Multispectral upconversion luminescence intensity ratios for ascertaining the tissue imaging depth

Kai Liu abc, Yu Wang ab, Xianggui Kong *a, Xiaomin Liu a, Youlin Zhang a, Langping Tu a, Yadan Ding bc, Maurice C. G. Aalders *c, Wybren Jan Buma b and Hong Zhang *b
aState Key Laboratory of Luminescence and Applications, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, P. R. China. E-mail: xgkong14@ciomp.ac.cn; Tel: +86-0431-86176313
bVan't Hoff Institute for Molecular Sciences, University of Amsterdam, Science Park 904, 1098 XH Amsterdam, The Netherlands. E-mail: h.zhang@uva.nl; Tel: +31-020-5256976
cDepartment of Biomedical Engineering and Physics, Academic Medical Center, University of Amsterdam, 1105 AZ Amsterdam, The Netherlands. E-mail: m.c.aalders@amc.uva.nl; Tel: +31-020-566 3829

Received 17th April 2014 , Accepted 3rd June 2014

First published on 5th June 2014


Abstract

Upconversion nanoparticles (UCNPs) have in recent years emerged as excellent contrast agents for in vivo luminescence imaging of deep tissues. But information abstracted from these images is in most cases restricted to 2-dimensions, without the depth information. In this work, a simple method has been developed to accurately ascertain the tissue imaging depth based on the relative luminescence intensity ratio of multispectral NaYF4:Yb3+,Er3+ UCNPs. A theoretical mode was set up, where the parameters in the quantitative relation between the relative intensities of the upconversion luminescence spectra and the depth of the UCNPs were determined using tissue mimicking liquid phantoms. The 540 nm and 650 nm luminescence intensity ratios (G/R ratio) of NaYF4:Yb3+,Er3+ UCNPs were monitored following excitation path (Ex mode) and emission path (Em mode) schemes, respectively. The model was validated by embedding NaYF4:Yb3+,Er3+ UCNPs in layered pork muscles, which demonstrated a very high accuracy of measurement in the thickness up to centimeter. This approach shall promote significantly the power of nanotechnology in medical optical imaging by expanding the imaging information from 2-dimensional to real 3-dimensional.


1 Introduction

Fluorescence imaging has great potential in early stage cancer diagnosis because of its high sensitivity and resolution.1–3 Especially with the development of near infrared (NIR) light excitable lanthanide ion (Ln3+) doped upconversion nanoparticles (UCNPs), more and more attention has been paid on the upconversion scheme.4–19 NIR light excitation has minimal absorption/scattering in animal tissue and will not excite the biological environment, which make UCNPs superior in luminescence imaging over traditional fluorescence compounds like organic dyes and quantum dots (QDs) that need ultraviolet (UV) to visible (Vis) light for excitation. As Chen et al. demonstrated in 2012, the Tm3+ doped UCNPs can image up to 3.2 cm thick in pork tissue, thus UCNPs is an excellent luminescent probe for in vivo imaging of deep tissue.13 Zhang also synthesized several different UCNPs and systematically studied their microscopic luminescence imaging depths by embedding the nanoparticle labeled cells in different animal tissues.18 Moreover, benefiting from the abundantly discrete energy level structures of the doped Ln3+ ions, UCNPs show a unique optical property of multiband upconversion luminescence (UCL) spanning from ultraviolet to near infrared, and the spectrum can be modulated by simply varying the doping ions, e.g. Er, Tm, Ho, etc. and/or relevant concentrations.20–24 Based on this, multicolor imaging methods can be aptly achieved for simultaneously imaging several different lesions with single 980 nm excitation.25,26 We also developed a multifunctional nanoplatform for cancer cell imaging and photodynamic therapy upon the selective energy transfer from multicolored NaYF4:Yb,Er UCNPs to surface covalently functionalized photosensitizers Rose Bengal (RB).27 All these efforts indicated the prospect of UCNPs in tissue imaging and/or therapy.

Despite this progress, how to relate these images to the exact position of the lesion, i.e. how to accurately locate the tissue depth of luminescence probe labeled cancer, remains a big challenge.28,29 In clinical oncology it has been proved that the invasion depth has a close relationship with cancer metastasis,30–32 and thus the determination of cancer depth is of great significance in cancer staging and prognosis. However, because of the intrinsic complex of the interactions between light and animal tissues (absorption, scattering, reflection, etc.), it is usually difficult to resolve the lesion from traditional single-color planar imaging (only lateral distribution of the luminescent probes is acquired) in which the detected signal intensity has a nonlinear dependence on the propagation depth in surrounding tissue, especially when the concentration of luminescent probes is taken into account. In this aspect, fluorescence molecular tomography (FMT) has recently been developed to reconstruct fluorescence images.33,34 However, this effort is often interfered by the complex light source arrays and detection techniques, and the requirements of intensive computation and complicated data analysis. Moreover, most present FMT techniques have to combine with CT or MRI to improve the photon reconstruction and image visualization.35,36 Thus a simple and independent method of evaluating the lesion depth is very demanding.

In this work, we have established a theoretical model which can be used to have an easy but accurate assessment of the depth of luminescence probes embedded in tissue based on multispectral luminescence of UCNPs. The parameters in the deduced quantitative relation between the light propagation depth and the UCL spectrum were fixed from tissue mimicking liquid phantoms, and the setup is depicted in Fig. 1, where UCNPs were encapsulated into a capillary tube and embedded in the tissue mimicking liquid phantoms. The optical path-length on excitation and emission could be well separately adjusted and the corresponding UCL spectra were recorded by PMT respectively. The integrated intensity ratio of the green and red emission was used for sensing the depth. The deduced relation between the relative intensities and depth was successfully used to determine, with high accuracy, the depth of the UCNPs embedded in pork muscle tissue up to centimeter.


image file: c4nr02090a-f1.tif
Fig. 1 (A) Schematic of the setup used for light penetration depth dependent UCL spectrum study. (B), (C), and (D) are the three different working modes. The liquid phantom cuvette moves along the directions shown by the dashed lines.

2 Experiments and methods

2.1 Synthesis of NaYF4:Yb,Er UCNPs

Hydrophobic NaYF4:Yb(20%),Er(2%) UCNPs of hexagonal phase were firstly synthesized by a solvothermal method according to the literature.37 In a typical synthesis procedure, 236.54 mg YCl3·6H2O (0.78 mmol), 77.48 mg YbCl3·6H2O (0.2 mmol), and 7.64 mg ErCl3·6H2O (0.02 mmol) were dissolved in 3 mL oleic acid (OA) and 7 mL 1-octadecene (ODE), and heated up to 156 °C under an argon atmosphere and maintained at that temperature for 1 h to obtain the OA stable lanthanide precursors. The precursor solution was cooled down to room temperature, then 148.21 mg NH4F (4 mmol) and 100.02 mg NaOH (2.5 mmol) were added into the solution and heated up to 300 °C and maintained for 90 min. The received nanoparticles were washed with ethanol at least three times and re-dispersed in 10 mL hexane.

In order to make the NaYF4:Yb,Er water dispersible, the hydrophobic ligands of oleic acid (OA) capping outside UCNPs were removed according to a previously reported ligand-free method.38 Briefly, 5 mL of OA capped UCNPs was mixed with 10 mL HCl solution (pH ∼ 3) and then rigorously stirred for 2 h at room temperature. After that, UCNPs were transferred into the water layer after standing 10 min. The ligand free UCNPs in the water layer were washed with ether 3 times at least and re-dispersed in 5 mL water.

2.2 Liquid phantom experimental stage

To simulate the UCL attenuation in tissue, a special sample chamber equipped with a two-dimensional (2-D) translation stage was setup in our study, as shown in Fig. 1A. The propagation distance of the excitation light and emission light can be separately controlled. UCNPs, encapsulated in a small glass capillary (1 mm outer diameter) at a concentration of 10 mg mL−1, were dipped into the liquid phantom vertically. The tissue-equivalent liquid phantom39 was used as a simulation model and poured into a 10 mm × 10 mm silica cuvette, which was fixed on the 2-D translation platform. The optical properties were adjusted by the relative concentration of India Ink (absorption component) and Intralipid (scattering component). The spectra at different depths were recorded by PMT in the SPEX system with a 980 nm laser excitation of 700 mW cm−2. In excitation mode (Ex mode, Fig. 1B), the liquid phantom cuvette moves along the excitation direction, i.e. Y-axis, in steps of 1 mm, the UCL spectra were recorded at each step with an SPEX spectrophotometer. In emission mode (Em mode, Fig. 1C), the cuvette moves along the emission direction, i.e. X-axis, in steps of 1 mm. In reflection mode (Ref mode, Fig. 1D), the cuvette moves along the excitation direction and the emission direction simultaneously.

Considering the absorption difference of real animal tissue at the two wavelengths (540 and 650 nm), a second absorption component (Rose Bengal) was also added into the liquid phantoms at different concentrations to simulate further the imaging depth of NaYF4:Yb,Er nanoparticles in real tissue. The optical properties of liquid phantoms can be well tuned by the relative concentration of the three components India Ink, Rose Bengal and Intralipid. The absorption coefficients and scattering coefficients are given below, sample A: μa = 0.872 cm−1, μs = 8.2 cm−1 (540 nm), μa = 0.306 cm−1, μs = 5.2 cm−1 (650 nm); sample B: μa = 1.362 cm−1, μs = 8.2 cm−1 (540 nm), μa = 0.308 cm−1, μs = 5.2 cm−1 (650 nm); sample C: μa = 1.362 cm−1, μs = 16.4 cm−1 (540 nm), μa = 0.308 cm−1, μs = 10.4 cm−1 (650 nm).

2.3 Characterization

Structural characterization was performed with a Philips Morgagni™ transmission electron microscope (FEI Company, US). UV-Vis absorption spectra of solutions in a quartz cuvette (1 cm) were recorded with a Hewlett-Packard/Agilent 8453 diode-array biochemical analysis UV-Vis spectrophotometer. The steady-state UCL spectra of UCNPs were detected using a SPEX Fluorolog-3spectrofluorometer (HORIBA JobinYvon, France) where a CW semiconductor diode laser of 980 nm was used for excitation.

2.4 Animal tissue depth evaluation using UCNPs

To validate the methodology of using multicolor UCL imaging to determine the tissue depth, layered pork muscle tissue (thickness = 0.65 mm) was utilized as the model. In the experiment, 50 μL of NaYF4:Yb,Er UCNP solution (10 mg mL−1) were firstly dropped onto a layer of pork muscle, which can seep into the tissue within a few seconds. Then more layers of fresh pork muscle (label-free) were covered layer by layer onto the one labeled with UCNPs, and the corresponding UCL spectra at different tissue depths were recorded using an SPEX Fluorolog-3 system under 980 nm excitation (700 mW cm−2). The luminescence intensities at 540 nm and 650 nm were used for quantitative analysis. The real color UCL imaging was recorded using a Canon Power Shot S120 digital camera by putting an 890 nm short-pass filter (Semrock) in front to eliminate the scattered 980 nm laser light.

3 Results and discussion

3.1 Characterization of NaYF4:Yb,Er nanoparticles

Fig. 2A is the transmission electron microscopy (TEM) image of the ligand free NaYF4:Yb,Er nanoparticles and the average diameter is 39 nm. Fig. 2B is the corresponding selected area electron diffraction (SAED) pattern, which confirms that the as-synthesized UCNPs are in hexagonal phase which is known to have high upconversion efficiency.35
image file: c4nr02090a-f2.tif
Fig. 2 (A) TEM image of the NaYF4:Yb,Er UCNPs. (B) Selected area electron diffraction (SAED) diagram of UCNPs.

Fig. 3A is the energy level structures of Yb3+ and Er3+ co-doped UCNPs and there are two main UPL bands around 540 nm and 650 nm, respectively. Considering that the allowed excitation power density is limited in animal tissues, we began with the excitation power dependence of the UCL spectrum. The upconversion spectra shown in Fig. 3B were taken under relative weak excitation densities from 175 to 700 mW cm−2, well below the UCL saturation threshold. The UCL in the visible region exhibits the feature of Er3+, a green band around 540 nm and a red one around 650 nm, corresponding to transitions of 4S3/24I15/2 and 4F9/24I15/2 in the doped Er3+ ions, respectively (Fig. 3A). The spectra demonstrate a monotonic increase with the excitation power without saturation. The excitation power density dependence of the two UCL bands is shown in Fig. 3C. From the slope of linear fitting in the log–log scale, it can be concluded that the upconversion emission has a quadratic dependence on the 980 nm excitation power, showing that the UCL originates from two-photon processes, no higher order process is significantly involved. An ideal luminescence marker should have a minimal or no bleaching effect under long time irradiation, thus we studied specifically the photostability of the two UCNP emission bands under 30 min continuous 980 nm excitation and the results are shown in Fig. 3D. There is no noticeable photodegradation. Based on these studies, we came to the conclusion that UCNPs could serve as ideal contrast agents for long-term luminescence imaging.


image file: c4nr02090a-f3.tif
Fig. 3 Optical property results of UCNPs. (A) Upconversion luminescence process in NaYF4:Yb,Er UCNPs. (B) UCL spectra of UCNPs in water (1 mg mL−1) under 980 nm excitation at different excitation power from 175 to 700 mW cm−2. (C) Power dependence curves of the two emission bands at 540 nm and 650 nm. (D) Photostability of the UCL under 30 min continuous 980 nm illumination (600 mW cm−2).

3.2 Depth dependent UCL in liquid phantom

To study the path-length effects on UCL spectra a 2-D translation platform was built up as shown in Fig. 1A, in which the excitation and emission processes could be separately controlled by simply adjusting the liquid phantom cuvette along different directions. Fig. 4 are the extinction spectra of the different components of the liquid phantom used in our study. India Ink and Intralipid were served respectively as the main absorption and scattering components. From the spectra we can see that their extinction coefficients at short wavelength (e.g. 540 nm) are higher than those at longer wavelength (e.g. 650 nm). Both the Intralipid and India Ink have linear response of extinction coefficients to their concentrations (Fig. S1 and S2 in the ESI), thus we could control the optical properties by modulating the relative concentrations of the two. Since the hemoglobin in real animal tissue has high absorption around 540 nm, Rose Bengal was also added into the liquid phantom to further enhance the absorption in this spectral region. Fig. 4B shows the extinction spectra of liquid phantoms with and without Rose Bengal. The small peak detected around 540 nm in the red curve can be attributed to the characteristic absorption of Rose Bengal. The UCL spectra recorded in Em-, Ex- and Ref modes are shown in Fig. S3A–C in the ESI, and the corresponding integrated intensities of the green and the red bands are given in Fig. 5A–C (mono-logarithm scale). In Ex mode (Fig. 5A), both the green and red emissions attenuate exponentially with the same slope (∼−4.3), indicating that the spectral shape does not vary with the propagation path-length of the excitation light. Here the contribution of surface reflection is already excluded. In Em mode (Fig. 5B), however, the green band attenuates faster than the red one, which is understandable because the liquid phantom absorbs and scatters more at shorter wavelength (Fig. 4). The fitted attenuation slopes are −3.25 and −2.72 for the green and red bands, respectively. The slope difference between Ex- and Em modes is related to the two photon nature of the UCL process. Fig. 5C shows the fitted slopes of Ref mode; both emission bands attenuate significantly with depth; the fitted attenuation slopes are −7.57 and −7.01, respectively. The attenuation slopes in Ref mode are found to be exactly the sum of the slopes in Ex- and Em modes. In Fig. 5D, we show the penetration depth dependent intensity ratio of green/red UCL (G/R ratio). Exponential relation is found in Em- and Ref modes, whereas it remains almost constant in Ex mode. This indicates that the propagation path-length of excitation light has a negligible effect on the G/R ratio.
image file: c4nr02090a-f4.tif
Fig. 4 (A) Wavelength dependent extinction coefficients of the components of the liquid phantom. (B) Extinction spectra of the liquid phantom without (black curve) and with (red curve) Rose Bengal.

image file: c4nr02090a-f5.tif
Fig. 5 Penetration depth dependence of the UCL intensities in (A) Ex mode, (B) Em mode, and (C) Ref mode in liquid phantoms (0.025% India Ink and 0.5% Intralipid). (D) G/R ratio in the three modes. Error bars are marked in the figures.

3.3 Theoretical model

In our experiments the 980 nm laser was collimated into a planar beam of 10 mm2 to excite the UCNP capillary tube embedded in the cuvette that is filled with liquid phantoms. The UCL was thus treated as a line light source, and the energy fluence attenuated isotropically in the tissue. Based on the optical diffusion theory,40,41 the distribution of the excitation light and the emission light along their propagation direction (z) inside tissue could be written as:

image file: c4nr02090a-t1.tif(1)

image file: c4nr02090a-t2.tif(2)
here Φx and Φm and are the influent intensities of excitation light and emission light inside the tissue, Px0 and Pm0 are the initial intensities of the incident excitation light (e.g. 980 nm) and the emission light (e.g. 540 or 650 nm), μa,x, μs,x and μt,x are the absorption coefficient, reduced scattering coefficient and the total attenuation coefficient for the excitation light, μeff,m is the effective attenuation coefficient for the emission light, Dx and Dm are the diffusion coefficients of excitation and emission, respectively. The solution for the emission diffusion equations is:

image file: c4nr02090a-t3.tif(3)

From eqn (3) we can see that the fluorescence energy fluence Φm is affected not only by the initial luminescence intensity Pm0 but also by the tissue optical property μeff,m. Regarding NaYF4:Yb,Er UCL, we can divide the fluorescence energy fluence into two parts Φ540 and Φ650, corresponding to the two emission bands around 540 and 650 nm, respectively. The intensity ratio R detected is therefore:


image file: c4nr02090a-t4.tif(4)
and

μeff2 = 3μαμt = 3μα(μα + μs)(5)

The first item at the right side of eqn (4) is constant that is determined by the intrinsic optical properties of UCNPs, as proved in Fig. 5A. And the diffusion coefficients D540 and D650 in the second part are also constant for a homogeneous tissue. Thus from this equation we can deduce that the G/R ratio detected at the surface follows an exponential decay pattern with increasing the tissue depth, and the attenuation slope can be calculated from the difference of effective attenuation coefficients at these two wavelengths.

3.4 Ascertaining the tissue imaging depth with multispectral upconversion luminescence

‘Real tissue’ contains hemoglobin and other chromophores, which lead to more absorption around 540 nm compared to 650 nm. To mimic this, studies were performed in liquid phantoms with different optical properties by varying the concentration of India Ink, Rose Bengal and Intralipid. The corresponding attenuation slopes detected in Ref mode are given in Fig. 6 (the corresponding spectra data are given in Fig. S4–S6 in the ESI). In sample A, the attenuation slopes are −5.46 and −4.71 for green and red bands, respectively (Fig. 6A). Adding more RB into the phantom, the slope of the green band changes to −5.95 while the red band remains almost constant (−4.74, Fig. 6B). This is because RB has maximal absorption around 540 nm, which makes the green band attenuate faster. In Fig. 6C, more Intralipid is in sample B, the scattering increases while the absorption remains the same around 540 nm and 650 nm. Sharper decreases of the intensities are observed with the slopes of −6.12 and −5.23, which is predictable since scattering is enhanced in both excitation and emission. Fig. 6D shows the G/R ratio of samples A, B and C, where the fitted slopes are −1.72, −2.76 and −2.80, respectively. Deviating from sample A, the slope variations are approximately the same for samples B and C although they have different amounts of Intralipid (the amount of India Ink/Rose Bengal was the same). This result tells us that the G/R intensity ratio is more sensitive to the absorption coefficient than the scattering coefficient. In fact it is in line with eqn (4) and (5), where the effective attenuation coefficient has a linear relationship with μs but a quadratic one with μa.
image file: c4nr02090a-f6.tif
Fig. 6 (A), (B) and (C) are the depth dependent UCL intensities detected in three liquid phantom samples with different components. (D) is the corresponding G/R intensity ratio attenuation curves of the three samples. Error bars are marked in the figures.

So far we have built up the quantitative relationship between the propagation depth of UCNPs in tissue mimic liquid phantoms and the UCL spectra. In the following, we will validate the method employing layered pork muscle tissue. Fig. S7 shows the extinction spectra of pork muscle with different thicknesses (or layers). As pork muscles contain a high concentration of myohemoglobin which has relatively high absorption around 540 nm, the effective attenuation coefficient is thus higher than that of 650 nm. The photographs in Fig. 7A and B are the real color UCL images recorded in Ex- and Em modes, respectively. The incident excitation power density at 980 nm was 700 mW cm−2 at the surface. In Ex mode, although the emission intensity dropped proportionally with the tissue depth (the actual excitation power decreased), the color remained unchanged. In contrast, the color of UCL in Em mode changed from green to red with the tissue depth, reflecting the higher absorption of muscle hemoglobin to 540 nm emission. More quantitative analyses were carried out by recording the UCL spectra at different depths of Em-, Ex- and Ref modes (data are shown in Fig. S8–S10 in the ESI), and the UCL intensities around 540 nm and 650 nm are given in Fig. 7C and D. Fig. 7C is the depth dependent UCL intensity recorded in Ex mode, where a similar tissue penetration depth dependence is observed for the green and the red emission. Fig. 7D shows the results of Ref mode; the slopes for green and red bands are −7.33 and −5.48, respectively. To determine the reproducibility of the results, all the spectra are recorded at least three times for each tissue depth. The results as shown in Fig. 7D are reproducible with the error bar less than 10%. Compared with the results on liquid phantoms, the G/R attenuation slope in pork muscle is much higher (−4.74), as shown in Fig. 7E. This discrepancy might attribute to the higher effective coefficient difference of the two bands in the pork muscles than that in the liquid phantoms. As the G/R ratio detected is determined by the inherent properties of NaYF4:Yb,Er UCNPs, which is independent of the absolute amount of UCNPs and the excitation power density at the low density level. To prove this hypothesis, different amounts of UCNPs were further embedded in the bottom pork layer and the ascertained tissue depth (as shown in Fig. 7F) was calculated from the G/R ratio (data are shown in Fig. S11). From the linear fitting we see that the calculated depths are in excellent agreement with the actual tissue ones. The standard error is less than 0.15 mm in the range 1–10 mm. In a word, the multispectral UCL imaging can be utilized as an effective method to accurately ascertain the UCNP depth in tissue, i.e. the marked lesion depth position can be accurately determined, which has great potential in tissue engineering and disease diagnosis.


image file: c4nr02090a-f7.tif
Fig. 7 UCL imaging in layered pork muscle tissue at different depths in Ex mode (A) and Em mode (B); (C) and (D) are the corresponding UCL intensities detected in Ex mode and Ref mode, respectively; (E) is the corresponding G/R ratio attenuation curves in Ref mode. (F) The measured depth of pork muscle versus the real depth. Error bars are marked in the figures. The error bars in (F) are due to the distribution of nanoparticles in the bottom pork layer.

4 Conclusions

In conclusion, a theoretical model has been established to relate the relative intensities of the UCL spectra to the tissue imaging depth of UCNPs. The method was validated in liquid phantoms and pork muscle tissue. Although in this work we have focused on NaYF4:Er3+,Yb3+ UCNPs, other upconversion materials can be similarly employed as well for even better penetration, e.g. introducing Tm3+. This new approach shall lift significantly the power of nanotechnology assisted luminescence imaging by providing also accurate information of the depth of UCNP labeled lesion.

Acknowledgements

This work was supported by the NSF of China (61275197, 21304084, 11374297, and 51372096), the Joint research program between KNAW of The Netherlands and CAS of China, the IOP program of the Netherland and John van Geuns Foundation.

Notes and references

  1. V. Ntziachristos, C. Bremer and R. Weissleder, Eur. Radiol., 2003, 13, 195 Search PubMed.
  2. P. P. Ghoroghchian, M. J. Therien and D. A. Hammer, Wiley Interdiscip. Rev.: Nanomed. Nanobiotechnol., 2009, 1, 156 CrossRef CAS PubMed.
  3. M. Bates, B. Huang, G. T. Dempsey and X. Zhuang, Science, 2007, 317, 1749 CrossRef CAS PubMed.
  4. G. Chen, H. Qiu, P. N. Prasad and X. Chen, Chem. Rev., 2014, 114, 5161 CrossRef CAS PubMed.
  5. T. Yang, Y. Sun, Q. Liu, W. Feng, P. Yang and F. Li, Biomaterials, 2012, 33, 3733 CrossRef CAS PubMed.
  6. J. Wang, F. Wang, C. Wang, Z. Liu and X. Liu, Angew. Chem., Int. Ed., 2011, 50, 10369 CrossRef CAS PubMed.
  7. Q. Liu, W. Feng, T. Yang, T. Yi and F. Li, Nat. Protoc., 2013, 8, 2033 CrossRef CAS PubMed.
  8. C. Vinegoni, D. Razansky, S. A. Hilderbrand, F. Shao, V. Ntziachristos and R. Weissleder, Opt. Lett., 2009, 34, 2566 CrossRef CAS PubMed.
  9. T. Y. Cao, Y. Yang, Y. A. Gao, J. Zhou, Z. Q. Li and F. Y. Li, Biomaterials, 2011, 32, 2959 CrossRef CAS PubMed.
  10. A. P. Popov, A. V. Bykov, V. I. Sokolov, Y. V. Lysak, A. Nadort, A. V. Priezzhev, R. Myllylä and A. V. Zvyagin, Proc. SPIE, 2011, 80900V CrossRef PubMed.
  11. C. T. Xu, N. Svensson, J. Axelsson, P. Svenmarker, G. Somesfalean, G. Chen, H. Liang, L. Haichun, Z. Zhiguo and S. Andersson-Engels, Appl. Phys. Lett., 2008, 93, 171103 CrossRef PubMed.
  12. T. V. Esipova, X. Ye, J. E. Collins, S. Sakadzic, E. T. Mandeville, C. B. Murray and S. A. Vinogradov, Proc. Natl. Acad. Sci. U. S. A., 2012, 109, 20826 CrossRef CAS PubMed.
  13. G. Chen, J. Shen, T. Y. Ohulchanskyy, N. J. Patel, A. Kutikov, Z. Li, J. Song, R. K. Pandey, H. Agren, P. N. Prasad and G. Han, ACS Nano, 2012, 6, 8280 CrossRef CAS PubMed.
  14. P. Svenmarker, C. T. Xu and S. Andersson-Engels, Opt. Lett., 2010, 35, 2789 CrossRef PubMed.
  15. X. Wang, J. T. Chen, H. Zhu, X. Chen and X. P. Yan, Anal. Chem., 2013, 85, 10225 CrossRef CAS PubMed.
  16. X. Li, Z. Li, W. Gan, T. Wang, S. Zhao, Y. Lu, J. Cheng and G. Huang, Analyst, 2013, 138, 3711 RSC.
  17. P. Ma, H. Xiao, X. Li, C. Li, Y. Dai, Z. Cheng, X. Jing and J. Lin, Adv. Mater., 2013, 25, 4898 CrossRef CAS PubMed.
  18. S. Nagarajan and Y. Zhang, Nanotechnology, 2011, 22, 395101 CrossRef PubMed.
  19. B. Dong, S. Xu, J. Sun, S. Bi, D. Li, X. Bai, Y. Wang, L. Wang and H. Song, J. Mater. Chem., 2011, 21, 6193 RSC.
  20. J. Wang, H. Song, W. Xu, B. Dong, S. Xu, B. Chen, W. Yu and S. Zhang, Nanoscale, 2013, 5, 3412 RSC.
  21. F. Wang and X. Liu, J. Am. Chem. Soc., 2008, 130, 5642 CrossRef CAS PubMed.
  22. Z. Li, Y. Zhang and S. Jiang, Adv. Mater., 2008, 20, 4765 CrossRef CAS.
  23. R. Chen, V. D. Ta, F. Xiao, Q. Zhang and H. Sun, Small, 2013, 9, 1052 CrossRef CAS PubMed.
  24. L. Cheng, K. Yang, M. Shao, S.-T. Lee and Z. Liu, J. Phys. Chem. C, 2011, 115, 2686 CAS.
  25. Q. Dou, N. M. Idris and Y. Zhang, Biomaterials, 2013, 34, 1722 CrossRef CAS PubMed.
  26. L. Cheng, K. Yang, S. Zhang, M. Shao, S. Lee and Z. Liu, Nano Res., 2010, 3, 722 CrossRef CAS PubMed.
  27. K. Liu, X. Liu, Q. Zeng, Y. Zhang, L. Tu, T. Liu, X. Kong, Y. Wang, F. Cao and S. A. Lambrechts, ACS Nano, 2012, 6, 4054 CrossRef CAS PubMed.
  28. V. Ntziachristos, J. Ripoll, L. H. V. Wang and R. Weissleder, Nat. Biotechnol., 2005, 23, 313 CrossRef CAS PubMed.
  29. F. Leblond, S. C. Davis, P. A. Valdes and B. W. Pogue, J. Photochem. Photobiol., B, 2010, 98, 77 CrossRef CAS PubMed.
  30. J. Jung, N. Cho, J. Kim, E. Choi, S. Lee, H. Byeon, Y. Park, W. Yang and S. H. Kim, Int. J. Oral Surg., 2009, 38, 653 CrossRef CAS PubMed.
  31. M. Hirose, H. Fukui, Y. Igarashi, Y. Fujimori, Y. Katake, A. Sekikawa, K. Ichikawa, S. Tomita, J. Imura and Y. Ajioka, J. Gastroenterol., 2010, 45, 1212 CrossRef PubMed.
  32. M. Pentenero, S. Gandolfo and M. Carrozzo, Head Neck, 2005, 27, 1080 CrossRef PubMed.
  33. X. Montet, V. Ntziachristos, J. Grimm and R. Weissleder, Cancer Res., 2005, 65, 6330 CrossRef CAS PubMed.
  34. C. T. Xu, P. Svenmarker, H. Liu, X. Wu, M. E. Messing, L. R. Wallenberg and S. Andersson-Engels, ACS Nano, 2012, 6, 4788 CrossRef CAS PubMed.
  35. M. Nahrendorf, P. Waterman, G. Thurber, K. Groves, M. Rajopadhye, P. Panizzi, B. Marinelli, E. Aikawa, M. J. Pittet and F. K. Swirski, Arterioscler.Thromb.Vasc.Biol., 2009, 29, 1444 CrossRef CAS PubMed.
  36. C. M. McCann, P. Waterman, J. L. Figueiredo, E. Aikawa, R. Weissleder and J. W. Chen, NeuroImage, 2009, 45, 360 CrossRef PubMed.
  37. H.-S. Qian and Y. Zhang, Langmuir, 2008, 24, 12123 CrossRef CAS PubMed.
  38. N. Bogdan, F. Vetrone, G. A. Ozin and J. A. Capobianco, Nano Lett., 2011, 11, 835 CrossRef CAS PubMed.
  39. S. T. Flock, S. L. Jacques, B. C. Wilson, W. M. Star and M. J. van Gemert, Lasers Surg. Med., 1992, 12, 510 CrossRef CAS.
  40. M. A. Mycek and B. W. Pogue, Handbook of Biomedical Fluorescence, CRC Press, 2003 Search PubMed.
  41. T. J. Farrell, M. S. Patterson and B. Wilson, Med. Phys., 1992, 19, 879 CrossRef CAS.

Footnote

Electronic supplementary information (ESI) available: Absorption spectra of India Ink, Intralipid and pork muscles; NaYF4:Yb,Er upconversion luminescence spectra detected at different depths in tissue mimicking liquid phantoms and pork muscles. See DOI: 10.1039/c4nr02090a
