Hybrid van der Waals heterostructures of zero-dimensional and two-dimensional materials

Abstract

van der Waals heterostructures meet other low-dimensional materials. Stacking of about 1 nm thick nanosheets with out-of-plane anchor groups functionalized with fullerenes integrates this zero-dimensional material into layered heterostructures with a well-defined chemical composition and without degrading the mechanical properties. The developed modular and highly applicable approach enables the incorporation of other low-dimensional materials, e.g. nanoparticles or nanotubes, into heterostructures significantly extending the possible building blocks.

---

Molecular assembly of materials with precise control over their chemical composition, thickness and structure has been in the focus of physical, chemical and materials science research already for many years.^1–9 This interest is motivated by engineering materials with controlled functionalities on demand. To this end, various techniques have been developed. Typical examples are Langmuir–Blodgett (LB) technique, layer-by-layer (LbL) assembly, and self-assembled monolayers (SAMs). They have been widely used to assemble zero- and one-dimensional (0D and 1D) materials such as small molecules, nanoparticles, biomolecules, polyelectrolytes and nanotubes/-wires.^1–8 With the demonstration of free-standing atomically or single-molecularly thick sheets,^10–12 stacking them vertically in a chosen way serves as a new technique to create designed artificial materials, the so-called van der Waals (vdW) heterostructures.^9,13,14 Combination of these 2D sheets including graphene, hexagonal boron nitride or metal chalcogenides has led to mechanically stable heterostructures with high potential for applications in sensors and flexible electronics.^9,15 Recent research efforts have also been focused on the development of various covalent and non-covalent functionalization approaches to combine 2D sheets with 0D and 1D materials.^16–20 However, it remains a major challenge to assemble stable stacks of 0D/1D materials with 2D sheets without degrading the mechanical properties of the pristine sheets. Non-covalent interactions, such as van der Waals interactions and π–π stacking, are not strong enough to stably immobilize 0D/1D materials on 2D sheets. Thus the adhered materials can be easily removed by solvent rinsing or even with time and by environmental moisture.^16,19,20 On the other hand, strong covalent interactions require a change in the integral structure of 2D sheets, which degrade their initial mechanical properties.

In this work, we present a modular and broadly applicable route to create hybrid vdW heterostructures made of individual ∼1 nm thick single molecular sheets, Janus nanomembranes (JNMs),^13,21 which have well-defined anchor groups on their opposite sides, see Fig. 1, and other low-dimensional materials. JNMs are generated via electron irradiation of 4′-nitro-1,1′-biphenyl-4-thiol (NBPT) SAMs resulting in their crosslinking via formation of lateral covalent bonds and simultaneous conversion of the terminal nitro groups into amino groups²² and the subsequent release from the original substrates via the poly(methyl methacrylate) (PMMA) assisted transfer process.^23,24 The upper side of the JNM has amino groups (N-side) and the lower side has sulfur species (S-side), see Fig. 1c; both sides can be independently and chemically functionalized.²¹ Using chemical functionalization of JNMs with the desired building blocks on their one or both faces and subsequent stacking, hybrid vdW heterostructures can be assembled. In our proof-of-concept experiments, we utilize 0D carbon – fullerene C₆₀ – as a functional nanomaterial and covalently bind to the amino groups of JNMs; we also demonstrate functionalization of the S-side with Au nanoparticles (NPs), see Fig. 1d. We fabricate heterostructure stacks of the C₆₀–JNM hybrid and characterize their structural, chemical and mechanical properties by optical microscopy, helium ion microscopy (HIM), X-ray photoelectron spectroscopy (XPS) and mechanical bulging tests. To make the S-side of JNMs accessible for post-modification under various experimental conditions, a universal flip-over procedure for JNMs was developed.

Fig. 1 Schematic representation of the heterostructure assembly. (a) Formation of a NBPT SAM on a gold substrate. (b) Electron irradiation induced crosslinking and reduction of the terminal nitro groups into amino groups. (c) Formation of a free-standing JNM with the terminal N- and S-faces. (d) Functionalization of the N- and S-faces with C₆₀ and AuNP, respectively. (e) Assembly of a (C₆₀–JNM)_n (here n = 3) hybrid heterostructure by mechanical stacking. Color code for atoms: black – carbon, grey – hydrogen, blue – nitrogen, green – sulfur, and red – oxygen.

To assemble C₆₀–JNM heterostructures, we synthesized JNMs on gold substrates (JNM/Au), immobilized C₆₀ onto the N-side of the JNMs, and stacked the C₆₀–JNM hybrids on top of each other (see ESI† for details). The successful immobilization of C₆₀ onto JNM/Au was confirmed by XPS. Fig. 2a shows the XP spectra of a JNM/Au. The C1s signal consists of several peaks with binding energies (BEs) at 284.2 eV and 285.3 eV, which are due to the aromatic carbon and the C–S/C–N bonds, respectively; and the aromatic shake-up satellites at 287–290 eV.²⁴ The N1s signal at 399.3 eV is characteristic for amino groups. The S2p signal shows the presence of two sulfur species with the S2p_3/2 BEs at 162.0 and 163.2 eV, which are due to thiolates and sulfides/disulfides formed upon irradiation,²⁵ respectively. The effective thickness of a JNM calculated from the attenuation of the Au4f_7/2 signal is about 1.1 nm.²⁶ In Fig. 2b, the XP spectra of a JNM with C₆₀ grafted to the amino groups are presented.²⁷ The successful grafting is confirmed by the corresponding changes of the respective XP signals. The total intensity of the C1s signal increases by ∼30% and a new N1s peak at ∼400.3 eV appears due to the formation of C–N bonds.^27–29 The intensity ratio between this peak and the total N1s intensity is ∼30%, which indicates the percentage of amino groups on forming chemical bonds with C₆₀. Intensity of the S2p signal decreases showing an increase of the hybrid thickness (see Table S1† for thickness change).

Fig. 2 XPS characterization. (a) JNM on the original gold substrate. (b) C₆₀–JNM on the original gold substrate. C₆₀–JNM monolayer/multilayer after transfer onto 285 nm SiO₂/Si (monolayer (c), bilayer (d) and trilayer (e)). Intensities of the S2p and N1s spectra were multiplied by 7.

To demonstrate that C₆₀–JNMs can be released from their original substrate and further used for fabrication of the heterostructures, we tested their transfer onto 285 nm SiO₂/Si substrates by the PMMA assisted process.²⁴ These substrates were chosen as they enable the observation of JNMs by optical interference (see Fig. S1a†).¹⁴Fig. 2c shows XP spectra of the transferred C₆₀–JNM. The characteristics of the XP signals are similar to those of the pristine C₆₀–JNM/Au. A slight increase of the C1s peak at ∼288.3 eV is observed, which is most likely due to the presence of some PMMA residuals after the transfer.³⁰ The S2p_3/2 signal at 162.0 eV disappears and the intensity of the S2p_3/2 signal at 163.2 eV increases significantly due to the transformation of thiolates into sulfides/disulfides or into unbound thiols during the transfer process.²¹ A new doublet appears with S2p_3/2 at 167.2 eV caused by the oxidation of thiolates/sulfides/disulfides into the sulfonic group.³¹ Note that the sulfonic group is negatively charged in water, which can be used for the functionalization of the S-side of JNMs by electrostatic interactions.

For the fabrication of cm²-sized patterned C₆₀–JNM heterostructures on 285 nm SiO₂/Si, a simple method was applied. C₆₀–JNM sheets on Au/mica substrates were cut with scissors into rectangular stripes of ∼0.5 cm width and then the sheets were transferred onto the Si-wafer by putting them on top of each other in different orientations. This procedure leads to the formation of regions with either no, one, two or three sheets (Fig. S1a†). Note that the uniform contrast within the areas with varying numbers of C₆₀–JNM sheets reflects their homogeneous thickness.

As only the electron irradiated areas of NBPT SAMs are converted into JNMs and there is no lateral crosslinking between molecules in the non-irradiated areas, it is possible by selective electron irradiation to pattern JNMs, functionalize them with C₆₀ and then transfer the patterned C₆₀–JNM onto a new substrate (Fig. S1b†). Such a procedure makes it possible to produce the JNM-based hybrids in any shape without additional resist materials either by using electron irradiation through stencil masks, as in this experiment, or by standard electron beam lithography.

The assembled heterostructure stacks were characterized by XPS. We found no significant changes in the shapes of C1s, S2p and N1s signals for the bi-layer and the tri-layer of C₆₀–JNM (Fig. 2d and e), which indicates that each layer has a similar chemical composition. The obtained effective thickness of the bi-layer and tri-layer stacks is ∼3.7 nm and ∼5.4 nm, respectively, which confirms further homogeneous contributions of each layer to the total structure. This homogeneity benefits from the high reproducibility by functionalization of mechanically stable JNMs, which is difficult to achieve employing the layer-by-layer growth on conventional SAMs.^32–34

To quantitatively characterize the mechanical properties of individual C₆₀–JNMs and their heterostructures, they were studied by mechanical bulge tests. To this end, the sheets were transferred onto a silicon substrate with an array of square shaped orifices. Fig. 3a shows a helium ion microscopy (HIM) image of a C₆₀–JNM hybrid. An orifice with the spanned C₆₀–JNM is observed (marked “freestanding”), which indicates that the hybrid can support its own weight and preserve its mechanical integrity. Apart from the large homogeneous area, some wrinkles or ruptures (Fig. 3b and c) are observed, which are typical for mechanically robust nanosheets.¹⁰Fig. 3d shows a homogeneous freestanding JNM/(C₆₀–JNM)₃ heterostructure spanning over an orifice with dimensions of 40 × 44 μm². The heterostructure in Fig. 3e shows some wrinkles, which increase the imaging contrast and help to identify the freestanding membrane by HIM. Note that only the homogeneous structures as in Fig. 3d were employed for bulge tests with an atomic force microscope (AFM). To ensure that the interaction between a (C₆₀–JNM)_n and an AFM tip is the same as that for an individual JNM, a JNM was placed on top of the respective heterostructures forming the JNM/(C₆₀–JNM)_n stacks. The testing was performed by adjusting an AFM tip to the nanomembrane center,^35,36 as schematically shown in Fig. 3f. Different N₂ pressures are applied beneath the membrane, and its corresponding deflection is then recorded by AFM. Fig. 3g shows a typical pressure-deflection curve for a JNM/(C₆₀–JNM)₂ heterostructure (see Fig. S2† for JNM, C₆₀–JNM and JNM/(C₆₀–JNM)_n, n = 1 and 3). By fitting multiple curves to a pressure-deflection equation for rectangular/square membranes,^35,36 Young's modulus (E_Young) can be extracted (Fig. 3h and Table S1†). First, we compare the mechanical properties of pristine JNM with C₆₀–JNM. To this end, the in-plane elastic modulus (E_2d) has to be considered.^37–39 It is equal to E_Young multiplied by the thickness of the sheet. The obtained E_2d values for JNM (9.9 ± 1.7 N m⁻¹) and C₆₀–JNM (11.6 ± 1.7 N m⁻¹) are of the same magnitude, which shows that the mechanical robustness of a JNM is not diminished upon its covalent functionalization. Next, we compare the mechanical properties of multilayered stacks considering the respective E_Young values.³⁷E_Young for JNM/(C₆₀–JNM)₁, JNM/(C₆₀–JNM)₂ and JNM/(C₆₀–JNM)₃ are 7.5 ± 1.8 GPa, 7.2 ± 1.3 GPa and 8.7 ± 1.5 GPa, respectively (Fig. 3h). It can be clearly seen that within the measurement accuracy the Young's moduli of the JNM/(C₆₀–JNM)_n (n = 1, 2 and 3) heterostructures have similar values demonstrating that the mechanical properties are not degraded upon the assembly of the hybrid JNMs into stacks.

Fig. 3 Helium ion microscopy (HIM) imaging of C₆₀–JNM heterostructures and their mechanical properties. (a) HIM image of a C₆₀–JNM on a Si substrate with orifices. An orifice with dimensions 40 × 44 μm² is marked here as “free-standing”. (b) Magnified HIM image of the C₆₀–JNM boundary; the corresponding place is marked in (a) with an arrow. (c) Magnified HIM image of the central part of the C₆₀–JNM; the corresponding place is marked in (a) with an arrow. In (d) and (e) HIM images of an JNM–(C₆₀–JNM)₃ heterostructure spanning a Si window are shown. In (d) the nanomembrane is homogeneous whereas in (e) a fold can be recognized. (f) A schematic diagram of the bulge test set-up. (g) Typical pressure-deflection curves for a JNM–(C₆₀–JNM)₂ heterostructure. (h) Young's moduli of JNM, C₆₀–JNM and JNM–(C₆₀–JNM)_n (n = 1, 2, and 3).

To show that for the assembly of hybrid heterostructures the S-side of JNMs can also be employed, we studied its functionalization with Au NPs (Fig. 1c and Fig. 4). Negatively charged Au NPs with sizes of ∼55 and 16 nm were used to this end. As the S-side of a JNM due to the presence of sulfonic groups is also negatively charged, a positively charged adhesive polyelectrolyte layer of poly(diallyldimethylammonium chloride) was added to immobilize the negatively charged Au NPs. We employed scanning transmission ion microscopy (STIM) to image the hybrid nanomembranes suspending hexagonal grids (∼25 μm) with the functionalized S-side oriented upwards. From statistical analysis we estimate the average coverage of the 55 and 16 nm-sized Au NPs on JNMs to be ∼15% and ∼50%, respectively, showing that the coverage correlates with the NP size. As a wide variety of materials can be immobilized by electrostatic interactions,² this strategy provides a flexible route to incorporate different materials into JNM-based hybrids. The modification of the S-side of JNMs with the above-described method needs PMMA as a protection layer, which restricts the modification to conditions compatible with this layer. In case such a layer cannot be employed, the JNM can also be flipped over and transferred onto a new solid substrate where the originally bottom S-side becomes the terminal one (Fig. S3–5†).

Fig. 4 JNMs functionalized with Au nanoparticles on the S-face. Helium ion microscope images acquired in the secondary electron (SE) mode and scanning transmission ion mode (STIM). (a) SE image of JNMs functionalized with 55 nm Au nanoparticles and transferred onto a grid. (b) and (c) STIM images show that the nanoparticles are uniformly distributed with an average coverage of ∼15%. (d) SE image of JNMs functionalized with 16 nm Au nanoparticles and transferred onto a grid. (e) and (f) STIM images showing that the nanoparticles are uniformly distributed with a coverage of ∼50%. Dark areas (see the arrow in (e)) are residues from sample preparation.

Conclusions

In summary, we have presented a modular and highly applicable approach for the assembly of cm²-sized vdW hybrid heterostructures. This approach is based on the utilization of ∼1 nm thick bifacial and mechanically stable JNMs, their chemical functionalization and subsequent stacking into layered heterostructures. In the present study the heterostructures of JNMs with C₆₀ and gold nanoparticles were investigated. The possibility of bifacial chemical functionalization of JNMs paves the way to hybrid vdW heterostructures with a variety of other 0D and 1D materials.
