Composite cathode material β-LiVOPO₄/LaPO₄ with enhanced electrochemical properties for lithium ion batteries

Abstract

A composite cathode material, β-LiVOPO₄/LaPO₄, is synthesized by a sol–gel method. The synthesized samples are characterized by XRD, SEM, TEM, EDS, XPS, and electrochemical tests. Results indicate that LiVOPO₄ has an orthorhombic structure with a Pnma space group and that LaPO₄ has a monazite structure with a P2₁/n space group. EDS and TEM results illustrate that LaPO₄ with typical sizes of 10–40 nm is homogeneously distributed on the surface of primary LiVOPO₄ particles. The synthesized β-LiVOPO₄/LaPO₄ exhibits much better electrochemical performance than bare β-LiVOPO₄. The β-LiVOPO₄/LaPO₄ samples delivered an initial discharge capacity of about 127.0 mA h g⁻¹ at 0.1 C and possessed favorable capacities at rates of 0.5 and 1 C. Therefore, surface modification of crystalline LaPO₄ is an effective way to improve the electrochemical performance of β-LiVOPO₄.

---

Introduction

Lithium-ion batteries are rechargeable batteries that can be used in portable electronic devices, electric vehicles, and hybrid electric vehicles, among others, because of their high specific capacity, long cycle life, and high operating voltage.^1,2 A significant amount of research has focused on new cathode materials for lithium-ion batteries. After Goodenough's laboratory^3–5 published their research results, interest in polyanionic compounds as lithium storage electrodes for rechargeable batteries grew. Specifically, lithium transition metal phosphates, such as LiMPO₄ (M = Fe, Mn, or Co),^6–8 Li₃V₂(PO₄)₃ (M = V, Fe, or Ti),^9–11 LiVPO₄F,^12,13 and LiVOPO₄,¹⁴ have gained extensive attention as cathode materials because of their high energy density, low cost, and excellent thermal stability.

LiFePO₄ is the simplest, most widely studied, and potentially most useful of these cathode materials because of its high lithium intercalation voltage (3.5 V vs. Li), high theoretical capacity of 170 mA h g⁻¹, and low cost.¹⁵ Compared with LiFePO₄, lithium vanadyl phosphate (LiVOPO₄) exhibits higher energy density at nearly the same theoretical capacity of 166 mA h g⁻¹ and a higher lithium intercalation potential of about 4 V.¹⁴ LiVOPO₄ exists as α-LiVOPO₄ (triclinic, space group P̄1) or β-LiVOPO₄ (orthorhombic, space group Pnma), which exhibit electronic conductivities of about 10⁻¹¹ and 10⁻¹⁰ S cm⁻¹, respectively.^16,17 The orthorhombic phase has been extensively investigated because of its excellent ion-intercalation properties. However, the poor electronic and ionic conductivity has been an obstacle to the development of LiVOPO₄.^18,19

Carbon coating, nano-sizing, porous structures, and morphology tailoring have been investigated to improve the performance of LiVOPO₄ cathode materials; however, these techniques present certain disadvantages.^20–22 Pure-phase LiVOPO₄, for example, is synthesized mainly through sintering in air, which results in negative effects on carbon coating and metal doping and leads to poor electrochemical performance. Hence, exploring other novel ideas to realize improved Li battery performance is necessary.

Introducing electrical additives to the surface of cathode materials is an effective way to improve the electrochemical performances of phosphate-based cathode materials.^23–25 M. M. Ren synthesized β-LiVOPO₄/RuO₂ composites presenting good electrochemical Li ion intercalation performance because of enhanced electrical conductivity and Li ion diffusion.²⁰ However, the electrical additives were only coated at a micro-scale level onto the pristine β-LiVOPO₄ particles so that improvements in the electrochemical performance of the lithium batteries were not very obvious. According to the ref. 26 introducing LaPO₄ (with good ionic conductivity) to the surface of a cathode material (Li[Ni_0.5Co_0.2Mn_0.3]O₂) is an effective way to improve the electrochemical performance of Li[Ni_0.5Co_0.2Mn_0.3]O₂.

In the present study, β-LiVOPO₄/LaPO₄ composite was synthesized and characterized, and the effects of LaPO₄ surface modification on the structural and electrochemical properties of the composite were investigated.

Experimental

The β-LiVOPO₄/LaPO₄ composite was synthesized via a sol–gel method. First, a stoichiometric amount of NH₄VO₃ (AR, ≥ 99.0%), LiNO₃ (AR, ≥ 99.0%), (NH₄)₂HPO₄ (AR, ≥ 99.0%), and La(NO₃)₃(AR, ≥ 99.0%) at 1 : 1.05 : 1.03 : 0.03 molar ratio were dissolved in water with magnetic stirring at 85 °C for 2 h. When the raw materials were completely dissolved, C₂H₂O₄·2H₂O (AR, ≥ 99.0%) was dissolved as both the chelating agent and reducer. Next, the mixture was continuously stirred at 85 °C until a dark blue gel formed. This gel was then dried and sintered at 450 °C for 8 h in air atmosphere to form β-LiVOPO₄/LaPO₄ composite powder. The product was spontaneously cooled to room temperature, and the β-LiVOPO₄/LaPO₄ composite was obtained. Bare β-LiVOPO₄ was synthesized via the same method but without La(NO₃)₃. The molar ratio of NH₄VO₃, LiNO₃, and (NH₄)₂HPO₄ used was 1 : 1.05 : 1.

The elemental composition of the powders was determined by XPS on an instrument (Kratos Model XSAM800) equipped with a Mg Kα achromatic X-ray source (1235.6 eV) and a JEOL-energy dispersive spectroscopy (EDS) detector. Structural and crystalline phase analyses of the products were conducted by XRD (Rint-2000, Rigaku) using Cu Kα radiation. The samples were observed by SEM (JEOL JSM-5600LV), and TEM (Tecnai G12). Elemental carbon analysis was performed using C–S analysis equipment (Eltar, Germany).

Electrochemical characterizations were performed using CR2025 coin-type cells. The composite electrodes were prepared by mixing the as-synthesized composite with carbon black and polyvinylidene difluoride at a weight ratio of 80 : 10 : 10 using NMP as the solvent. The cathode was prepared by spreading the mixture on an aluminum foil. Charge–discharge tests of the samples were performed in coin cells with cathodes and lithium anodes. After solvent evaporation, the electrodes were punched to form disks with 14 mm diameter and then dried at 120 °C for 4 h. The test cell consisted of the positive electrode and lithium foil negative electrode separated by a porous polypropylene film, and 1 mol L⁻¹ LiPF₆ in EC : EMC : DMC (1 : 1 : 1 v/v) as the electrolyte. The coin cells were assembled in a dry Ar-filled glove box. The cells were charged and discharged over a voltage range of 3.0–4.5 V versus a Li/Li⁺ electrode at 25 °C. The cycling and charge–discharge performance of the cells was tested using an automatic galvanostatic charge–discharge unit (LAND battery cycle). Cyclic voltammograms were recorded with a scan rate of 0.1 mV s⁻¹ between 3.0 and 4.5 V.

Results and discussion

The XRD patterns of the synthesized powders are shown in Fig. 1. The sharp peaks in the patterns indicate that the powders are well crystallized. The pattern of the β-LiVOPO₄ powders is consistent with the JCPDS data (PDF#85-2438) and literature reports.^5,25 The main crystalline phase in both samples represents an orthorhombic structure with a Pnma space group. A subtle difference may be observed between bare β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ from 28° to 31° (marked with an oval). The main planes of (1 2 0), (2 1 0), (0 1 2), and (−1 1 2) indicate the diffraction peaks of impurities corresponding to the peaks for LaPO₄, which is consistent with the JCPDS data (PDF#83-0651). These results indicate that LaPO₄ has a crystalline phase and a monazite structure with a P2₁/n space group. The weight percentage of LaPO₄ in the β-LiVOPO₄/LaPO₄ composite is 4%. No other diffraction peak is found in the XRD patterns. The amount of carbon in the composites is about 1.2 wt%, as determined by the C–S analysis method. Carbon remaining in the composite could not be detected by XRD, which indicates that the residual carbon is amorphous.

Fig. 1 XRD patterns of the synthesized samples.

SEM images of bare β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ are shown in Fig. 2. The surfaces of bare β-LiVOPO₄ particles [Fig. 2(a) and (b)] are slightly smoother than those of β-LiVOPO₄/LaPO₄ [Fig. 2(c) and (d)]. In addition, the particle sizes of β-LiVOPO₄/LaPO₄ sample are much smaller than those of bare β-LiVOPO₄, which is beneficial to intercalation and de-intercalation of Li ions over short paths. Moreover, β-LiVOPO₄/LaPO₄ has more pores than β-LiVOPO₄; these pores cause an increase in the specific area of the former. The specific surface areas of β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ are 3.012 and 3.898 m² g⁻¹, respectively.

Fig. 2 (a and b) SEM images of β-LiVOPO₄; (c and d) SEM images of β-LiVOPO₄/LaPO₄.

HRTEM images of β-LiVOPO₄/LaPO₄ are shown in Fig. 3. As seen in Fig. 3(a) and (b), the β-LiVOPO₄ particle is surrounded by LaPO₄ nanoparticles, and the particle size of LaPO₄ is within 10–40 nm. The presence of LaPO₄ as observed in the present study is different from that described in previous literature reports, in which LaPO₄ may be observed as a thin amorphous layer on the surface of the particles.²⁵ To verify the characteristics of LaPO₄ modification, local amplification of one of the modification sites (marked with a blue circle) was performed, as shown in Fig. 3(c). One type of lattice fringe was found in the LaPO₄ modification site [right section in Fig. 3(c)]. The lattice fringe is attributed to LaPO₄ with an inter-planar spacing of 3.12 Å, which corresponds to the (1 2 0) lattice plane. These results indicate that crystalline-phase LaPO₄ particles are distributed on the surface of β-LiVOPO₄ particles, which is consistent with the XRD results. Fig. 3(d) and (e) reveal the Fourier transform (FFT) of the selected areas. The FFT image in Fig. 3(d) shows the diffraction spots of β-LiVOPO₄, while the FFT image in Fig. 3(e) corresponds to the diffraction spots of LaPO₄.

Fig. 3 (a and b) TEM image of β-LiVOPO₄/LaPO₄ composite material (c) the local amplification of one of selected LaPO₄ site (d and e) fourier transform (FFT) of the selected areas.

To analyze the uniformity of element distribution in LaPO₄, EDS analysis was carried out. Fig. 4 shows the EDS patterns of vanadium, phosphorus, and lanthanum in the β-LiVOPO₄/LaPO₄ sample. Vanadium and phosphorus are uniformly distributed in the sample, and lanthanum is homogeneously dispersed on the surface of primary particles. These results clearly illustrate that crystalline LaPO₄ is homogeneously on the surface of β-LiVOPO₄ primary particles.

Fig. 4 X-ray spectroscopy (EDS) analysis of vanadium, phosphorus and lanthanum for β-LiVOPO₄/LaPO₄ composite material.

The XPS spectra of β-LiVOPO₄/LaPO₄ sample are shown in Fig. 5. Peaks appearing at 54.96, 130.70, 531.80, 517.28, and 853.08 eV can be assigned to Li1s, P2p, O1s, V2p, and La3d3, respectively. The test values are fairly consistent with the ref. 27 which reports that Li⁺, P⁵⁺, O²⁻, and La³⁺ cations exhibit characteristic peaks of Li1s, P2p, O1s, and La3d3 at 54.9, 130.7, 531.8, and 853.0 eV, respectively. In addition, according to another ref. 28 V⁴⁺ (VO₂) cations exhibit a peak of V2p at 517.3 eV. These results reveal that the valence state of vanadium in the external surface area of the sample is +4 and that of lanthanum is +3. The results are consistent with the discussion above.

Fig. 5 X-ray photoelectron (XPS) spectra of β-LiVOPO₄/LaPO₄ composite material.

The charge–discharge curves of Li/β-LiVOPO₄ and Li/β-LiVOPO₄/LaPO₄ cells at different rates of 0.1, 0.25, 0.5, and 1 C (160 mA g⁻¹) in the voltage range of 3.0–4.5 V at 25 °C are illustrated in Fig. 6(a). The ΔV of charge–discharge plateaus in the curves of the β-LiVOPO₄/LaPO₄ cell is much smaller than that of bare β-LiVOPO₄. In addition, the initial discharge capacities of β-LiVOPO₄ at rates of 0.1, 0.25, 0.5, and 1 C are about 109.1, 94.3, 76.7, and 54.6 mA h g⁻¹, respectively, whereas those of β-LiVOPO₄/LaPO₄ are about 127.0, 120.0, 103.6, and 83.0 mA h g⁻¹, respectively. Apparently, the rate capacity of β-LiVOPO₄/LaPO₄ is much better than that of β-LiVOPO₄.

Fig. 6 (a and b) Charge–discharge profiles and cycling performance of β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ cathode; (c) cyclic voltammetry curves for β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ cathode at a scan rate of 0.1 mV s⁻¹.

Based on Fig. 6(b), the discharge capacities of β-LiVOPO₄ at rates of 0.1, 0.25, 0.5, and 1 C are about 99.2, 84.5, 63.3, and 36.0 mA h g⁻¹ after 30 cycles, which indicates that the cell respectively retains 90.9%, 89.6%, 82.5%, and 65.9% of its initial discharge capacity. Compared with β-LiVOPO₄, the discharge capacities of β-LiVOPO₄/LaPO₄ at rates of 0.1, 0.25, 0.5, and 1 C are about 125.0, 116.0, 97.0, and 73.6 mA h g⁻¹ after 30 cycles, and the cell respectively retains 98.4%, 96.7%, 93.6%, and 73.6% of its initial discharge capacity. Thus, the capacity retention of β-LiVOPO₄/LaPO₄ displays greater advantages compared with that of bare β-LiVOPO₄ even at higher rates.

From the discussion above, we can draw the conclusion that the composite cathode material β-LiVOPO₄/LaPO₄ shows better electrochemical performance than β-LiVOPO₄ because of introduction of the ionic conductor LaPO₄ to the 3D network between β-LiVOPO₄ primary particles.

Fig. 6(c) shows the cyclic voltammetry curves of β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ at a scan rate of 0.1 mV s⁻¹ between 3.0 and 4.5 V. The redox processes of β-LiVOPO₄ and β-LiVOPO₄/LaPO₄ occur at 3.822/4.160 V and 3.839/4.066 V, respectively, which may be assigned to the V⁴⁺/V⁵⁺ couples and attributed to LiVOPO₄. The voltage gap between the redox peaks of β-LiVOPO₄/LaPO₄ is obviously much smaller than that of bare β-LiVOPO₄, which indicates that β-LiVOPO₄/LaPO₄ presents much better reversibility for Li⁺ extraction/insertion. These results are in accordance with the charge and discharge curves obtained previously.

Conclusions

β-LiVOPO₄/LaPO₄ was synthesized via the sol–gel method, and crystalline LaPO₄ was successfully on the surface of β-LiVOPO₄ primary particles. Introduction of the ionic conductor LaPO₄ to the 3D network between β-LiVOPO₄ primary particles and the small particle and pore structure of the matrix enhanced the discharge capacity, cyclic stability, and capacity retention of the resultant composite compared with those of bare β-LiVOPO₄. Hence, introduction of LaPO₄ to β-LiVOPO₄ is an effective way to enhance the electrochemical performance of LiVOPO₄.
