A high-throughput microfluidic device inspired by the Wheatstone bridge principle for characterizing the mechanical properties of single cells

Abstract

The mechanical properties of single cells have been recognized as biomarkers for identifying individual cells and diagnosing human diseases. Microfluidic devices based on the flow cytometry principle, which are not limited by the vision field of a microscope and can achieve a very high throughput, have been extensively adopted to measure the mechanical properties of single cells. However, these kinds of microfluidic devices usually required pressure-driven pumps with a very low flow rate and high precision. In this study, we developed a high-throughput microfluidic device inspired by the Wheatstone bridge principle for characterizing the mechanical properties of single cells. The microfluidic analogue of the Wheatstone bridge not only took advantage of flow cytometry, but also allowed precise control of a very low flow rate through the constricted channel with a higher input flow rate generated by a commercially available pressure-driven pump. Under different input flow rates of the pump, the apparent elastic moduli and the fluidity of osteosarcoma (U-2OS) cells and cervical carcinoma (HeLa) cells were measured by monitoring their dynamic deformations passing through the bridge-channel with different sizes of rectangular constrictions. The results showed that the input flow rate had little effect on measuring the mechanical properties of the cells, while the ratio of cell radius to effective constriction radius was different, i.e., for U-2OS cells it was 1.20 and for HeLa cells it was 1.09. Under this condition compared with predecessors, our statistic results of cell mechanical properties exhibited minimal errors. Furthermore, the cell viability after measurements was kept above 90% that demonstrated the non-destructive property of our proposed method.
