BODIPY based self-healing fluorescent gel formation via acylhydrazone linkage†
Received
2nd November 2015
, Accepted 16th January 2016
First published on 20th January 2016
Abstract
Polymeric BODIPY derivatives with reactive functional groups undergo reversible formation of covalent bonds leading to self-healing properties. Cross-reactivity of acyl-hydrazine and aldehyde moieties forms the basis of dynamic covalent chemistry leading to sol–gel transition in this series of compounds. In addition, thin layers of absorbers show efficient energy transfer indicating a potential in solar concentration.
Self-healing is a very intriguing emergent property which was until recently kept in the domain of biological systems.1–8 Reversible supramolecular interactions and certain covalent transformations which are also reversible under ambient conditions provided an avenue for the realization of self-healing with non-biological smart materials.9–18 Having the potential to repair the damage caused by mechanical use over time, these polymeric materials are, and will be, highly sought-after due to considerations for safety, extended use period and energy conservation.19–24 In general, tiny fractures or defects on the surface of the polymeric materials are difficult to correct, but the self-healing property offers a great advantage in this regard, extending the functional use period significantly.25 Judiciously engineered covalent interactions have the potential to result in particularly robust materials with such self-healing capability. Any tear or break in the material will leave behind multiple adhesive/cross-reactive termini, which, on contact, would reinstate the covalent bonds ruptured by the physical effector in the first place. Cross-linked covalent polymers with self-healing properties are expected to result in particularly durable materials.26–35
During the past decade, the progress made in BODIPY chemistry has attracted considerable attention due to their high quantum yields, ease of derivatization and a multitude of potential applications.36–42
In this study, our goal was to combine the two phenomena namely, through space energy transfer and self-healing ability, to open a new path towards a new generation of solar concentrators. We targeted the synthesis of two gels (G1 and G2), which are to function as energy donor and acceptor layers. To that end, a BODIPY donor monomer M1 with triformyl groups and a BODIPY acceptor monomer M2 were separately synthesized.
For the synthesis of M1, firstly triiodo-BODIPY derivative (compound 6) was synthesized and then 4-ethynyl benzaldehyde groups were attached this compound via Sonogashira coupling. The synthesis for the second monomer M2 started with the reaction of known BODIPY dye (compound 2) with 4-(hydroxymethyl) benzaldehyde under Knoevenagel conditions (Scheme 1). Thus, the monomer M2 was designed to have longer absorption and emission wavelengths, compared to the monomer M1 due to extended of conjugation and strong intramolecular charge transfer (ICT) (ESI,† Table S1). M2 was obtained via subsequent formylation with Dess–Martin periodianane. Following that conversion, a bis-acylhydrazine functionalized PEO polymer P1 (polyethyleneoxide, Mn = 2000) was prepared according to literature.43 This polymer was used previously in the reversible conversion to poly(acylhydrazone) compounds.
 |
| Scheme 1 Synthesis of monomers M1 and M2. | |
Gel formation reaction was carried out in DMF using BODIPY based monomers M1, M2 and the PEO polymer P1, and it proceeds by the formation of acylhydrazone linkage. The sol–gel transition of the fluorescent material (Fig. 1) was affected by the addition of acetic acid, as the addition of catalytic amount of acid is known to facilitate this reaction.44 As expected, on acid addition at room temperature, transition to gel state is observed as evidenced by the inverted vial test and gelation was completed about 2 hours under these conditions. IR spectra of dried gel formed in dichloromethane (Fig. S18†) showed absorption band at 3496 cm−1 due to the presence of –NH group. In addition, the band observed at 1606 cm−1 corresponds to C
N linkage and indicates the formation of acylhydrazone bond.
 |
| Fig. 1 Inverted vial test demonstration: on acid addition at room temperature, transition to gel state is observed as evidenced by the inverted vial test and gelation was completed about 2 hours under these conditions. On the other hand, gels (G1 and G2) responded to added triethyamine changes showing a reversal to sol phase. The sol–gel transition of fluorescent donor dye (a) and fluorescent acceptor dye (b). The compositions of gels are 0.02 mmol polymer (P1), 0.0134 mmol dye (M1 or M2), 30 μL acetic acid in 0.4 mL DMF. | |
On the other hand, gels (G1 and G2) responded to added base (triethyamine) changes showing a reversal to sol phase (ESI,† Fig. S2). For the sol gel transition firstly hydrochloric acid (5 μL) was added on the gel surface, after waiting 2 hours gel turns into sol due to hydrolysis of acylhydrazone bond at higher acidic conditions, so after adding triethylamine (8 μL) to this solution, sol turns into gel because of the formation of acylhydrazone bond again.
Self-healing properties of the gel materials were investigated initially, by bringing together two pieces of the gel and holding them in contact to form a single piece, without any other external influence. Following a brief period, the two pieces were reattached visibly (Fig. 2). In addition, two gel pieces prepared using the polymeric linker and the donor BODIPY monomers, and the acceptor BODIPY monomers were brought together in the same way.
 |
| Fig. 2 The digital photographs of the cracked and merged fluorescent donor and acceptor gels: (a) merged donor gel (left half) and acceptor gel (right half) by putting donor half and acceptor half together for two hours at ambient temperature, (b) cracked donor gel (left) and acceptor gel (right), (c) also merged donor gel (left half) and acceptor gel (right half) pulled by tweezers. | |
Rheological measurements were also carried out in order to determine and compare the strengths of G1, G2 and the healed gel. The rheological spectra of G1, G2 and the healed gel show that storage modulus (G′) is much larger than the loss modulus (G′′) and it does not depend on angular frequency ω, suggesting an organogel formation (Fig. 3a–c). In addition, G′ vs. ω plot shows a wide plateau indication of covalent cross-linked polymer gel.45 The stress–strain at break of G1, G2 and the self-healed gel which was obtained by bringing together the two pieces of G1 and G2 are shown in Fig. 3d. The toughness which is the area under the stress–strain curve is almost same for G1, G2 and the healed gel. Hence the healing efficiency of healed gel is determined as 100% with respect to G1 and G2.46
 |
| Fig. 3 Storage modulus (G′) and loss modulus (G′′) vs. angular frequency (ω) of donor gel (G1) (a), acceptor gel (G2) (b), and healed gel (c). Stress strain curves of donor gel (G1), acceptor gel (G2) and healed gel (d). | |
Healing at the microscopic level was investigated as well, for that purpose G1, which consists of donor monomer M1 and PEO polymer P1, was deliberately damaged by a needle tip and microscopy shows the disappearance of the wedge under optical microscope after two hours, and SEM images are also supportive of rebuilding of the surface (Fig. 4).
 |
| Fig. 4 Optical microscope images of mechanically damaged fluorescent self-healing donor gel (a), after one hour (b) and after two hours (c). SEM images of fluorescent self-healing donor gel show healing line after cutting and healing gel (d) and (e). | |
To investigate energy transfer properties between donor gel G1 and acceptor gel G2, initially we acquired the photo luminescence spectra of gels directly from the gel phase, G1 has an emission peak at 605 nm, and G2 at 658 nm. The normalized emission spectra of the gels are shown in Fig. 5.
 |
| Fig. 5 The emission spectra of fluorescent self-healing donor gel and fluorescent self-healing acceptor gel at 575 nm for donor gel and at 645 nm for acceptor gel. The data were acquired from G1 and G2 gel phase separately. | |
Besides the spectral overlap, proximity of the donor–acceptor pair is significant for fluorescence energy transfer phenomenon. So in order to perform energy transfer in gel phase, self-healing ability of gels provide proximity of molecules on contact surfaces of gels (G1 and G2). Hence, a glass surface was coated by spin coating with the solution containing precursors of G1 at 8000 rpm for one minute. Then it was set aside for the completion of gelation. This coated surface with G1 was then coated with the other gel G2 by the same method and the thickness of the both gel layers were determined 10 nm by profilometer (Fig. 6). The excitation spectrum obtained using the two-layers of the gel shows a clear evidence of energy transfer between the fluorescent gel layers (Fig. 6). Here, self-healing takes place between contact surfaces of gels through condensation reaction between acylhydrazine and aldehyde groups in the gels. Thus, the Förster type energy transfer47 between donor and acceptor gel surfaces occurs because of the formation of dynamic covalent bonds on contacting surfaces of the self-healed donor and acceptor gels.
 |
| Fig. 6 The emission and excitation spectra for the spin coated (10 nm for G1 and G2, respectively) glass with fluorescent self-healing donor gel G1 and fluorescent self-healing acceptor gel G2. (a) The emission spectrum of spin coated glass excited at 550 nm. (b) Excitation spectrum of spin coated glass (the emission data were collected at 700 nm). (c) Schematic representations of spin coating set-up for fluorescent self-healing donor gel (G1, 10 nm thickness, 8000 rpm for one minute) and fluorescent self-healing acceptor gel (G2, 10 nm thickness, 8000 rpm for one minute). | |
A plot of energy transfer efficiency (Fig. S16†) as a function of wavelength,48 yields energy transfer efficiencies above 90% in the region of analysis. This means that the energy transfer between the gel layers is promising for potential use in solar concentrator applications.49 On the other hand, the energy transfer efficiency for the mixture of monomers M1 and M2 is determined in sol phase (in chloroform) as about 30% (Fig S17†). This result shows that some energy transfer occurs in sol phase because the donor and acceptor modules are closer each other. However we do not think that it is a nonradiative FRET, it is most probably a valueless radiative energy transfer.
With this work for the first time two fluorescent gel materials, which have self-healing characteristics were synthesized and shown to cascade energy from the shorter wavelength absorbing gel (donor gel G1) to the longer wavelength absorbing (acceptor gel G2) one. An induced tear in both gels are effectively healed in a relatively short amount of time. We are confident that materials designed with this approach are likely to have a practical potential in luminescent solar concentrators. Our work to that end is in progress.
Acknowledgements
Funding from TUBITAK (113T062) to F. S. is gratefully acknowledged. The authors thank Professor Dr Engin U. Akkaya for fruitful discussions.
References
- A. Phadkea, C. Zhanga, B. Armanb, C.-C. Hsuc, R. A. Mashelkard, A. K. Leled, M. J. Tauberc, G. Aryab and S. Varghesea, Proc. Natl. Acad. Sci., 2012, 109, 4383 CrossRef PubMed.
- K. Imato, M. Nishihara, T. Kanehara, Y. Amamoto, A. Takahara and H. Otsuka, Angew. Chem., Int. Ed., 2012, 51, 1138 CrossRef CAS PubMed.
- X. Chen, M. A. Dam, K. Ono, A. Mal, H. Shen, S. R. Nutt, K. Sheran and F. Wudl, Science, 2002, 295, 1698 CrossRef CAS PubMed.
- R. Nicola, J. Kamada, A. V. Wassen and K. Matyjaszewski, Macromolecules, 2010, 43, 4355 CrossRef.
- Y. Amamoto, J. Kamada, H. Otsuka, A. Takahara and K. Matyjaszewski, Angew. Chem., Int. Ed., 2011, 50, 1660 CrossRef CAS PubMed.
- E. B. Murphy, E. Bolanos, C. Schaffner-Hamann, F. Wudl, S. R. Nutt and M. L. Auad, Macromolecules, 2008, 41, 5203 CrossRef CAS.
- K. Ishida and N. Yoshie, Macromol. Biosci., 2008, 8, 916 CrossRef CAS PubMed.
- Y. Ruff and J.-M. Lehn, Angew. Chem., Int. Ed., 2008, 47, 3556 CrossRef CAS PubMed.
- Z. Wei, J. H. Yang, J. Zhou, F. Xu, M. Zrinyi, P. H. Dussault, Y. Osadag and Y. M. Chen, Chem. Soc. Rev., 2014, 43, 8114 RSC.
- E. Kolomiets and J. M. Lehn, Chem. Commun., 2005, 1519 RSC.
- J. M. Lehn, Prog. Polym. Sci., 2005, 30, 814 CrossRef CAS.
- S. Otto, R. L. Furlan and J. K. Sanders, Drug Discovery Today, 2002, 7, 117 CrossRef CAS PubMed.
- J. M. Lehn, Chem. Soc. Rev., 2007, 36, 151 RSC.
- C. R. South, C. Burd and M. Weck, Acc. Chem. Res., 2007, 40, 63 CrossRef CAS PubMed.
- S. J. Rowan, S. J. Cantrill, G. R. Cousins, J. K. Sanders and J. F. Stoddart, Angew. Chem., Int. Ed., 2002, 41, 898 CrossRef.
- S. K. M. Nalluri, C. Berdugo, N. Javid, P. W. J. M. Frederix and R. V. Ulijn, Angew. Chem., Int. Ed., 2014, 53, 5882 CrossRef CAS PubMed.
- S. K. M. Nalluri and R. V. Ulijn, Chem. Sci., 2013, 4, 3699 RSC.
- M. Zhang, D. Xu, X. Yan, J. Chen, S. Dong, B. Zheng and F. Huang, Angew. Chem., Int. Ed., 2012, 51, 7011 CrossRef CAS PubMed.
- M. Nakahata, Y. Takashima, H. Yamaguchi and A. Harada, Nat. Commun., 2011, 2, 511 CrossRef PubMed.
- B. J. Blaiszik, S. L. B. Kramer, S. C. Olugebefola, J. S. Moore, N. R. Sottos and S. R. White, Annu. Rev. Mater. Res., 2010, 40, 179 CrossRef CAS.
- Y. Chen, A. M. Kushner, G. A. Williams and Z. Guan, Nat. Chem., 2012, 4, 467–472 CrossRef CAS PubMed.
- Frontiers of Self-Healing Materials and Applications, ed. N. Shinya, CMC Publishing Co., 2010 Search PubMed.
- Self-HealingMaterials: Fundamental, Design Strategies, and Applications, ed. S. K. Ghosh, Wiley-VCH, 2009 Search PubMed.
- T. Shu, J. Wu, M. Lu, L. Chen, T. Yi, F. Li and C. Huang, J. Mater. Chem., 2008, 18, 886 RSC.
- Z. Wei, J. H. Yang, J. Zhou, F. Xu, M. Zrinyi, P. H. Dussault, Y. Osadag and Y. M. Chen, Chem. Soc. Rev., 2014, 43, 8114 RSC.
- L. B. Cappeletti, E. Moncada, J. Poisson, I. S. Butler and J. H. Z. DosSantos, Appl. Spectrosc., 2013, 67, 441 CrossRef CAS PubMed.
- S. K. Goswami, C. J. McAdam, A. M. Lee, L. R. Hanton and S. C. Moratti, J. Mater. Chem. A, 2013, 1, 3415 CAS.
- Y. M. Chen, Z. Q. Liu, Z. H. Feng, F. Xu and J. K. Liu, J. Biomed. Mater. Res., Part A, 2013, 102, 2258 CrossRef PubMed.
- A. S. Hoffman, Adv. Drug Delivery Rev., 2012, 65, 10 CrossRef PubMed.
- Y. M. Chen, R. Ogawa, A. Kakugo, Y. Osada and J. P. Gong, Soft Matter, 2009, 5, 1804 RSC.
- K. Y. Lee and D. J. Mooney, Chem. Rev., 2001, 101, 1869 CrossRef CAS PubMed.
- G. Y. Huang, L. Wang, S. L. Wang, Y. L. Han, J. Wu, Q. Zhang, F. Xu and T. J. Lu, Biofabrication, 2012, 4, 42001 CrossRef PubMed.
- G. Y. Huang, L. H. Zhou, Q. C. Zhang, Y. M. Chen, W. Sun, F. Xu and T. J. Lu, Biofabrication, 2011, 3, 12001 CrossRef PubMed.
- H. Geckil, F. Xu, X. Zhang, S. Moon and U. Demirci, Nanomedicine, 2010, 5, 469 CrossRef CAS PubMed.
- Z. Hu, Y. Chen, C. Wang, Y. Zheng and Y. Li, Nature, 1998, 393, 149 CrossRef CAS.
- G. Ulrich, R. Ziessel and A. Harriman, Angew. Chem., Int. Ed., 2008, 47, 1184 CrossRef CAS PubMed.
- A. Loudet and K. Burgess, Chem. Rev., 2007, 107, 4891 CrossRef CAS PubMed.
- K. Rurack, M. Kollmannsberger and J. Daub, Angew. Chem., Int. Ed., 2001, 40, 385 CrossRef CAS.
- S. Atilgan, I. Kutuk and T. Ozdemir, Tetrahedron Lett., 2010, 51, 892 CrossRef CAS.
- O. A. Bozdemir, Y. Cakmak, F. Sozmen, T. Ozdemir, A. Siemiarczuk and E. U. Akkaya, Chem. - Eur. J., 2010, 16, 6346 CrossRef CAS PubMed.
- T. Ozdemir, F. Sozmen, S. Mamur, T. Tekinay and E. U. Akkaya, Chem. Commun., 2014, 50, 5455 RSC.
- F. Sozmen, B. S. Oksal, O. A. Bozdemir, O. Buyukcakir and E. U. Akkaya, Org. Lett., 2012, 14, 5286 CrossRef CAS PubMed.
- G. H. Deng, C. M. Tang, F. Y. Li, H. F. Jiang and Y. M. Chen, Macromolecules, 2010, 43, 1191 CrossRef CAS.
- J. Boekhoven, J. M. Poolman, C. Maity, F. Li, L. van der Mee, C. B. Minkenberg, E. Mendes, J. H. vanEsch and R. Eelkema, Nat. Chem., 2013, 5, 433 CrossRef CAS PubMed.
- G. Kavanagh and S. Ross-Murphy, Prog. Polym. Sci., 1998, 23, 533 CrossRef CAS.
- M. Burnworth, L. Tang, J. R. Kumpfer, A. J. Duncan, F. L. Beyer, G. L. Fiore, S. J. Rowan and C. Weder, Nature, 2011, 472, 334 CrossRef CAS PubMed.
- T. Z. Forster, Naturforscher, 1949, 4, 321 Search PubMed.
- Z. Kostereli, T. Ozdemir, O. Buyukcakir and E. U. Akkaya, Org. Lett., 2012, 14, 3636 CrossRef CAS PubMed.
- O. A. Bozdemir, S. Erbas-Cakmak, O. O. Ekiz, A. Dana and E. U. Akkaya, Angew. Chem., Int. Ed., 2011, 50, 10907 CrossRef PubMed.
Footnote |
† Electronic supplementary information (ESI) available: Synthetic procedures, spectroscopic properties, NMR spectra and additional data of synthesized compounds. See DOI: 10.1039/c5ra22993f |
|
