Juliane
Adler
a,
Holger A.
Scheidt
a,
Katharina
Lemmnitzer
a,
Martin
Krueger
b and
Daniel
Huster
*a
aInstitute for Medical Physics and Biophysics, Leipzig University, Härtelstr. 16-18, 04107 Leipzig, Germany. E-mail: daniel.huster@medizin.uni-leipzig.de; Fax: +49 (0)341 9715709; Tel: +49 (0)341 9715701
bInstitute for Anatomy, Leipzig University, D-04103 Leipzig, Germany
First published on 16th December 2016
Fibril formation of amyloid β(1–40) (Aβ(1–40)) peptides N-terminally lipid modified with saturated octanoyl or palmitoyl lipid chains was investigated. Lipid modification of Aβ(1–40) significantly accelerates the fibrillation kinetics of the Aβ peptides as revealed by ThT fluorescence. Electron microscopy and X-ray diffraction results indicate a heterogeneous cross-β structure of the fibrils formed by the lipid-conjugated peptides. Solid-state NMR was used to investigate structural features of these fibrils. The lipid moieties form dynamic and loosely structured heterogeneous lipid assemblies as inferred from 2H NMR of the deuterated lipid chains. 13C NMR studies of selected isotopic labels reveals that in addition to Phe19 and Val39, which are part of the canonical cross-β structure, also N-terminal residues (Ala2, Phe4, Val12) are found in β-strand conformation. This suggests that the increased hydrophobicity induced by the lipid modification, alters the energy landscape rendering an N-terminal extension of the β-sheet structure favorable. Furthermore, the fibrils formed by the Aβ–lipid hybrids are much more rigid than wildtype Aβ fibrils as inferred from NMR order parameter measurements. Taken together, increasing the local hydrophobicity of the Aβ N-terminus results in highly ordered but heterogeneous amyloid fibrils with extended N-terminal β-sheet structure.
Peptide–polymer conjugates represent an interesting class of such hybrid molecules. They combine the wealth of the thermotropic structural polymorphism of (synthetic) polymers with the biologically important process of protein structure formation usually referred to as folding. In addition to native protein folding into the active state, misfolding into amyloid structures is observed for both intrinsically disordered and well-folded proteins.5 Amyloid formation is a self-organization process that many proteins and peptides of very different structural features can undergo leading to ordered aggregates that are characterized by a relatively generic cross-β structure6,7 that is typically very well defined.8–10 Synthetic polymers can also assemble into multiple structures, which include, for instance, coiled structures, amorphous and highly ordered crystalline phases, as well as a multitude of curved (micellar, hexagonal, inverse hexagonal) or lamellar structures. Structure formation of polymers is governed by straightforward thermodynamics.11,12
Amyloid–polymer hybrids hold great potential for understanding some underlying questions of structure formation. The perhaps most simple polymer modification of proteins is the attachment of poly(ethylene glycol), also called PEGylation, which is also applied in several protein-based medicines to mask a therapeutic protein or drug delivery system from the immune response of the host.13 In basic research, conjugation of amyloid forming peptides with PEG provides insights into the structure forming properties of these hybrids. Previous work has focused on the assembly properties of shorter fragments of amyloid β (Aβ) peptides, C-terminally conjugated with PEG14–18 or N-terminally with poly(N-isopropylacrylamide) and poly(hydroxyethylacrylate).19 These studies found a predominance of β-sheet structures, but also coiled coils19 or spherulite structures14 have been observed suggesting that other structure forming processes and principles can interfere with amyloid formation. PEG–Aβ hybrids represent interesting model systems to study the competition of PEG crystallization and peptide secondary structure formation.14 Depending on the length of the PEG chain and the respective peptide segment, both the presence or absence of the characteristic cross-β structure has been confirmed.14
Covalent lipid attachment is a biologically occurring mechanism of protein modification typically encountered when otherwise soluble proteins obtain a propensity to bind to lipid membrane surfaces.20–22 Lipid chains can also be viewed as simple short hydrophobic polymers. Protein–lipid conjugates, therefore, represent interesting hybrid systems that allow addressing fundamental questions of amyloid structure formation. Although none of the biologically relevant proteins that form amyloids are reported to undergo lipid modification in vivo, lipidation locally increases the hydrophobicity of the biological copolymer. This allows addressing the question if the self-assembly reaction of amyloid formation is governed by the hydrophobic effect and increased entropy upon water desolvation9 or requires very specific interactions between residues that result in structural motifs suggestive of a tight, dry steric fit between a pair of sheets that represents the fundamental feature of amyloid fibrils as first highlighted for short peptide sequences (“steric zipper”).23 While general alteration of the hydrophobicity in the β-sheet core of the Aβ sequence resulted in moderate changes in the fibrillation kinetics and local structure and dynamics,24,25 the more recently published highly resolved solid-state NMR structures of Aβ(1–42) provide strong evidence for rather specific interactions on the single residue scale.8–10 However, this is only true for the well-ordered part of the Aβ fibrils, which starts at around residue 15.
Full length Aβ peptides carrying an N-terminal polymer or lipid conjugation have not been studied so far. Here, we describe Aβ(1–40) peptides conjugated with saturated C8:0 (octanoyl) or C16:0 (palmitoyl) lipid chains on the N-terminus. This modification serves three purposes: (i) the hydrophobic lipid tail locally increases the hydrophobicity of the Aβ molecule by ΔG0 = −5.8 and –12.4 kcal mol−1 for octanoyl and palmitoyl residues, respectively,26,27 which should influence the fibrillation kinetics and possibly the extent of the cross-β structure formed. (ii) Lipids are known to show a rich thermotropic phase behavior that results in the assembly into micelles, (inverse) hexagonal structures, or bilayers, which could interfere with amyloid structure formation. This poses the question which structure forming process dominates – peptide amyloid or lipid structure formation. (iii) The lipid modification and the cross-β core of Aβ peptides are linked by the charged and rather hydrophilic N-terminus of the molecules, which has no fibrillating properties and was found to be highly dynamic in solid-state NMR studies.8,28 This raises the question if the two structure forming principles may progress independent of each other or lead to new structural features.
2H NMR spectra were acquired on a Bruker Avance I 750 MHz NMR spectrometer (Bruker Biospin GmbH, Rheinstetten, Germany) operating at a resonance frequency of 115.1 MHz for 2H. A single-channel solids probe equipped with a 5 mm solenoid coil was used. The 2H NMR spectra were accumulated with a spectral width of ±250 kHz using quadrature phase detection. A phase-cycled quadrupolar echo sequence33 was used. The typical length of a 90° pulse was 2.7 to 3.0 μs, the interpulse delay was 30 μs, and a relaxation delay of either 1 s or 50 s was applied.
Magic-angle spinning (MAS) NMR spectra were acquired on a Bruker 600 Avance III NMR spectrometer (Bruker BioSpin GmbH, Rheinstetten, Germany) operating at a resonance frequency of 600.1 MHz for 1H, 150.9 MHz for 13C and 60.8 MHz for 15N. A triple channel 3.2 mm MAS probe was used. Typical pulse lengths were 4 μs for 1H and 13C and 5 μs for 15N. 1H–13C and 1H–15N contact time were 1 ms at a spin lock field of ∼60 kHz, and the relaxation delay 2.5 s. 1H dipolar decoupling during acquisition with an rf amplitude of 70 kHz was applied using Spinal64.
13C–13C DARR and 13C–15N correlation spectra were acquired simultaneously using dual-acquisition.34 In the same experiment, two-dimensional 13C–13C DARR NMR spectra with mixing times of 100 ms or 600 ms with 128 data points and four 15N–13Cα correlation spectra with 32 data points in the indirect dimensions were acquired. The MAS frequency was 11777 Hz.
1H–13C coupling constants were measured using the constant time DIPSHIFT experiments.35 Homonuclear decoupling during dipolar evolution was achieved by applying the frequency switched Lee-Goldberg (FSLG)36 scheme with an effective radiofrequency field of 80 kHz. The MAS frequency was 5 kHz. The strength of the dipolar coupling was determined from the dephasing curves for each resolved carbon atom by analyzing them with numerical simulations and dividing the result by the rigid limits.37,38
All NMR spectra were acquired at a temperature of 30 °C.
Fig. 1 Thioflavin T (ThT) fluorescence intensity of Aβ(1–40) wildtype (black), octanoyl–Aβ(1–40) (red) and palmitoyl–Aβ(1–40) (blue) as a function of time. The asterisk at 45 minutes indicates the beginning of the fluorescent measurement after prior sample treatment (shaking and heating). Data were fitted using functions discussed in the literature.39 |
We also carried out ThT fluorescence kinetics measurements of wildtype Aβ(1–40) peptides in the presence of equimolar concentration of octanoic and palmitic acid, respectively, shown in Fig. S1 (ESI†). The CMC of the free fatty acids was determined to be 54.1 μM for palmitic acid and 50.6 mM for octanoylic acid, so the peptide concentration of 230 μM used in the measurements was in between these values. In the presence of equimolar concentrations of octanoic acid the lag time of wildtype Aβ(1–40) fibrillation is decreases by ∼45%, while only a moderate effect was observed in the presence of 230 μM palmitic acid (lag time reduced by ∼3%).
Fig. 2 Transmission electron micrographs of fibrils of wildtype Aβ(1–40) (A), octanoyl–Aβ(1–40) (B), and palmitoyl–Aβ(1–40) (C). The scale bar represents 500 nm. |
X-ray diffraction images show the two typical reflections of the cross-β structure of amyloid fibrils, with one sharp reflection describing a fixed distance of 4.7 Å, which defines the interstrand hydrogen bond distance and one broad peak, which characterizes the intersheet distance of the opposing β-strands.40 The X-ray diffraction pattern of wildtype and lipid-conjugated Aβ(1–40) are displayed in Fig. S2 of the ESI.† The width of the reflections is an indication of heterogeneity of the fibrils. The broad reflections indicate intersheet distances of 11.0 Å for octanoyl–Aβ(1–40) and 10.2 Å for palmitoyl–Aβ(1–40). These reflections are much broader for the lipid-conjugated Aβ peptide fibrils indicating higher heterogeneity and possibly structural polymorphism.
Fig. 3 Overview of the local secondary structure of the labelled amino acids Ala2, Phe20, Gly25, and Val39 of the conjugated peptides derived from the 13C NMR chemical shifts. Plotted are the 13Cα–13Cβ chemical shift changes for Ala2, Phe20, and Val39 as well as the absolute 13CO chemical shift of Gly25. A second set of N-terminal chemical shift values is given for palmitoyl–Aβ(1–40) including residues Phe4, Ser8, Gly9, and Val12. The bars represent the reference values of α-helix, random coil and β-sheet secondary structure as reported in the literature.41 Experimental data is given as black squares for Aβ(1–40) wildtype, red crosses for octanoyl–Aβ(1–40), and as blue circles for palmitoyl–Aβ(1–40). |
To further investigate the possible N-terminal extension of the fibrillar structure of lipid conjugated Aβ(1–40) fibrils, an additional palmitoylated-Aβ(1–40) peptide variant with isotopic labels in positions Phe4, Ser8, Gly9, and Val12 was prepared. All these isotopic labels were concentrated in the N-terminus. The solid-state NMR chemical shifts of these amino acids are also shown in Fig. 3 and Table S1 (ESI†). Confirming the results for Ala2, β-sheet structure was also found for Phe4 and Val12. The chemical shift of Gly9 is random coil, while chemical shift data for Ser8 is not conclusive as chemical shift data of serine in random coil and β-sheet secondary structure is indistinguishable.41
Fig. 4 Static 2H NMR spectra of octanoyl-d15–Aβ(1–40) (red) and palmitoyl-d31–Aβ(1–40) (blue). The inset shows the 2H NMR spectrum of palmitic acid-d31. |
In general, the fibrils formed by the lipid-conjugated Aβ(1–40) peptides showed higher order parameters than wildtype Aβ(1–40) fibrils indicative of more compact packing of the individual molecular segments. The most pronounced ordering is observed for residues Ala2 and Phe4, which also showed the most drastic secondary structure change. While in wildtype Aβ(1–40) fibrils, the N-terminus is unstructured and relatively mobile,28 lipid conjugated Aβ(1–40) peptides form fibrils where the N-terminus is in β-sheet structure that is more restricted expressed by higher order parameters, which is also in agreement with the β-sheet structure found for Ala2 and Phe4. Most other residues show slightly higher order parameters, but the differences lie within experimental error of the measurement.
All these effects can be explained by the increased hydrophobicity of Aβ induced by the lipidated N-terminus. In aqueous environment, lipid chains have a high propensity to assemble to form structures such as micelles or bilayers. We determined the CMC of palmitic and octanoic acid to be 54.1 μM and 50.6 mM, respectively. Fibrillation experiments of the lipid-conjugated Aβ peptides were done at a peptide concentration of 230 μM, which is above the CMC of palmitic acid and much below the CMC of octanoic acid. This may explain why palmitoyl–Aβ(1–40) showed very fast amyloid forming kinetics as prefibrillar micellar aggregates may form instantaneously. Furthermore, even though the octanoyl–Aβ(1–40) concentration was much below the CMC, still the fibrillation kinetics was faster suggesting that the increase in hydrophobicity does indeed contribute to the fibrillation kinetics.
Our data suggest that the N-terminal lipid modifications of Aβ also form some loosely structured heterogeneous lipid assembly, which is however rather dynamic. However, there are no bilayer or hexagonal lipid phases formed. Clearly, this tendency also helps to associate the hybrid molecules to form Aβ fibrils as indicated by much accelerated fibrillation kinetics. Likely, N-terminal lipid modifications decrease the energy barrier separating the unstructured and the amyloid states. The lipids of the N-terminal part of the lipidated Aβ peptides are dynamic and loosely associated as indicated by the 2H NMR spectra of the deuterated lipid modifications. We did not detect the well-known superposition of 2H NMR Pake spectra with varying quadrupolar splittings as known from liquid crystalline membranes or inverse hexagonal lipid structures.42 Rather, the observed Super-Lorentzian lineshape of the 2H NMR spectra of the lipid chains indicates that the lipid moieties in the aggregated structures undergo multiple conformational transitions on a fast and intermediate time scale. As oppose to free lipid micelles in aqueous solution, the N-terminal lipid modifications linked to Aβ peptides cannot undergo fast diffusion on the highly curved micellar surface; neither can the micelles tumble freely in solution as they are constraint by the amyloidic peptide segments. As a consequence, the NMR line at half maximum is rather broad (∼6.5 kHz), which is clearly much higher than what is known for free detergent micelles.45 A residual quadrupolar splitting of 6.5 kHz would correspond to a 2H NMR order parameter of 0.05. This is much lower than the 0.65 that has been reported for the first amino acid of unmodified Aβ(1–40).28 However, as spectral intensity spreads out up to widths of >50 kHz, also relatively ordered lipid segments are present in these preparations emphasizing the very high gradient in the segmental dynamics of these lipid assemblies.
Very short fibril forming dipeptides with N-terminal lipid modifications have been studied before.46 These peptides formed well-ordered fibrils and the lipid modifications were found in a crystalline structure as if they were part of the fibril.46 Clearly, lipid modified Aβ(1–40) peptides form more heterogeneous assemblies and are not part of a highly ordered structure. As the morphological data (electron microscopy, X-ray diffraction) as well as the fact that the NMR measurements indicate several polymorphs suggest, fibrils of lipid-conjugated Aβ(1–40) peptides are somewhat more heterogeneous than wildtype Aβ fibrils.
Most interestingly, the 13C solid-state NMR results reveal that a significant reorganization of the N-terminal part of the Aβ hybrids occurs. Drastic 13C NMR chemical shift changes of Ala2 and Phe4 indicate that the N-terminus undergoes a structural change from random coil in wildtype Aβ(1–40) to a well-defined β-sheet structure. Furthermore, the segmental order parameter for the Cα–H bond vector of Ala2 increases from 0.65 in unmodified Aβ to 0.9 in the two lipid-conjugated peptides. The order parameter of Phe4 in palmitoyl–Aβ(1–40) increases to 0.85 compared to 0.61 in wildtype Aβ fibrils. This means that the amplitudes of the fluctuations, the 1H–13Cα bond vectors in the N-terminus of the lipid-conjugated Aβ fibrils undergo, are significantly reduced. Furthermore, there appears to be a very steep gradient in the amplitude of the molecular fluctuations from the N-terminal residues to the lipid segments of the lipid chains. The structuring of the N-terminus of Aβ as well as the assembly of the lipid modification does not depend on the length of the lipid chain attached to the peptide.
The structure of the core of the Aβ fibril is not influenced by the N-terminal lipid conjugation. Nevertheless, the investigated amino acids of the fibril core experience a substantial increase in their order parameters, indicating a more compact packing of the fibrils. The turn region, which was probed by Gly25, however, remained uninfluenced by the N-terminal lipid modification.
Apparently, the energy landscape of Aβ misfolding is modified by the solvent conditions or the hydrophobicity of the entire molecule, which can lead to more or less extended cross-β structures.
Implications of our findings can be found, for instance, in the biologically relevant interaction of amyloid forming protein with biological membranes.47 As proteins that form amyloids typically consist of a fibril part, organized in the cross-β structure, and unstructured flexible segments that flank the core of the fibrils,48–50 the extent of β-structure may vary significantly in the vicinity of membrane surfaces. This may also lead to tertiary structure changes of the Aβ amyloids, which could be relevant with regard to their toxic effects on neurons by disrupting the cellular membranes.51
In conclusion, we investigated the interplay between lipid assembly versus amyloid structure formation in hybrid molecules of lipid conjugated Aβ peptides. The results show that cross-β structure formation is accelerated for the more hydrophobic N-termini of the Aβ peptides. This suggests that amyloid formation is the dominating structure forming mechanism in these lipid-modified Aβ peptides. The lipid moieties on the N-terminus show a tendency for a dynamic heterogeneous lipid assembly that is loosely structured. The association of the lipidated N-termini induces largely immobilized β-strand structure at least for the first amino acids of the Aβ N-terminus. However, this likely fibrillar structure is also heterogeneous. This suggests that the extent of the cross-β structure found in amyloids sensitively depends on local hydrophobicity imposed onto the sequence. This supports the high fibrillation capacity of Aβ peptides that can apparently also extend towards the N-terminus if it is constraint by formation of an aggregated lipid phase.
Footnote |
† Electronic supplementary information (ESI) available. See DOI: 10.1039/c6cp05982a |
