavior of the formation energies of vacancies responding to the volumetric strain can be understood in a similar way to the uniaxial strain.

Fig. 2 Volumetric strain. The variation of the formation energy of a vacancy with respect to volumetric strains in α-Zr.

As the volumetric strain is applied, the total energy of the system includes the contribution from the external work which is discussed in the following subsections. However, the unit-atom-volume Ω₀ swells in three-dimensions instead of stretching along the c direction only. As a result, the ratio of the increase in the vacancy formation energy to the strain is bigger than that for the uniaxial strain.

3.4 Equations of state

In our previous work, we introduced a generalized EOS method (EOS stands for “equations of state”) to study the formation energy, formation volume, and formation enthalpy of defects in an HCP crystal.³⁹ Many analytic semi-empirical relations have been proposed to describe the EOS of various classes of solids.^68–70 It is generally believed that for strains less than 30%, most EOS are similar in accuracy.^71,72 Here we use the Murnaghan EOS.⁶⁸ The pressure–volume relationship is expressed by the Murnaghan EOS as⁶⁸or equivalently, the volume as a function of pressure iswhere V₀ is the volume at equilibrium at zero temperature and zero pressure, B is the bulk modulus, and B′ is the pressure derivative of the bulk modulus and thus is unitless. If DFT computations are used to calculate the total energy of the system (E) as a function of the volume (V), then the parameters in the EOS (eqn (4) and (5)) can be obtained by fitting with the following equation⁶⁸where E₀ is a constant, marking the total energy of the system at the reference state of P = 0 or equivalently, V = V₀.

So far the total energy of the system at any state of pressure and volume can be obtained. Now consider two systems, with and without a vacancy. We can have two sets of EOS and thus the total energies of the two systems at all states.

For each system, we calculated the total energies corresponding to seven volumes. Two systems were studied, with a vacancy and the ideal system (without a vacancy). The results of E(V) as a function of V are plotted in the upper panel of Fig. 3.

Fig. 3 EOS. The total energy as a function of volume (top) and the equation of state of pressure vs. volumetric strain (bottom) for the ideal system and the vacancy (179-atom) system.

The fitting parameters of the vacancy and ideal systems are summarized in Table 2. Our EOS parameters agree with experiments,^73,74 where B is measured as 92–102 GPa and B′ is 3.1–4.0. Using these parameters, the EOS of eqn (4) can be obtained, as plotted in the bottom panel of Fig. 3. It shows that the EOS of the ideal and vacancy systems are very similar. We only show the data within the volumetric strain range of −0.3 to 0.3 due to the limitation of the accuracy of the EOS for small strains (<30%).⁷² A pressure of 50 GPa corresponds to a volumetric strain of −0.26, and a pressure of −15 GPa corresponds to a volumetric strain of 0.26. We will use the pressure range of −15 GPa to 50 GPa for further study.

Table 2 Equilibrium volume V₀, bulk modulus B and its pressure derivative B′ of bulk α-Zr from the EOS fitting of the ab initio DFT calculations

	V0 (Å^3)	B (GPa)	B′
Ideal	4235.51	94.6	3.51
Expt^74	4191.30	92	4.0
Ref. 64	4236.68	93.4	3.22
Ref. 75	4219.70	97.3	4.00
Ref. 76	4217.40	96.7	2.25
Ref. 65	4218.06	96.0	3.12
Monovacancy	4225.79	93.48	3.492

---

A pressure-induced phase transition is not directly observed from the relaxation of atoms in the static model, but through results from the comparison of the enthalpy of different possible atomic structures.^65,76,77 Although real samples of Zr cannot sustain such high pressures, the theoretical study is still useful since it provides the properties of materials under high pressure, including insights into the stabilities and transition paths.

3.5 Pressure effects

Corresponding to a boundary condition of constant pressure, the formation energy at pressure P is defined as^47,78where E(N − 1; P) and E(N; P) are the total energies of the vacancy system and the ideal system (without defects), respectively, which are calculated from eqn (6) with the parameters in Table 2.

For accuracy reasons, we chose the biggest super cell with a system size of N = 180 for the pressure effect study. The formation energies of a vacancy at a constant pressure E^f(P) as a function of pressure P are plotted in Fig. 4. The formation energy increases rapidly in the tensile mode but slowly in the compressive mode. When the pressure is larger than 10 GPa, the formation energy E^f(ε) increases linearly with respect to the pressure.

Fig. 4 Pressure effect. The formation energy of a vacancy at constant pressure E^f(P) as a function of pressure P.

To have a better understanding of the effect of pressure on the formation energy of a single vacancy, we rewrote eqn (7) as:

E^f(P) = E^d(P) + μ(P), (8)

where the first term is the threshold displacement energy, with

E^d(P) = E(N − 1; P) − E(N; P), (9)

where E^d(P) is the minimum energy cost to knock out an atom⁵⁴ under pressure P. The knocked out atom goes infinitely far away. The second term on the right hand side of eqn (8) is the chemical potential energy,μ(P) is the chemical potential energy under pressure P, which is the energy cost to add one atom to the system.

To illustrate the explicit pressure effect, we take the difference between the finite pressure and zero pressure:

ΔE^f(P) = E^f(P) − E^f(0), (11)

ΔE^d(P) = E^d(P) − E^d(0), (12)

Δμ(P) = μ(P) − μ(0), (13)

where E^f(0), E^d(0), and μ(0) are the total formation energy E^f and its two components the threshold displacement energy E^d and the chemical potential energy μ at zero pressure, respectively. We have plotted the three functions in the top panel of Fig. 5. It can be seen in the figure that both components have the same trend with varying pressure as the total formation energy. The plots imply that the threshold displacement energy E^d is dominant when the pressure is less than 26 GPa, especially under negative pressure. When the pressure goes up higher than 26 GPa, the chemical potential energy μ is the main contributor.

Fig. 5 Two components. The two components of the formation energy of a vacancy at constant pressure E^f(P): the threshold displacement energy E^d (diamond line) and chemical potential energy μ as a function of pressure P relative to the state at zero pressure. The upper panel shows their differences at finite pressure and zero pressure. The bottom shows the contributions of each component to E^f(P).

We have calculated the contribution of the two components to the total formation energy in percentages as illustrated in the bottom panel of Fig. 5. It is clear that the contribution from the first component E^d decreases monotonically with an increase in pressure, from 77.41% at −15 GPa to 40.36% at 50 GPa. This behavior is opposite to that of the second component, the chemical potential energy μ, which increases monotonically with respect to pressure, from 22.59% at −15 GPa to 59.64% at 50 GPa.

The behavior of Δμ as a function of the pressure P could be understood as the following: with a larger pressure, the distance between atoms are on average reduced. As a result, the strength of the bonds are enhanced. It requires more work to introduce one more atom to the system, thus Δμ increases. For the same reason, it becomes relatively easier to remove an atom from the system, as shown by the decrease in the contribution from the change of the threshold displacement energy ΔE^d as displayed in Fig. 5.

It is worth mentioning that there is a crossover of the two curves of the two components in Fig. 5 at a pressure of 26 GPa. This value of pressure is coincident with the phase change of zirconium from the ω to the β phase at a pressure of 22–33 GPa.⁷⁹ This indicates that the vacancy might play a role in this phase change.

3.5.1 Vacancy formation volume. The vacancy formation volume measures the volume change of the vacancy system with respect to the ideal system under the same conditions of N and P. Under constant pressure P, since the electrons are delocalized in metals, the system volume determines the overall binding energy in the system. As a result, the formation volume contributes to the bonding and thus the formation energy. The vacancy formation volume Ω^f(P) is defined as^47,78where V(N − 1; P) and V(N; P) are the volumes of the vacancy system and the ideal system (without defects), respectively, at constant pressure P. V(N − 1; P) and V(N; P) are calculated from eqn (5) with the parameters listed in Table 2.

Formation volumes of the vacancy at constant pressure Ω^f(P) as a function of pressure P are shown in Fig. 6. The unit of Ω^f(P) is Ω₀ = V (N; P = 0)/N, the unit-atom-volume at zero pressure of the ideal system for convenience. In this study, Ω₀ = 23.52 ų. The formation volume decreases monotonically with respect to the pressure. The formation volume at zero pressure Ω^f(0) is 0.6Ω₀. This is the first time that the formation volume of α-Zr has been reported from ab initio DFT calculations. Compared with empirical many-body potentials, our results are smaller than those reported by Pasianot et al.(0.8Ω₀)²⁶ and Ackland et al.(0.74Ω₀).²⁵

Fig. 6 Formation volume. The formation volume Ω^f (top) and external work PΩ^f (bottom) of a vacancy as a function of pressure P.

3.5.2 Vacancy formation enthalpy. Naturally, the presence of pressure introduces the external work of PΩ^f according to the formation volume Ω^f. Under pressure P, the thermodynamically relevant quantity which determines the stability under pressure is the formation enthalpy, which is defined as^47,78,80

H^f(P) = E^f(P) + PΩ^f(P) (15)

where PΩ^f(P) is the external work to the formation volume due to the pressure P. At zero pressure, H^f(P = 0) = E^f(ε = 0).

The formation enthalpy of the vacancy (H^f(P)) as a function of pressure P is plotted in Fig. 7. The formation enthalpy H^f(P) monotonically increases with pressure. When the pressure is larger, the external forces have done more work on the vacancy and thus the formation enthalpy becomes larger.

Fig. 7 Formation enthalpy. The formation enthalpy of a vacancy H^f(P) as a function of pressure P. The region of negative formation enthalpy is the avalanche region, where avalanche swelling occurs. The avalanche pressure P_a is the critical swelling pressure, which is P_a = −15 GPa for alpha zirconium.

The component of PΩ^f(P) is plotted in the bottom panel in Fig. 6. There is a maximum around P = 25 GPa due to the slow decrease of the formation volume with respect to the pressure.

It is also worth noting that the formation enthalpy is negative when the pressure is −15 GPa. This indicates that the generation of the vacancy is energetically favorable. In other words, the vacancy formation is exothermic. Such a trend will create a large amount of vacancies in an avalanche style and cause the system to fail. Because vacancies are inevitably presented in bulk α-Zr at finite temperatures, our results indicate a critical swelling pressure, namely the avalanche pressure, under which avalanche swelling occurs, leading to material failure. The region of negative formation enthalpy is the avalanche region, illustrated in Fig. 7. Our study reveals that the avalanche pressure is P_a = −15 GPa for alpha zirconium, as illustrated in Fig. 7.

4 Conclusions

In summary, we studied the stability of a monovacancy under various strains in HCP-zirconium by examining the vacancy formation energies using ab initio DFT calculations. We found that the vacancy formation energy converges with the system size at N ≥ 96 and the kinetic energy cut-off of 400 eV. There is a maximum in the curve of vacancy formation energy versus c/a ratio at c/a = 1.75, which corresponds to the uniaxial strain along the c direction with a strain value of 0.094. The formation energy at constant volume monotonically decreases with respect to the volumetric strain. However, the formation energy at constant pressure has a minimum at zero pressure, which is 2.00 eV. The formation enthalpy increases monotonically with respect to the pressure. We reported the vacancy formation volume of α-Zr as a function of pressure for the first time, which monotonically decreases with respect to the pressure, and the particular value at zero pressure is 0.6 unit-atom-volume. We predicted that at the avalanche pressure of −15 GPa, the formation enthalpy becomes negative, thus forming a vacancy is exothermic, leading to avalanche swelling and the failure of the bulk α-Zr.
