Microfluidic flow-focusing in ac electric fields

Author affiliations

Abstract

We demonstrate the control of droplet sizes by an ac voltage applied across microelectrodes patterned around a flow-focusing junction. The electrodes do not come in contact with the fluids to avoid electrochemical effects. We found several regimes of droplet production in electric fields, controlled by the connection of the chip, the conductivity of the dispersed phase and the frequency of the applied field. A simple electrical modelling of the chip reveals that the effective voltage at the tip of the liquid to be dispersed controls the production mechanism. At low voltages (≲ 600 V), droplets are produced in dripping regime; the droplet size is a function of the ac electric field. The introduction of an effective capillary number that takes into account the Maxwell stress can explain the dependance of droplet size with the applied voltage. At higher voltages (≳ 600 V), jets are observed. The stability of droplet production is a function of the fluid conductivity and applied field frequency reported in a set of flow diagrams.

Graphical abstract: Microfluidic flow-focusing in ac electric fields

Back to tab navigation
Please wait while Download options loads

Publication details

The article was received on 07 Oct 2013, accepted on 02 Dec 2013 and first published on 09 Jan 2014


Article type: Paper
DOI: 10.1039/C3LC51143J
Citation: Lab Chip, 2014,14, 1099-1106
  • Open access: Creative Commons BY license
  •   Request permissions

    Microfluidic flow-focusing in ac electric fields

    S. H. Tan, B. Semin and J. Baret, Lab Chip, 2014, 14, 1099
    DOI: 10.1039/C3LC51143J
